Sunset Trading DLU-BR-B20-RTA Assembly Instruction

701 E Industrial Pk Dr
Manchester, NH 03109
sunsettrading.com
Please Contact us if you are
Missing Parts or have any Questions
877-364-8464
info@sunsettrading.com
d
e
a
f
f
Step 2 01
02
06
04
Thank you for purchasing this quality product!
It has been engineered for easy assembly yet
constructed for durability.
Please take the time to read and follow
the instructions while assembling.
Step 1
d
e
c
02
f
06
05
03
ASSEMBLY INSTRUCTIONS
01
02
d
e
b
1 OF 2
SKU: DLU-BR-B20-RTA
List of Parts For 1 Set
Figure
Code Part
01 Chair Back
02
Seat Frame
Front Leg (R)
03
04
Front Leg (L)
Front Stretcher
05
06
Side Stretcher
List of Hardware For 1 Set
Code Figure Hardware
Hex. Bolt
a
M6 x 80mm
Hex. Bolt
b
M6 x 60mm
Hex. Bolt
c
M6 x 40mm
Flat Washer
d
1/4 " x 18mm
Spring Washer
e
1/4 "
Spanner
f
10mm
PHRS Screw
g
#8 x 1 1/4"
IMPORTANT NOTES:
• Keep all hardware and small
parts out of reach of children.
• Remove all staples and
packing straps before you start
to assemble.
• Do not discard main cartons
and wrapping material until
assembly is complete.
• Check to be sure you have all
parts and hardware.
• Place all wooden parts on a
clean soft surface to avoid
parts from being scratched
• Do not tighten all screws / bolts
until completely assembled.
• Check tightness 3x's/year, with
use screws can become loose.
• Do not attempt to repair or
modify parts that are broken or
defective. Please contact us
immediately.
• Enjoy your new furniture!
MADE IN MALAYSIA
Qty.
1
1
1
1
1
2
Qty.
4
4
2
10
10
1
6
