- Page 1 MOUNTING AND INSTRUCTION MANUAL Multi Signal Converter MSC Cascadable Signal-Converter / Distributor Article No. 133286 without fiber optic (FO) Article No. 133287 with fiber optic input and output (FO IN, OUT) Please read these instructions carefully before installation. © MOBATIME...
- Page 2 5. It is prohibited to copy this publication or to store it on a computer system. All rights reserved. Copyright © BÜRK MOBATIME GmbH D-78026 VS-Schwenningen / GERMANY and MOSER-BAER AG CH 3454 Sumiswald / SWITZERLAND.
-
Page 3: Table Of Contents
Appropriate accessories - Mains power supply ..................7 Function description ..........................7 Configuration, Displays and Connections ..................... 8 Application examples and circuits ......................... 9 Detailed wiring examples of the inputs and outputs ..................10 Technical data ............................. 14 Dimensions ..............................15 © MOBATIME 3 / 16 801367.01... -
Page 4: Safety
Ideally, the device is used for digital sig- nals. See also chapter 7 Technical data. Please refer to section - 3.3 Function description - for a detailed function description. © MOBATIME 4 / 16 801367.01... -
Page 5: Observe Operating Safety
Great fluctuations in temperature or humid- ity may lead to moisture within the device caused by condensation, which can cause a short. Observe electromagnetic compatibility! The device complies with the requirements of EMC directive 2004/108/EC and Vorsicht! 96/48/EC © MOBATIME 5 / 16 801367.01... -
Page 6: Maintenance
Return your device to your supplier who will dispose of it correctly. Packaging Your device is packaged to protect it from damages during transport. Packaging is made of materials that can be disposed of in an environmentally friendly manner and properly recycled. © MOBATIME 6 / 16 801367.01... -
Page 7: General Information: Introduction
- Very low signal propagation delay - DC Out for GNSS receiver or cascaded de- vices, limited to 30V (@ UIN >30V). - 2 LEDs for supervision: power and input sig- - Replaces DCF-Multi-4 and 10x-DCF-Multi- plexer © MOBATIME 7 / 16 801367.01... -
Page 8: Configuration, Displays And Connections
The inversion only takes place for "DCF OUT" and "FO OUT". The output "TTL OUT" is not af- fected since the signal is already available in inverted form (-). © MOBATIME 8 / 16 801367.01... -
Page 9: Application Examples And Circuits
DCF OUT: Current-loop passiv current-limiter Opto- Mains Mains coupler Optical fiber Optical fiber SIG IN: 2-24V 2.5V SIG OUT: 5V TTL 50Ω Mains Mains 50Ω Slave DCF OUT (RS422) (current-loop) © MOBATIME 9 / 16 801367.01... -
Page 10: Detailed Wiring Examples Of The Inputs And Outputs
SIG IN 3-5V Logic (Mode 3 or 4) or MOBALine RS 422 Signal Reference-GND 24V input from a PLC (inverted) 24V input from a PLC SIG IN SIG IN minus minus Optional 4.7-22kOhms Optional 4.7-22kOhms © MOBATIME 10 / 16 801367.01... - Page 11 ANTENNA Master clock Current loop Operating threshold of the current detection: ca. 6mA. Short-circuit current: ca. 30mA. Current loop from a third party device Third party device ANTENNA 30V/30mA Open Current loop collector output © MOBATIME 11 / 16 801367.01...
- Page 12 5V logic 5V logic not inverted 24V 3rd party dev. 3 24V signal Opto coupler active 24V power supply - External - e.g. from SPS 3rd party dev. 4 24V signal Input SPS Input © MOBATIME 12 / 16 801367.01...
- Page 13 RS 422 → Optical transmission to 2. Multi Signal Converter FiberOptic – data converter FiberOptic FO IN → RS 422 OUT resp. TTL OUT FiberOptic – current converter/distr. FiberOptic FO IN → 4xDCF OUT © MOBATIME 13 / 16 801367.01...
-
Page 14: Technical Data
(current loop): max. 500kHz voltage signal (open collector): max. 50kHz Technical parameters: Temperature range -20 .. +70°C Dimensions L x B x H 94mm x 94mm x 60mm Mounting DIN rail 35mm Weight 200g © MOBATIME 14 / 16 801367.01... -
Page 15: Dimensions
Dimensions 53 mm 95 mm © MOBATIME 15 / 16 801367.01... - Page 16 © MOBATIME BE-801367.01...
