BeNext Energy Switch EU Quick Start Manual

Technical specifications
Normal operating voltage
Recommended max. load
Frequency range
Wireless range
Energy measurement
Basic operations
- The Energy Switch can be remotely controlled.
The Energy Switch can be controlled by the push button on the front of the device.
-
The Energy Switch's indicator light can indicate the status of the switch (ON or OFF).
-
- The Energy Switch can measure the power that is consumed through the socket.
- The Energy Switch is a Routing device to make a stronger and wider Z-Wave mesh network.
How it operates
Control and monitor your lightning or any other appliance.
During operation mode it will measure the instance and accumulated energy consumption of the applied
appliance.
Easy plug and play.
Mounting
1. Place the Energy Switch into an outlet socket.
2. Plug any appliance into the socket of the Energy Switch to control and measure the energy
consumption from.
Include or exclude in Z-Wave network
1. Press and hold the push button until the indicator light is blinking than release the button to start the
inclusion or exclusion process.
2. When classic inclusion failed the product will start Network Wide Inclusion automatically
Manual control
Press and release the push button of the Energy Switch to switch on/off the socket of the Energy Switch.
Manual control by the Push Button can be protected by a configuration parameter.
-
Led indicator can be inverted by a configuration parameter.
-
Remote control
The Energy Switch can be remote controlled by several Z-Wave devices.
1
Make sure your Z-Wave controller is in the correct operation mode (include or exclude).
Version 0.7
Quick start: Energy Switch EU
230Vac/50Hz
3000W 600W
868.42 MHz
30~100 meters in line of sight
3 - 4500W (5%) and kWh
1
1 August 2017
Indicator light
Push button
AC Power
plug
