Summary of Contents for ZIMX BK2
- Page 1 HOVER BIKE H O V E R B O A R D S A T T A C H M E N T W I T H A T T I T U D E UKBIGBUY M O V E M E N T .com W I T H A T T I T U D E...
- Page 2 HOVER BIKE H O V E R B O A R D S A T T A C H M E N T W I T H A T T I T U D E Operational Manual : BK2...
- Page 4 Section Two of this manual gives assembly and installation instructions for your ZIMX BK2 Hover Bike. Section Three of this manual covers specic safety and operating instructions for your ZIMX BK2 Hover Bike. Even if you are an experienced rider, you should review this section before your rst ride.
-
Page 5: Specifications
ZIMX BK2 HOVER BIKE DIAGRAM 1. Seat 2. Handle Bars 3. Shock Absorbing Spring 4. Pedal Mounts 5. Hook and Loop Straps 6. Seat Frame 7. Adjustment knob 8. Frame Extension 9. Wheels 10. Seat Pole 11. Foot Rest SPECIFICATIONS Compatibility: Most self-balancing electric scooters upto 10”... - Page 6 MEASUREMENTS 55cm 63cm 53cm 15cm 22cm 54cm...
-
Page 7: Parts List
PARTS LIST (1) Seat (1) Handlebar (1) Seat pole (1) Pedal Mount Frame (1) Seat Frame (1) Frame Extension (1) Extension Tube (1) Wheels Bar (1) Foot Rest (1) Handlebar Rod NOTE - Some of the parts have been added to the product to reduce the steps required for assembly and reduce installation time. -
Page 8: Accessories List
ACCESSORIES LIST (1) Long Neck Plastic (1) Allen key / Wrench Tube Set, 3 items (1) Short Neck Plastic Tube (1) Wrench / Spanner Set, 2 items (2) Bolt Screw M10 (2) Locking Nuts M10 (2) Wheel Frame Screws (2) Large Washer (4) Rubber Pedal Mount Ends (1) Small Washer... - Page 9 ASSEMBLING YOUR ZIMX BK2 HOVER BIKE Next connect the seat frame to the frame extension and tighten Connect the seat frame to the wheels bar and with spanner and allen key, then using the wheel frame screws tighten together insert the adjustment knob.
- Page 10 ASSEMBLING YOUR ZIMX BK2 HOVER BIKE Loose and remove the handlebar clamp at the top of the handlebar rod, using Insert the the allen key. Then insert the pedal mount handlebar, replace clap and frame tube tighten securely with allen key.
- Page 11 ASSEMBLING YOUR ZIMX BK2 HOVER BIKE Then insert the Add the seat Securely seat pole into tighten the onto the seat the seat seat pole, using pole and tighten Tighten frame. the pre-installed the seat clamp nut + bolt locking clamp.
- Page 12 Someone will be in touch to guide you through these steps. Carefully follow the steps shown on the following pages for installing the ZIMX BK2 Hover Bike onto your electric scooter. Read the remainder of this manual before riding your ZIMX BK2 Hover Bike.
- Page 13 Slide on all the protective rubber pedal mount covers on each end of the pedal mounts. Then using the hook and loop straps, place the hook and loop side of strap downward and then pull each strap end through the holes on back of each pedal mount. Rubber Pedal Mounts Ends...
- Page 14 WARNING: Do not over tighten straps when you are assembling your ZIMX BK2 Hover Bike to your scooter. Ensure that the ZIMX BK2 Hover Bike is secure to the scooter when attaching. Your ZIMX BK2 Hover Bike should be properly installed onto your scooter as shown below.
-
Page 15: Before Riding
It is important that you fully understand all elements of your ZIMX BK2 Hover Bike . If these elements are not used correctly, you will not have full control of your ZIMX BK2 Hover Bike . Before you ride fast, or outside of a controlled environment, learn the functions of the various mechanisms on your ZIMX BK2 Hover Bike . - Page 16 PRE-RIDE ZIMX BK2 HOVER BIKE CHECKLIST Ensure that your ZIMX BK2 Hover Bike and scooter are in proper working order each and every time you ride. If a part of the ZIMX BK2 Hover Bike does not function correctly, please contact our Customer Support Center.
-
Page 17: Safety Precautions
SAFETY PRECAUTIONS The 1st rule in safe riding is to use common sense. A ZIMX BK2 Hover Bike is vulnerable; it cannot protect you in a crash, against impact, or loss of control the way driving a car can. A ZIMX BK2 Hover Bike can tip over sideways so be vert careful. - Page 18 Brakes do not work as well under wet conditions as they do when dry. It is recommended that you do not ride your ZIMX BK2 Hover Bike in wet weather, as there are electronic components in your scooter that may be damaged...
- Page 19 2. Due to the particularity of the product, the assembly pieces are to be checked before every ride to avoid an accident while riding. 3. Do not make a sharp turns as you may drift and overturn the ZIMX BK2 Hover Bike which can result in injury to yourself and/or damage the unit.
- Page 20 RIDING YOUR ZIMX BK2 HOVER BIKE Ensure your ZIMX BK2 Hover Bike is fully assembled and correctly installed onto your scooter with all straps and bolts / screws and nuts secured in place. Ensure your scooter is properly maintained as well. Failure to do so may result in serious bodily harm or death and damage to the unit.
-
Page 21: Warranty / Customer Service
Printed in China for UKBIGBUY.COM Copyright 2010-2022 UKBIGBUY.COM All rights reserved. ZIMX, the ZIMX logo design, and X logo design are among the registered trademarks of NEW AGE GROUP in the United Kingdom and / or select foreign countries. UK_220315BR... - Page 22 H O V E R B O A R D S W I T H A T T I T U D E www.ukbigbuy.com @ukbigbuy @ukbigbuy @ukbigbuy www.zimx.uk UKBIGBUY .com Saving you money every day...
