Summary of Contents for Crestron Electronics CEN-RGBHV32X32

  • Page 1 Crestron CEN-RGBHV32X32 32x32 Matrix Switchers Operations Guide...
  • Page 2 IMPORTANT: • Disconnect power prior to connecting or disconnecting equipment. The CEN-RGBHV32X32 can be used with Class 2 output • Do not install in direct sunlight. wiring. • The apparatus must be installed in a way that the power cord can be removed either from the wall outlet or from the device itself in order to disconnect the mains power.
  • Page 3 Regulatory Compliance As of the date of manufacture, the CEN-RGBHV32X32 has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling. Federal Communications Commission (FCC) Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions: (1) This device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 5: Table Of Contents

    Crestron CEN-RGBHV32X32 32x32 Matrix Switchers Contents 32x32 Matrix Switchers: CEN-RGBHV32X32 Introduction ..........................1 Features and Functions ....................1 Specifications ......................3 Physical Description....................5 Setup ............................16 Network Wiring......................16 Identity Code ......................16 Installation ......................... 17 Hardware Hookup ..................... 19 Programming Software ......................
  • Page 7: 32X32 Matrix Switchers: Cen-Rgbhv32X32

    (CEN-RGBHV32X32A) and full Crestron control system integration, the CEN-RGBHV32X32V and CEN-RGBHV32X32A (hereinafter collectively referred to as “CEN-RGBHV32X32”, except where noted), satisfy the demanding video and audio requirements of corporate boardrooms and training centers, university lecture halls, high-tech houses of worship, command and control facilities and live staging events.
  • Page 8 SIMPL™ Windows or SystemBuilder™ without deciphering cryptic protocols. Up to 10 routing presets can be saved onboard the CEN-RGBHV32X32 for instant recall. Integration with any ® 2-Series Control system also provides the gateway to Crestron’s RoomView Asset ®...
  • Page 9: Specifications

    When linked, the two components operate as one, allowing audio-follow-video or audio breakaway capability, with full setup and control enabled from the RGB switcher’s front panel as well as from a control system. Specifications Specifications for the CEN-RGBHV32X32 are listed in the following table. CEN-RGBHV32X32 Specifications SPECIFICATION DETAILS...
  • Page 10 NOTE: Crestron software and any files on the website are for authorized Crestron dealers and Crestron Authorized Independent Programmers (CAIP) only. New users may be required to register to obtain access to certain areas of the site (including the FTP site). 4 • 32x32 Matrix Switchers: CEN-RGBHV32X32 Operations Guide – DOC. 6758A...
  • Page 11: Physical Description

    Crestron CEN-RGBHV32X32 32x32 Matrix Switchers Physical Description This section provides information on the connections, controls and indicators available on your CEN-RGBHV32X32. CEN-RGBHV32X32V Front View 32x32 Matrix Switchers: CEN-RGBHV32X32 • 5 Operations Guide – DOC. 6758A...
  • Page 12 32x32 Matrix Switchers Crestron CEN-RGBHV32X32 CEN-RGBHV32X32V Rear View 6 • 32x32 Matrix Switchers: CEN-RGBHV32X32 Operations Guide – DOC. 6758A...
  • Page 13 Crestron CEN-RGBHV32X32 32x32 Matrix Switchers CEN-RGBHV32X32A Front View CEN-RGBHV32X32A Rear View 32x32 Matrix Switchers: CEN-RGBHV32X32 • 7 Operations Guide – DOC. 6758A...
  • Page 14 32x32 Matrix Switchers Crestron CEN-RGBHV32X32 CEN-RGBHV32X32V Overall Dimensions (Front View) 19.00 in (483 mm) 15.72 in (400 mm) 11 12 13 8 • 32x32 Matrix Switchers: CEN-RGBHV32X32 Operations Guide – DOC. 6758A...
  • Page 15 Crestron CEN-RGBHV32X32 32x32 Matrix Switchers CEN-RGBHV32X32V Overall Dimensions (Top View) 17.58 in (447 mm) 18.96 in (482 mm) 18.36 in (467 mm) 0.60 in (16 mm) 32x32 Matrix Switchers: CEN-RGBHV32X32 • 9 Operations Guide – DOC. 6758A...
  • Page 16 32x32 Matrix Switchers Crestron CEN-RGBHV32X32 CEN-RGBHV32X32V (Rear View) CEN-RGBHV32X32A Overall Dimensions (Front View) 19.00 in (483 mm) 5.20 in (133 mm) 10 • 32x32 Matrix Switchers: CEN-RGBHV32X32 Operations Guide – DOC. 6758A...
  • Page 17 Crestron CEN-RGBHV32X32 32x32 Matrix Switchers CEN-RGBHV32X32A Overall Dimensions (Top View) 19.88 in (505 mm) 19.62 in (499 mm) 17.03 in (433 mm) CEN-RGBHV32X32A (Rear View) 32x32 Matrix Switchers: CEN-RGBHV32X32 • 11 Operations Guide – DOC. 6758A...
  • Page 18 (3) high bandwidth video inputs plus (2) sync inputs; Output level: 0.2 to 5.0 V Output impedance: 75 Ω nominal Return loss: < -30 dB @ 5 MHz (Continued on following page) 12 • 32x32 Matrix Switchers: CEN-RGBHV32X32 Operations Guide – DOC. 6758A...
  • Page 19 250 Volt, 5 A, time-lag CEN-RGBHV32X32A: 20 mm x 5 mm 250 Volt, 1 A, time-lag POWER SWITCH (1) Rocker switch, turns main power on or off (Continued on following page) 32x32 Matrix Switchers: CEN-RGBHV32X32 • 13 Operations Guide – DOC. 6758A...
  • Page 20 (32) 5-pin 3.5 mm detachable terminal (1 – 32) blocks; Balanced/unbalanced stereo line level outputs; Maximum output level: 12 V balanced, unbalanced; Output impedance: 100 Ω balanced, 50 Ω unbalanced (Continued on following page) 14 • 32x32 Matrix Switchers: CEN-RGBHV32X32 Operations Guide – DOC. 6758A...
  • Page 21 5. To determine which is pin 1 on the cable, hold the cable so that the end of the eight pin modular plug is facing away from you, with the clip down and copper side up. Pin 1 is on the far left. 6. CEN-RGBHV32X32A only. 32x32 Matrix Switchers: CEN-RGBHV32X32 • 15 Operations Guide – DOC. 6758A...
  • Page 22: Setup

