Schletter FIXGRID PRO-100 Assembly Instructions Manual

Hide thumbs

Table of Contents

Quick Links

Download this manual

ROOF SYSTEMS

FIXGRID PRO-100

ASSEMBLY INSTRUCTIONS

Assembly instructions

for east-west orientation

1 General Information �� 2

Tools Needed �� 2

Summary of Contents for Schletter FIXGRID PRO-100

Page 1: Table Of Contents
9 Connecting the floor profile ��13 10 Aligning the floor profile ��13 11 Ballasting �� 14 12 Solar module installation ��18 FIXGRID PRO EAST-WEST | 800440-100EN | V1 | ASSEMBLY INSTRUCTIONS | VERSION: 2023 / 01 | WWW.SCHLETTER-GROUP.COM (18) Subject to modifications...
Page 2: General Information
It is vital to observe accident prevention regulations and use appropriate fall protection equipment� Hazard area! Prior to installation, set up barriers to warn people who are in the vicinity� FIXGRID PRO EAST-WEST | 800440-100EN | V1 | ASSEMBLY INSTRUCTIONS | VERSION: 2023 / 01 | WWW.SCHLETTER-GROUP.COM (18) Subject to modifications...
Page 3: Installation Instructions
Schletter Configurator� Check that the existing roofing has been adequately fixed� Sufficient roof cover must be checked on site� FIXGRID PRO EAST-WEST | 800440-100EN | V1 | ASSEMBLY INSTRUCTIONS | VERSION: 2023 / 01 | WWW.SCHLETTER-GROUP.COM (18) Subject to modifications...
Page 4: Versions
Detail A Version 5° Landscape Maintainance Support spacing Version 10° Landscape Maintainance Support spacing Version 15° Landscape Maintainance Support spacing FIXGRID PRO EAST-WEST | 800440-100EN | V1 | ASSEMBLY INSTRUCTIONS | VERSION: 2023 / 01 | WWW.SCHLETTER-GROUP.COM (18) Subject to modifications...
Page 5 Version 5° Landscape Plus Maintainance Support spacing Version 10° Landscape Plus Maintainance Support spacing Version 15° Landscape Plus Maintainance Support spacing FIXGRID PRO EAST-WEST | 800440-100EN | V1 | ASSEMBLY INSTRUCTIONS | VERSION: 2023 / 01 | WWW.SCHLETTER-GROUP.COM (18) Subject to modifications...
Page 6: Defining Base Profile Lengths And Module Support Distances
The modules are to be clamped flush at the upper and lower module support� LANDSCAPE Maintainance Support spacing Detail A LANDSCAPE PLUS Maintainance Support spacing Detail B FIXGRID PRO EAST-WEST | 800440-100EN | V1 | ASSEMBLY INSTRUCTIONS | VERSION: 2023 / 01 | WWW.SCHLETTER-GROUP.COM (18) Subject to modifications...
Page 7: Inserting The Pro Front Screw-In Module Support
(insert pressed- in screw-in connector into click channel) Pull the screw-in aid sideways off the base profile FIXGRID PRO EAST-WEST | 800440-100EN | V1 | ASSEMBLY INSTRUCTIONS | VERSION: 2023 / 01 | WWW.SCHLETTER-GROUP.COM (18) Subject to modifications...
Page 8: Inserting The Pro Screw-In Heightening Elements
(insert pressed- Pull the screw-in aid sideways off the base profile in screw-in connector into click channel) FIXGRID PRO EAST-WEST | 800440-100EN | V1 | ASSEMBLY INSTRUCTIONS | VERSION: 2023 / 01 | WWW.SCHLETTER-GROUP.COM (18) Subject to modifications...
Page 9: Extending The Pro Heightening Element
The Pro screw-in heightening element can also be used instead of the Pro heightening element� The Pro screw-in module support can also be used instead of the Pro module support� FIXGRID PRO EAST-WEST | 800440-100EN | V1 | ASSEMBLY INSTRUCTIONS | VERSION: 2023 / 01 | WWW.SCHLETTER-GROUP.COM (18)
Page 10: Extending The Pro Module Support
7 EXTENDING THE PRO MODULE SUPPORT Place Pro module support on Pro Click in on long side heightening element at a slight angle FIXGRID PRO EAST-WEST | 800440-100EN | V1 | ASSEMBLY INSTRUCTIONS | VERSION: 2023 / 01 | WWW.SCHLETTER-GROUP.COM (18) Subject to modifications...
Page 11: Mounting The Surface Protection Mat
Press it to the bottom of the base profile at the desired position FIXGRID PRO EAST-WEST | 800440-100EN | V1 | ASSEMBLY INSTRUCTIONS | VERSION: 2023 / 01 | WWW.SCHLETTER-GROUP.COM (18) Subject to modifications...
Page 12 A 10-cm gap between the mats must be maintained to ensure the flow of rainwater� Standard version: Centrally under each support Version with reduced surface pressure: FIXGRID PRO EAST-WEST | 800440-100EN | V1 | ASSEMBLY INSTRUCTIONS | VERSION: 2023 / 01 | WWW.SCHLETTER-GROUP.COM (18) Subject to modifications...
Page 13: Connecting The Floor Profile
Schletter configurator� 10 ALIGNING THE FLOOR PROFILE Position profiles according to dimension g g = [module length] + 23 mm FIXGRID PRO EAST-WEST | 800440-100EN | V1 | ASSEMBLY INSTRUCTIONS | VERSION: 2023 / 01 | WWW.SCHLETTER-GROUP.COM (18) Subject to modifications...
Page 14: Ballasting
Place ballast blocks (e�g� 20 * 10 * 8 cm - l * w * h) lengthwise in floor profile� FIXGRID PRO EAST-WEST | 800440-100EN | V1 | ASSEMBLY INSTRUCTIONS | VERSION: 2023 / 01 | WWW.SCHLETTER-GROUP.COM (18) Subject to modifications...
Page 15 (The ballast blocks are to be moved up to the vertical bar of the ballast profile) Slide in connector ballast profile up to vertical bar of self-locking lug FIXGRID PRO EAST-WEST | 800440-100EN | V1 | ASSEMBLY INSTRUCTIONS | VERSION: 2023 / 01 | WWW.SCHLETTER-GROUP.COM (18) Subject to modifications...
Page 16 Maximum weight on ballast profiles: Floor profile spacing ≤ 2,000mm without support: 150 kg Floor profile spacing > 2,000mm without support: 250 kg FIXGRID PRO EAST-WEST | 800440-100EN | V1 | ASSEMBLY INSTRUCTIONS | VERSION: 2023 / 01 | WWW.SCHLETTER-GROUP.COM (18) Subject to modifications...
Page 17 Slide two clamping wedges between the lowest support of the Pro ballast tray and the floor profile FIXGRID PRO EAST-WEST | 800440-100EN | V1 | ASSEMBLY INSTRUCTIONS | VERSION: 2023 / 01 | WWW.SCHLETTER-GROUP.COM (18) Subject to modifications...
Page 18: Solar Module Installation
Fix the last module of the respective row with 2 end clamps, making sure that the clamp is in contact with the frame FIXGRID PRO EAST-WEST | 800440-100EN | V1 | ASSEMBLY INSTRUCTIONS | VERSION: 2023 / 01 | WWW.SCHLETTER-GROUP.COM (18) Subject to modifications...
