Summary of Contents for ASSALUB BSP
- Page 1 I2107-E-20.11 INSTRUCTION MANUAL ÅSSA LUBRICATORS TYPE B ASSALUB AB, Prästängsvägen 15, Box 240, SE-597 26 ÅTVIDABERG, SWEDEN Tel. +46-(0)120-358 40, E-mail: info@assalub.se, URL: www.assalub.se...
- Page 2 Thank you for choosing an Assalub lubricator. It is a high-quality Swedish product. Every lubricator is subjected to comprehensive testing before delivery. Read the instruction manual carefully to ensure correct use of the lubricator. Original instructions...
-
Page 3: Table Of Contents
CONTENTS 1. Presentation 2. Safety regulations 3. Technical description 4. Assembly and installation 5. Initial start-up, setting discharge rate 6. Maintenance and repair 7. Spare parts 8. Guarantees 9. CE certification... -
Page 4: Presentation
1. PRESENTATION • The ÅSSA Type B lubricator is intended for automatic oil lubrication of machinery and also for dispensing lubricants. • When an electrically driven lubricator (Model BSM) is to be used in an explosive environment an electric motor of the correct type and safety class must be used. 2. -
Page 5: Technical Description
3. TECHNICAL DESCRIPTION GENERAL The lubricator consists of a reservoir with lid, which contains the pump mechanism and pump body. A mechanical or electric drive unit is mounted on one end of the reservoir. A hand crank or a feed pump may be mounted on the other end. -
Page 6: Assembly And Installation
4. ASSEMBLY INSTALLATION • Make sure when unpacking that no items are missing from the delivery. • Before assembling, make sure that all pipes and hoses are clean inside. • The lubricator must be installed on a level surface. Use shims to eliminate any unevenness. This important in order to avoid stresses that might give rise to cracks in the reservoir. -
Page 7: Maintenance And Repair
6.MAINTENANCE AND REPAIR PREVENTIVE MAINTENANCE Make regular checks of: • Oil level in lubricator reservoir; it must not run dry. In the ratchet driven version the ratchet mechanism is filled with highly stable grease during manufacture. We rec- ommend the careful introduction of multi-purpose NLGI-2 EP grease with a grease gun through the drive ratchet housing grease nipple every 8000 hours. -
Page 8: Spare Parts
7. SPARE PARTS Lubricator type B When ordering spare parts always state lubricator type and serial number as on the name-plate Art.No. Designation Art.No. Designation A 209 note Ratchet lever B 2238-1 note Packing A 209-4 Ratchet arm B 2239-X Suction pipe B1-BS Pump body... - Page 10 Drive units type BSRE, BSRD and K (hand crank) DRIVE SHAFTS AND GEARS Direction of Drive side / Drive shaft position Utväxling rotation Drivshaft Gear 45:1 F 1221 B 1107/1 Right hand / I IV V Clockwise 22.5:1 F 1222 B 1107A Left hand / II III VI 4.6:1...
- Page 12 Connecting of two lubricators, BSM gear Connecting two lubricators Art. No. Designation Art. No. Designation B 108-7 Bearing, left-hand B 1011-3 Gear, ratio 1:1 + 1:1,75 1:1,75 + 1:1 B 109-7 Bearing, right-hand B 1013 Screw B 1009A Bearing housing, blind 900 559 Packing B 1009-3...
-
Page 14: Guarantees
ADDRESS: DATE: ASSALUB AB guarantees new lubricators for 24 months from the day on which they are taken into service, but for not more than 36 months after delivery from our factory The guarantee covers only defects that manifest themselves during correct use of the equipment and excludes defects caused by external damage, incorrect assembly, lack of maintenance or any other cause not related to material or defects in manufac- ture. - Page 15 EU DECLARATION OF CONFORMITY We, Assalub AB, Prästängsvägen 15, SE-597 30 Åtvidaberg, Sweden, declare that the: OIL PUMP Type BSP and BSM is designed and manufactured in accordance with EUROPEAN MACHINE DIRECTIVE 2006/42/EG Åtvidaberg, December 11, 2009 Kim Funck Niklas Rehn...