    Identity Code Net ID The Net ID of the CEN-RGBHV32X32 has been factory set to 33. The Net IDs of multiple CEN-RGBHV32X32 devices in the same system must be unique. Net IDs are changed from a personal computer (PC) via the Crestron Toolbox™ (refer to “Establishing Communication”...
  • Page 23: Installation

    32x32 Matrix Switchers Installation Ventilation The CEN-RGBHV32X32 should be used in a well-ventilated area. The venting holes should not be obstructed under any circumstances. To prevent overheating, do not operate this product in an area that exceeds the environmental temperature range listed in the table of specifications. Consider using forced air ventilation and/or incrementing the spacing between units to reduce overheating.
  • Page 24 These feet should be attached prior to the hookup procedure. Refer to the following illustration for placement of the feet. Foot Placement for the CEN-RGBHV32X32A Place Feet in Corners 18 • 32x32 Matrix Switchers: CEN-RGBHV32X32 Operations Guide – DOC. 6758A...
  • Page 25: Hardware Hookup

    Refer to “Network Wiring” on page 16 before attaching the 4-position terminal block connector. Apply power after all connections have been made. Hardware Connections for the CEN-RGBHV32X32V (Front View) COMPUTER: To PC 32x32 Matrix Switchers: CEN-RGBHV32X32 • 19 Operations Guide – DOC. 6758A...
  • Page 26 Other Cresnet Devices LAN: 10/100BASE-T Ethernet to LAN (VIDEO) OUT: To RGBHV Inputs NOTE: Ensure the unit is properly grounded. Hardware Connections for the CEN-RGBHV32X32A (Front View) COMPUTER: To PC 20 • 32x32 Matrix Switchers: CEN-RGBHV32X32 Operations Guide – DOC. 6758A...
  • Page 27 2 + Out 2 – signal return Open jumper to GND Typical Balanced Input and Output Balanced Balanced Input Output Shield Shield Source 1 Chan 2 Source 2 Chan 1 32x32 Matrix Switchers: CEN-RGBHV32X32 • 21 Operations Guide – DOC. 6758A...
  • Page 28 Shield Fuse Replacement If the CEN-RGBHV32X32 does not power up when it is plugged into an AC outlet, its fuse may need to be replaced. The fuse holder is located on the rear panel, just above the power switch. To replace the fuse: 1.
  • Page 29: Programming Software

    SystemBuilder from the Crestron website and examine the extensive help file. Programming with SIMPL Windows NOTE: While SIMPL Windows can be used to program the CEN-RGBHV32X32, it is recommended to use SystemBuilder for configuring a system. SIMPL Windows is Crestron’s premier software for programming Crestron control systems.
  • Page 30 Crestron CEN-RGBHV32X32 Locating the CEN-RGBHV32X32 (Cresnet) in the Device Library To incorporate the CEN-RGBHV32X32 (Ethernet) into the system, drag the CEN-RGBHV32X32 from the Ethernet Control Modules | Ethernet Video Modules folder of the Device Library and drop it in the System Views.
  • Page 31 Net ID or IP ID as shown in the following illustration. C2Net Device, Slots 8 and 9 3. Additional CEN-RGBHV32X32 devices are assigned different Net ID or IP ID numbers as they are added. 4. If necessary, double click a device to open the “Device Settings” window and change the Net ID or IP ID as shown in the following figure.
  • Page 32: Example Program

