Page 2
Assembly instructions Chapter first editing 1) In photo n ° 1 we can see the RF box and its housing. Mount the 50cm pipe through the insulator to the 100cm pipe, Insert the 6x60 bolts in the two most distant holes. Then insert the RF box into the two closest holes. It is recommended to use two 10 mm wrenches, with one, hold the nut behind the box and with the second tighten the nut to the aluminum barrel.
Page 3
1) 1) The second stage of assembly is to connect the 50mm x 100cm pipe via the insulator to the 50mm x 150cm pipe. To do this, just match the holes in the insulator with the holes in the aluminum barrel. 2) Attention on the insulator there is a groove to let the water flow, it must be mounted in the upper part of the pipe towards the 50mmx 150 cm.
Page 6
4) 4) At this point we can mount the telescopic part of the antenna, respecting the drilling to size of the antenna as photo PHOTO 4/5/6 FOTO 4 FOTO 5...
Page 7
FOTO 6 Third step for assembling the resonant element 15m 5) Mount the 35mm diameter aluminum collar with the aluminum spacer and the steel wire in the upper part of the 35mm x 150 pipe immediately above the clamping bolt of the 35mm pipe with the 30mm one, check the diagram s N ° 1 . The measurement of 679 cm from the second uppermost insulator is only indicative and may vary by a few cm without compromising operation.
Page 10
Fourth phase assembly of the last element 30mm x 120 The final element has 3 holes to adjust the resonance of the antenna in 20 and 10 m. The central hole is the one that is the best in most cases. Final phase elevation and calibration Now we can raise the antenna by remembering to put at least 3 tie rods about the middle of the antenna.
Page 11
Fifth phase of antenna calibration 1) 1) Start moving the lowest coil, that of 80 meters, up or down along the tube until it reaches the desired frequency 2) Example: if the antenna resonates at 3700 and you want to go up to 3750, the coil must be moved downwards;...
Page 12
The last calibration to be performed must be done using a coil to be fixed to the two bolts next to the antenna connector on the RF box. Wrap 8 to 16 coils of 1.5mm electric cable tightly and tightly together on a plastic support with a diameter of 40mm.
Page 14
The last calibration to be performed must be done using a coil to be fixed to the two bolts next to the antenna connector on the RF box. Wrap 8 to 16 coils of 1.5mm electric cable tightly and tightly together on a plastic support with a diameter of 40mm.
