COMPRESSOR OPERATION

Caution:

Run

compressor only for 10 minutes at a time continuously, then leave off for

10 minutes before using again so that the compressor can cool.

Switch the compressor power switch on. You should hear the compressor start.

For tyre inflation use the universal adapter that is attached permanently to the air

hose. Place this adapter (refer Figure 2, No. C) onto the tyre valve

stem, press the adapter lever down to lock onto the valve system.

For inflation of leather balls, flotation devices, etc, use one of the

plastic nozzles.

Check pressure gauge (refer Figure 2, No. A), to determine the de-

sired pressure. This is only an indicator, for exact inflation pressure use a quality pres-

sure gauge.

Turn on power switch (refer Figure 2, No. B).

When the desired pressure is reached turn the compressor switch off (refer Figure 2,

No. B).

Remove the adapter (refer Figure 2, No. C) from the tyre or other item being inflated.

The lead acid battery contained in the powerstation should be recycled once it has expired.

Please contact your local government for recycling information.

Warning: Do NOT dispose of the battery in an open flame as this may result in an explosion

and toxic fumes.

Warning: Before disposing of the battery, protect exposed terminals with heavy-duty elec-

trical tape to prevent shorting (shorting can result in injury or fire). Do NOT expose battery

to fire or intense heat as it may explode.

This appliance needs to be disposed of in an environmentally friendly way when it be-

comes of no further use or has worn out. Contact your local government for details of

where to take the item for re-cycling.

This

product has no user serviceable parts.