    The symbol can be viewed by double clicking on the icon or dragging it into Detail View. Each signal in the symbol is described in the SIMPL Windows help file (F1). Example Program An example program for the CEN-RGBHV32X32 is available from the Crestron website (www.crestron.com/exampleprograms). 26 • 32x32 Matrix Switchers: CEN-RGBHV32X32...
  • Page 33: Uploading And Upgrading

    Finally, program checks can be performed (such as changing the device ID or creating an IP table) to ensure proper functioning. Establishing Communication Use Crestron Toolbox for communicating with the CEN-RGBHV32X32; refer to the Crestron Toolbox help file for details. There are three methods of communication. Indirect Communication...
  • Page 34: Programs And Firmware

    CEN-RGBHV32X32 Crestron Toolbox The COMPUTER port on the CEN-RGBHV32X32 connects to the USB port on the PC via the included Type-A to Type B USB cable: 1. Use the Address Book in Crestron Toolbox to create an entry using the expected communication protocol (USB).
  • Page 35: Program Checks

    Functions menu to display actions that can be performed on the CEN-RGBHV32X32. Be sure to use the Crestron Toolbox to create the CEN-RGBHV32X32 IP table. 1. Select Functions | IP Table Setup. 2. Add, modify or delete entries in the IP table. The CEN-RGBHV32X32 can have only one IP table entry.
  • Page 36: Operation

    MAC Address NOTE: The Audio Setup screens will not appear if the CEN-RGBHV32X32V is not connected to a CEN-RGBHV32X32A, with the CEN-RGBHV32X32A in slave mode, as described on this page. 30 • 32x32 Matrix Switchers: CEN-RGBHV32X32 Operations Guide – DOC. 6758A...
  • Page 37: Setup And Information Screens

