Summary of Contents for WAPRO WAGATE MTV
- Page 1 ® WAGATE SLUICE GATES ® INSTALLATION MAINTENANCE & PRODUCT GUARANTEE PLEASE NOTE SERIAL/ORDERNUMBER HERE:...
-
Page 2: Table Of Contents
THANK YOU FOR PURCHASING A WAPRO PRODUCT. FOR FURTHER PRODUCT INFORMATION PLEASE REFER TO WAPRO.COM INDEX OPERATION INSTRUCTIONS ..........................3 TRANSPORT AND STORAGE .........................3-5 MOUNTING ...................................5-7 COMMISSIONING ................................ 8 GERERAL OPERATION ............................9-10 MAINTENANCE ................................11 WARRANTY ..................................11... -
Page 3: Operation Instructions
OPERATION INSTRUCTIONS WAGATE SLUICE GATES – MTV, SPS-TL, SPS-TG, SPK-TG, SPM-P-TG, SPM-S-TG SAFETY INSTRUCTIONS This manual should be read and properly understood before product commissioning. All personnel working with the device must be familiar with the safety and warning instructions in this document. STANDARDS/DIRECTIVES Our products are designed and manufactured in compliance to recognized standards and directives. - Page 4 The following table shows the applicable uses of each sluice gate type, as well as which types of operation is available. If a sluice gate is used outside its intended application, proper function can´t be ensured, contact Wapro for advice.
-
Page 5: Mounting
MOUNTING Make sure to bolt through all mounting holes MOUNTING SURFACE DIRECTION Before mounting of the sluice gate, make sure that the mounting surface is flat and smooth (max. +/-3mm/m) MOUNTING SURFACE GASKET All sluice gates are supplied with a mounting gasket for sealing against the mounting surface. Make sure that this gasket is correctly mounted and has not been damaged during transport. - Page 6 The MTV and SPS-TL models can be mounted using dowels. All other models of sluice gates must be mounted using either wall anchors or chemical anchors. Hardware size can be found on the model specific datasheets. Wapro can supply complete mounting kits for all sluice gate models.
- Page 7 OPERATING DEVICES All Wapro sluice gates are available with a diverse range of operating devices. Both for direct mounting on the sluice gate as well as to extend the operation of the sluice gate. Lengths are made to order. Note that as standard the sluice gate comes without any operating device.
-
Page 8: Commissioning
COMMISSIONING These steps must be followed closely before first use. MECHANICAL SETUP After mounting is completed, slowly move the sluice gate from open to closed. Make sure that there is no sudden resistance to the movement which would indicate a problem. To prolong the life of the sluice gate, apply a water- resistant grease to the spindle when commissioning. -
Page 9: Gereral Operation
GENERAL OPERATION MTV & SPS-TL To close the gate push gently on the gate handle until a natural resistance is met. The gate opening is fully closed slightly before reaching the end of the gates travel. Pressing hard on the handle will not improve gate performance and can lead to permanent damage. - Page 10 To commission the sluice gate either follow the commissioning steps in the AUMA specific manual supplied with the actuator or get the local branch of AUMA to carry out the commissioning. Contact Wapro for further advice. LOCAL ELECTRIC OPERATION To operate the sluice gate, the selector switch [5] is moved into the “Local”...
-
Page 11: Maintenance
WAPRO A/S WARRANTY Wapro will remedy defects in material and/or workmanship in any new Wapro valve for a period of two (2) years from the documented date of purchase so long as the valve has been used in accordance with Wapros instructions and recommendations and under normal operating conditions. - Page 12 CONTACT WAPRO customerservice@wapro.com wapro.com SE: +46 (0)454 185 10 DK: +45 64 82 40 00 US: +1 888 927 8677 UK: +44 114 308 0123...
