- Page 1 RRAS-MC/A1 IP microphone for rolling stock Operation manual Version 1.01 rras-mca1_g_en_101...
- Page 2 RRAS-MC/A1 AMiT, spol. s r.o. does not provide any warranty concerning the contents of this publication and reserves the right to change the documentation without any obligation to inform about it. This document can be copied and redistributed under following conditions: 1.
-
Page 3: Table Of Contents
RRAS-MC/A1 Contents History of revisions ..................4 Related documentation ................... 4 Introduction ..................5 Technical parameters ................6 2.1. Dimensions ..................... 8 2.2. Design of front panel ..................9 2.3. Recommended drawing symbol ..............9 Conformity assessment ..............10 3.1. -
Page 4: History Of Revisions
RRAS-MC/A1 History of revisions Document name: rras-mca1_g_en_101.pdf Author: Jaroslav Šach Revision Date Changes 13. 6. 2013 New document 2. 6. 2014 Dangerous materials added Related documentation ACASYS-AS Programming manual file: acasys-as_ms_en_xxx.pdf ACASYS-AS Projection manual file: acasys-as_mp_en_xxx.pdf Application Note AP0037 – Principles of using Ethernet network file: ap0016_en_xx.pdf... -
Page 5: Introduction
RRAS-MC/A1 1. Introduction RRAS-MC/A1 is a noise-reducing microphone with Ethernet interface, intended for mounting into passenger areas. Device is supplied from factory only with loader. Before first use must be loaded an user application into device. Ethernet 100 Mbps interface Basic features ... -
Page 6: Technical Parameters
RRAS-MC/A1 2. Technical parameters Processor STM32F207 Internal FLASH memory 512 KB Internal RAM 128 KB EEPROM 2 KB Microphone Type Electret condenser Frequency range 50 Hz to 16 kHz Ethernet Number of lines Data transmission rate 10 / 100 Mbps... - Page 7 RRAS-MC/A1 Others Maximum ambient humidity < 95 % non-condensing Expected MTBF > 250 000 h Expected lifetime 15 years Components with reduced lifetime Software Device is supplied with loader, which enables software downloading by application RRAS Configurator via Ethernet line.
-
Page 8: Dimensions
RRAS-MC/A1 2.1. Dimensions Fig. 1 - RRAS-MC/A1 dimensions rras-mca1_g_en_101 8/18... -
Page 9: Design Of Front Panel
RRAS-MC/A1 2.2. Design of front panel RAL 9005 RAL 9006 Fig. 2 - Panel colour design 2.3. Recommended drawing symbol Following drawing symbol is recommended for RRAS-MC/A1 microphone. RJ45 Fig. 3 - Recommended drawing symbol for RRAS-MC/A1 9/18 rras-mca1_g_en_101... -
Page 10: Conformity Assessment
RRAS-MC/A1 3. Conformity assessment The equipment meets the claims of Czech government decree NV616/2006; the conformity assessment has been performed in accordance with harmonized standard EN 50121-3-2:2006. Tested in accordance Type of test Classification with standard EN 55011:2009 Industrial, scientific and medical Complies equipment –... -
Page 11: Other Tests
RRAS-MC/A1 Electromagnetic compatibility (EMC) – EN 61000-4-11:2004 Complies Part 4-11: Testing and measurement techniques – Voltage dips, short interruptions and voltage variations immunity tests *) Some disturbing noise can be heard in the speaker when disturbances appear. 3.1. Other tests... -
Page 12: Front Panel
4.2. ALS indication LED Behind perforation of front panel are concealed the LED indicators, which allows the user an identification of device which communicates at given moment. Diodes blinks red, when the RRAS-MC/A1 unit recognizes its IP address within the Ethernet frame. rras-mca1_g_en_101... -
Page 13: Ethernet
RRAS-MC/A1 5. Ethernet Connector RJ45 for connecting the Ethernet interface is positioned on the cover rear side. Closer information about Ethernet factory settings can be found in chapter 6.1 Factory settings. Ethernet Fig. 5 - Location of Ethernet connector 13/18... -
Page 14: Configuration
RRAS-MC/A1 6. Configuration All microphone parameters are configured through Ethernet interface. 6.1. Factory setting The microphone set is fitted with „RESTORE“ button to get into factory setting. This button is accessible at the cover upper side. To push the button use a tool (stick) with maximum diameter 1.5 mm. -
Page 15: Mounting
RRAS-MC/A1 7. Mounting Microphone RRAS-MC/A1 is designed to mount into vehicle wall. Use M4 bolts with cylindrical head for fastening. Microphone can be mounted in any position. 54,0 61,0 Fig. 7 - Mounting aperture and holes for RRAS-MC/A1 7.1. Installation rules Earthing Connect the terminal PE on the microphone rear cover with vehicle frame. -
Page 16: Ordering Information And Completion
RRAS-MC/A1 8. Ordering information and completion IP microphone RRAS-MC/A1 IP microphone, Routine testing protocol, Insulation testing protocol, Warranty certificate, Operation manual rras-mca1_g_en_101 16/18... -
Page 17: Maintenance
RRAS-MC/A1 9. Maintenance Device requires no periodic control nor maintenance. Cleaning Time after time with regard to way of device usage, it is necessary to remove dust from inside electronics. The equipment can be cleaned by dry soft brush or vacuum cleaner, only when turned-off and disassembled. -
Page 18: Waste Disposal
RRAS-MC/A1 10. Waste disposal Electronics The disposal of electronic equipment is subject to the regulations on handling disposal electrical waste. The equipment must not be disposed off in common public waste. It must be delivered to places specified for that purpose and recycled.
