- Page 1 MV55G User Manual V1.0 Learn how to set up your new Autopmall Tracker Copy right ©2022 A ut opmall | All Rights Reserved...
-
Page 2: Main Features
Engine Start/ Vibration Movement Geo-fence Alarm Flame-out Alarm Alarm Alarm 2.Specifications Model MV55G Weight Device Information Dimensions 59mm(L) * 45mm(W) * 22mm(H) Battery Working Time Tracking Mode：1-2 hours Working Voltage DC 9V - 50V Battery Capacity 3.7V 140mAh Lion Polymer battery... -
Page 3: Activate Device
Positioning Type GPS+BEIDOU+LBS GPS Antenna Built-in ≤32 Seconds Cold Start ≤1 Second Hot Start GNSS Specifications Tracking sensitivity -162 dBm GPS Channels Position Accuracy 5-10m 3. Activate Device Install the SIM card via the correct direction as below: State Event Charging Solid POWER LED (RED) -
Page 4: Package Content
5. Functions Explanation Please follow with the quick user guide carefully! For example: a. Vibration Alert： This vibration alert function just work under MV55G stationary status.How to use this function: SOS,A, 12345678910# * First Step: Configure SOS numbers for SET SO S NUMB E R O K the tracker by this sms command：... - Page 5 SMS, call and tracking platform. For example: * First Step: Configure SOS numbers for MV55G the tracker by this sms command： SOS,A,1st number, 2nd number,3rd number# SOS,A, 12345678910# 3 SOS numbers supports at the most.
-
Page 6: Installation Recommendation
6. Installation Recommendation Where is the OBD interface? Most of the car‘s OBD interface is located in A and B, A small part of the car will be in C,D and E. VW、Ford、 Toyota 、Hyundai 、Citroen、BMW、 Area A etc./Most cars. Area B Honda,Lexus,etc. -
Page 7: Troubleshooting
7. Troubleshooting Type Check the APN and settings. Unable to connect to Check whether the data service of SIM card is enabled. tracking platform Check the balance of SIM card. Check whether external power is still connected. Check if the vehicle entered network blind area. Tracker shows offline Check the balance of SIM card. - Page 8 Functions Command Format Explanation Version Inquiry VERSION# Parameter Inquiry PARAM# BATTERY: XX% (Built-in Battery Power Percent) INTERNET: CLOSED (No Network) FAILED (Conn- ecting Network or Failure) SUCCESS (Connected to Network） NET: NONE (No GSM Signal),HIGH / MED / LOW (Signal Strength) GPS: CLOSED (GPS Module Closed) , FIXED, N (Positioned and satellite number), UNFIX, 0 (Not Positioned yet)
- Page 9 Functions Command Format Explanation Delete Center Number CENTER,D# Set 3 numbers at a time: SOS,A,13800138000,1380013800 1,13800138002# Set the first numberseparately: Add SOS Administ- SOS,A,13800138000# SOS,A,1st number, rator Number 2nd number,3rd number# Set the second number separately: SOS,A,,13800138001# Means to set 3rd number separately: SOS,A,,,13800138002# Directly delete the number: SOS,D,13800138000#...
-
Page 10: Any Questions
2 : GPRS+SMS+phone call, default：2； Alarm PWRALM,OFF# Close power disconnect alarm 9. Any Questions? E-mail: support@autopmall.co m autopmall Skype: 10. Download the APP Search "MiCODUS" in iOS APP store or Google Play Store, or just scan the QR code as below to download...
