Air curtain: Recessed Optima

INSTALLATION, OPERATION AND MAINTENANCE MANUAL

Please, read these instructions carefully before attempting installation

Deliver this manual to the final user.

Attention, Danger, Safety Advice!

Injuries risk!

Important information.

SECURITY ADVISE SYMBOLS

Danger from electric current or high voltage!

Danger! Do not stay underneath: Heavy load.

Table of Contents

Need help?

Do you have a question about the RECESSED OPTIMA RO 1000 A and is the answer not in the manual?

Questions and answers

Summary of Contents for Airtecnic RECESSED OPTIMA RO 1000 A

Page 1 Air curtain: Recessed Optima INSTALLATION, OPERATION AND MAINTENANCE MANUAL Please, read these instructions carefully before attempting installation Deliver this manual to the final user. SECURITY ADVISE SYMBOLS Danger from electric current or high voltage! Attention, Danger, Safety Advice! Injuries risk! Danger! Do not stay underneath: Heavy load.
Page 2 Instruction manual - Air curtain Recessed Optima...
Page 3: Table Of Contents
INDEX INSTALATION �� 4 TRANSPORTATION AND STORAGE �� 10 OPERATING INSTRUCTIONS �� 10 ELECTRICAL SQUEMES �� 14 DATA SHEET �� 25 MAINTENANCE INSTRUCTIONS �� 26 REPAIRS AND REPLACEMENTS �� 30 TROUBLESHOOTING �� 35 ACCESSORIES�� 36 DECLARATION OF CONFORMITY �� 37 IDENTIFICATOR ��...
Page 4: Instalation
INSTALATION Tips and recomendations for a good installation LENGTH CENTERED/ HEIGHT (*) Unless it has been de- signed to be installed at that height. DOOR DISTANCE Instruction manual - Air curtain Recessed Optima...
Page 5 AIR DISCHARGE AIR ASPIRATION MAINTENANCE ACCESSIBILITY CONTROL (CLEVER) Instruction manual - Air curtain Recessed Optima...
Page 6 Recessed Optima model Installation work, connection, disconnection, electrical wiring, mechanical maintenance and service must be done by qualifi ed people observing these instructions and in accordance with all applicable norms and standards. If the unit is operated with additional controller, please consider its specifi c instructions.
Page 7 Connexion diagram Standard without heating, with water and electric heating 400V x 3 and 230 Vx1 Instruction manual - Air curtain Recessed Optima...
Page 8 Power supply For feeding the device the connection should be done at the lateral exterior part of the air curtain: Water coil and Electrical coil models non heated models Water coil models: For curtains without heating or with water heating, only the curtain must be connected to single-phase current at 230V for the operation of the fans directly to the PCB�...
Page 9 Water coils The air curtains with water coil have a 230Vx1 output to optionally connect a solenoid valve (it opens or clo- ses the water inlet to the heat exchanger of the coil)� This outlet can also be used for other low amperage electrical appliances (10A)�...
Page 10: Transportation And Storage
TRANSPORTATION AND STORAGE Warning! Heavy load. Do not stand under the suspended load during transportation or assembly. Store in a dry place protected from the environment� If the package is opened, cover the curtain to protect it from the dust� Do not step on or place heavy loads on it to avoid damage to the material� Storage temperature between -20 ⁰C and +40 ⁰C.
Page 11 - RJ45 cable and digital communication: they have a fast connection with a telephone type cable and digital communication between the regulator and the curtain� This type of communication is reliable even over long distances (up to 20 meters)� - External start-stop: inside the regulator there is the possibility of connecting a normally open contact (1,2) that governs the on/off of the equipment through any external device.
Page 12 It also prevents the air expelled by the curtain from exceeding 60ºC (sensing temperature)� excessive for people)� Characteristics common to all controllers for electric battery System with 2 ventilation speeds and 2 heating stages (C1, C2)� 2 heating power: - 1000 / 1500 air curtain size: C1=2/3 C2 = 3/3· or 1 - 2000 air curtain size: C1= 1/”...
Page 13 Special regulators If there is a need to be able to control more parameters (intelligent proactive regulation, automatic/manual operation, door delay, time programmer, energy saving mode, multi-device management and BMS Modbus connection, among others) ), there are two controllers that allow much more possibilities than the standard controller, especially the Clever�...
Page 14: Electrical Squemes
ELECTRICAL SQUEMES Curtain with water battery or without battery with standard control models 1000 and 1500. Scheme AIRDOE07050 In case there is a need to connect the curtain to a PLC, the corresponding diagram is attached� Instruction manual - Air curtain Recessed Optima...