    NOTE: The ▲and ▼symbols in the lower right corner of the display let you know if there are screens available above and/or below the presently displayed screen. 32x32 Matrix Switchers: CEN-RGBHV32X32 • 31 Operations Guide – DOC. 6758A...
  • Page 38 ENTER button. Input Compensation Screen 2 To adjust gain, press an input Press the front panel IN button for the input source you wish to adjust. 32 • 32x32 Matrix Switchers: CEN-RGBHV32X32 Operations Guide – DOC. 6758A...
  • Page 39 Use the quick-adjust knob to change the output level. In this example, we will lower the output level by 1%. The display will show the change in output level along with a bar graph. 32x32 Matrix Switchers: CEN-RGBHV32X32 • 33 Operations Guide – DOC. 6758A...
  • Page 40 Use the quick-adjust knob to select another input or press MENU to return to the “Input Names” screen. From the “Input Names” screen, use the quick- adjust knob to select another Audio Setup parameter. The next parameter is Output Names. 34 • 32x32 Matrix Switchers: CEN-RGBHV32X32 Operations Guide – DOC. 6758A...
  • Page 41 Audio: “Audio Blanking” Screen Audio Blanking Audio Setup Audio Blanking To set audio blanking, press ENTER. Use the quick-adjust knob to turn audio blanking on or off. 32x32 Matrix Switchers: CEN-RGBHV32X32 • 35 Operations Guide – DOC. 6758A...
  • Page 42 Using the quick-adjust knob, you can change to any of the other parameters of the Video Setup menu. When you see the parameter you wish to enter, press the ENTER button. 36 • 32x32 Matrix Switchers: CEN-RGBHV32X32 Operations Guide – DOC. 6758A...
  • Page 43 To set up an output name, press the ENTER button. “Sel. output to name” Screen Sel. output to name 1:OUT1 Use the quick-adjust knob to select the output you wish to name. Then press ENTER. 32x32 Matrix Switchers: CEN-RGBHV32X32 • 37 Operations Guide – DOC. 6758A...
  • Page 44 Blanking” screen. Use the quick-adjust knob to select another Video Setup parameter or press MENU to return to the “Video Setup” category screen. Use the quick-adjust knob to select another category. The next category is Blanking Setup. 38 • 32x32 Matrix Switchers: CEN-RGBHV32X32 Operations Guide – DOC. 6758A...
  • Page 45 Press ENTER to save the new setting. The display will return to the “Blanking Setup” screen. Press ENTER to select another output. Use the quick-adjust knob to select another category. The next category is Network Setup. 32x32 Matrix Switchers: CEN-RGBHV32X32 • 39 Operations Guide – DOC. 6758A...
  • Page 46 Press ENTER to save the IP address. The display will return to the “IP Address” screen. Use the quick-adjust knob to select another Network Setup parameter. The next parameter is Subnet Mask. 40 • 32x32 Matrix Switchers: CEN-RGBHV32X32 Operations Guide – DOC. 6758A...
  • Page 47 Press ENTER to save the default router. The display will return to the “Def. Router” screen. Use the quick-adjust knob to select another Network Setup parameter. The next parameter is DHCP. 32x32 Matrix Switchers: CEN-RGBHV32X32 • 41 Operations Guide – DOC. 6758A...
  • Page 48 Use the buttons below the < and > symbols on the display to navigate to the digit you wish to set. Use the buttons below Del and Ins to delete and/or insert digits. Change a digit by rotating the quick-adjust knob. 42 • 32x32 Matrix Switchers: CEN-RGBHV32X32 Operations Guide – DOC. 6758A...
  • Page 49 Using the quick-adjust knob, you can change to any of the other parameters of the Control Setup menu. When you see the parameter you wish to enter, press the ENTER button. 32x32 Matrix Switchers: CEN-RGBHV32X32 • 43 Operations Guide – DOC. 6758A...
  • Page 50 Press ENTER to save the new setting. The display will return to the “Password” screen. Use the quick-adjust knob to select another Control Setup parameter. The next parameter is Info. 44 • 32x32 Matrix Switchers: CEN-RGBHV32X32 Operations Guide – DOC. 6758A...
  • Page 51 “FLASH” Screen FLASH: << >> Flash “Monitor” Screen Monitor: 64 KB / 64 KB (100%) << >> Flash “Code” Screen Code: 458 KB / 1984 KB (23%) << >> 32x32 Matrix Switchers: CEN-RGBHV32X32 • 45 Operations Guide – DOC. 6758A...
  • Page 52 >> RAM “Initialized Data” Screen Initialized Data: 6 KB / 2153 KB (0%) << >> RAM “Uninitialized Data” Screen Uninitialized Data: 1684 KB / 2153 KB (0%) << >> 46 • 32x32 Matrix Switchers: CEN-RGBHV32X32 Operations Guide – DOC. 6758A...
  • Page 53 >> To view the firmware version and serial number of your CEN-RGBHV32X32V, press MENU to return to the “Info HW/OPS” screen then press the button below OPS. CEN-RGBHV32X32 Firmware and Serial Number Screen CEN-RGBHV8x8 Wide-Band Switcher [v1.000.0006, #FFFFFFFF] << >>...
  • Page 54 Front Panel Screen 2 Front Panel Lock: *Off An asterisk to the left of the front panel lock option will show the current setting. 48 • 32x32 Matrix Switchers: CEN-RGBHV32X32 Operations Guide – DOC. 6758A...
  • Page 55: Routing Signals

    The LED below TAKE will blink on and off. Press the TAKE button to execute the routing you have selected. The TAKE LED will stop blinking when routing changes have been executed. To exit View or Route mode, press the MENU button. 32x32 Matrix Switchers: CEN-RGBHV32X32 • 49 Operations Guide – DOC. 6758A...
  • Page 56: Sync Mode

    To view the sync rates for a different input, press the numbered IN button for the input you wish to view. To exit Sync mode, press the SYNC button or press another button such as VIEW or MENU. 50 • 32x32 Matrix Switchers: CEN-RGBHV32X32 Operations Guide – DOC. 6758A...
  • Page 57: Problem Solving

    Cresnet Hub/Repeater (CNXHUB) to maintain signal quality throughout the network. Also, for networks with lengthy cable runs it may be necessary to add a Hub/Repeater after only 20 devices. 32x32 Matrix Switchers: CEN-RGBHV32X32 • 51 Operations Guide – DOC. 6758A...
  • Page 58: Reference Documents

    Future Updates As Crestron improves functions, adds new features and extends the capabilities of the CEN-RGBHV32X32, additional information may be made available as manual updates. These updates are solely electronic and serve as intermediary supplements prior to the release of a complete technical documentation revision.
  • Page 59: Return And Warranty Policies

    CRESTRON Limited Warranty CRESTRON ELECTRONICS, Inc. warrants its products to be free from manufacturing defects in materials and workmanship under normal use for a period of three (3) years from the date of purchase from CRESTRON, with the following exceptions: disk drives and any other moving or rotating mechanical parts, pan/tilt heads and power supplies are covered for a period of one (1) year;...
  • Page 60 Crestron Electronics, Inc. Operations Guide – DOC. 6758A 15 Volvo Drive Rockleigh, NJ 07647 (2022756) Tel: 888.CRESTRON 04.10 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
