Summary of Contents for Hi-Line ConSEP100
- Page 1 ConSEP 100-1500 Instruction and Maintenance Manual OIL / WATER SEPARATOR ConSEP100-1500 1/15...
- Page 2 2/15...
- Page 3 INDEX GENERAL INFORMATION TECHNICAL DESCRIPTION INSTALLATION Acceptance and transport Installation site Activation of ConSEP100 , ConSEP300 , ConSEP750 and repalcemente filter kit Activation of ConSEP1500 and replacemente filter kit Condensate drain OPERATION MAINTENANCE, DISMANTLING AND SPARE PARTS Maintenance Dismantling exhausted bags and separator...
-
Page 4: General Information
1 GENERAL INFORMATION Symbols applied on the manual Mandatory consulting the manual Environmental requirements Attention Recyclable materials This manual has been written to allow staff use oil / water separator in a safety and affactive way. therefore any installation, use and maintenance operations must be performed respecting the instructions contained in this manual. -
Page 5: Acceptance And Transportation
3 INSTALLATION 3.1 ACCEPTANCE AND TRANSPORTATION At the moment the customer accepts the delivery, he must fully inspect the dryer to verify its integrity and the presence of all the items listed in the shipping documentation. Eventual claims for missing and/or damaged parts must be addressed directly to our facility or to the closest reseller, within 8 (eight) days from the date on which the goods have been received. - Page 6 3. Place foam (FM), as shown in photo, in the lid (LD) (activity #1); place activated carbon layer (CAF) above the foam. 4. Models ConSep100 and ConSEP300 are provided by a carbon bag (CF) and a white pre-filter bag (PF). Model Con SEP750 is provided by 2 carbon bags (CF) and a white pre-filter bag (PF). First place activated the carbon bag or the carbon bags (CF) in separator body (BD) (activity #2), then white pre-filter bag (PF), (activity #3).
- Page 7 ConSEP 100-300 ConSEP 750 5. Establish inlet connection (I1 or I2) by which connect separator to plant and then fit T joint. 6. Insert lid (LD) as shown in following image. 7/15...
- Page 8 7. Insert connector for outlet (OT); then fit drain tube to connector. 8. Insert dedicated screw to close connection test. 3.4 ACTIVATION OF ConSEP 1500 AND REPLACEMENT FILTER KIT Perform the following steps to correct installation. ConSEP 1500 1. If present, remove only the plastic bag of activated carbon (CF) of both separator. 2.
- Page 9 4. Assemble separator as shown on image. 5. Place a carbon bag (CF) in first separator body (activity #2) and both pre-filter bags (PF) in first separator body (activity #3) 9/15...
- Page 10 6. Place 3 activated carbon bags (CF) in second separator body (activity #4) 7. Fit Tee joint to first separator 8. Insert lid (LD) on both separator 10/15...
- Page 11 9. Insert connector for outlet (OT); then fit drain tube to connector. 10. Insert dedicated screw to close connection test. 11/15...
- Page 12 It is recommended to check drain water quality at least once every 6 months. Replace filter bags at least once every 12 months; replacement of filter bag must be in compliance instruction 4 of paragraph 3.3 for separator ConSEP100 - ConSEP750 , and in coompliance instructions 5 and 6 for separator ConSEP1500 .
- Page 13 LIST OF ATT A CHEMENTS 13/15...
- Page 14 A. DIMENSIONS SEPARATORS TECHNICAL FEATURES SEPARATORS ConSEP100-750 Connections Standard flow rate Weight MODEL I1, I2, I3 e OT l/min inch BSP 1/2” ConSEP100 2833 BSP 1/2” ConSEP300 8500 BSP 3/4” ConSEP750 1275 21250 10,8 Maximum air flow Maximum Screw compressor...
- Page 15 ConSEP1500 Connections Standard flow rate Weight MODEL I1, I2, I3 e OT l/min inch ConSEP1500 2550 42500 1500 1150 21,8 BSP 3/4” Maximum air flow Maximum Screw compressor Piston compressor ambient Mineral oil Synt hetic oil Mineral oil Syn the tic oil temperature ESTER ESTER...
