List of parts
1
2
3
4
5
6
7
1.
M4 screw 12x
2.
TX10 wrench 1x
3.
Shelf left sheet metal panel 1x
4.
Shelf right sheet metal panel 1x
5.
Shelf front wooden panel 1x
6.
Shelf rear wooden panel 1x
Shelf bottom sheet metal panel 1x
7.
Assembly instructions
Step 1. Connect bottom metal panel to the front and rear wooden panels.
Fasten panels with M4 screws (6x) and TX10 wrench.
7
1
2
5
6
Step 2. Connect left and right metal sheet panels to the shelf.
Fasten panels with M4 screws (6x) and TX10 wrench.
1
2
3
4
Step 3. Place the shelf on top of the Click and Grow 25 farm, make
sure the shelfs legs go into their corresponding sockets. Maximum load
the shelf can hold is 5 kg /11 lb.