Page 15 Cortina with water battery or without battery with Hand Auto. Scheme AIRDOE07060 In case there is a need to connect the curtain to a PLC, the corresponding diagram is attached� Instruction manual - Air curtain Recessed Optima...
Page 16 Electric curtain 400V~3 with PRBEO and electric control models 1000 6kW and 1500 6 and 9kW. Scheme AIRDOE07100 In case there is a need to connect the curtain to a PLC, the corresponding diagram is attached� Instruction manual - Air curtain Recessed Optima...
Page 17 Electric curtain 400V~3 with PRBEO and electric control 1000-9kW. Scheme AIRDOE07200 In case there is a need to connect the curtain to a PLC, the corresponding diagram is attached� Instruction manual - Air curtain Recessed Optima...
Page 18 Electric curtain 230V~1 models 1000 and 1500 6 kW and electric control. Scheme AIRDOE07190 In case there is a need to connect the curtain to a PLC, the corresponding diagram is attached� Instruction manual - Air curtain Recessed Optima...
Page 19 Electric curtain 230V~1 and electric control 1000 E230-9kW. Scheme AIRDOE07215 In case there is a need to connect the curtain to a PLC, the corresponding diagram is attached� Instruction manual - Air curtain Recessed Optima...
Page 20 Electric curtain 230V~1 and electric control 1500 E230-9kW. Scheme AIRDOE07195 In case there is a need to connect the curtain to a PLC, the corresponding diagram is attached� Instruction manual - Air curtain Recessed Optima...
Page 21 Curtain with water battery or without battery with standard control model 2000. Scheme AIRDOE07150 In case there is a need to connect the curtain to a PLC, the corresponding diagram is attached� Instruction manual - Air curtain Recessed Optima...
Page 22 Curtain without battery or with water battery model 2000 with Hand Auto. Scheme AIRDOE07065 In case there is a need to connect the curtain to a PLC, the corresponding diagram is attached� Instruction manual - Air curtain Recessed Optima...
Page 23 Electric curtain 400V~3 model 2000 and electric control. Scheme AIRDOE07160 In case there is a need to connect the curtain to a PLC, the corresponding diagram is attached� Instruction manual - Air curtain Recessed Optima...
Page 24 Electric curtain 230V~1 with PRBEO model 2000 and electric control. Scheme AIRDOE07170 In case there is a need to connect the curtain to a PLC, the corresponding diagram is attached� Instruction manual - Air curtain Recessed Optima...
Page 25: Data Sheet
DATA SHEET RECESSED OPTIMA Characteristics • Self-supporting casing construction made of galvanized steel plate, ready to be installed recessed in a false ceiling. • Inlet grille (free of maintenance) made with aluminium profiles and blow-out nozzle, integrated in a single white frame colour RAL 9016. Other colours are available on request.
Page 26: Maintenance Instructions
MAINTENANCE INSTRUCTIONS For safety, before cleaning, stop the curtain through the controller and disconnect the device from the current. Do not open the service door (risk of electric shock and entrapment in the fans). Repairs must be carried out exclusively by authorized personnel. The inside of the device must not be cleaned with water or steam.
Page 27 Exterior cleaning Wipe the entire outer surface of the air curtain (except the suction grille) with a damp cloth to trap dust parti- cles� In addition to the damp cloth, neutral soaps that do not contain acids or are caustic can be used� Interior cleaning It is recommended to clean the inside of the unit with a vacuum cleaner at least once every 2 years�...
Page 28 Heating maintenance To ensure good heat transmission in the air curtain exchanger, it is recommended to check the heating coils as follows: Coil cleaning With both electric coils and water coils, the coil must be cleaned periodically with pressurized air� Water coils Check the inlets and outlets of the water tubes to ensure that there are no fl uid leaks.
Page 29 Electrical coil Check that no cable has been disconnected from the battery circuit: Resistence type for models optima in all its lengths Models To verify the correct operation of the component, check the battery consumption per heating stage� Theore- tical consumptions are shown below: Optima models Curtain Theoretical consump-...
Page 30: Repairs And Replacements
REPAIRS AND REPLACEMENTS Assembly and electrical connection must be carried out exclusively by specialized professionals and in compliance with these instructions. Before carrying out any repair, it is necessary to: • Notify staff and indicate that work is being done. •...
Page 31 Service door opening Recessed Optima model 1� Remove the two service door security screws by inserting a screwdriver 2� Raise the grate of the service door to be able to open the panel� Fan replacement Before changing the fan, notify and indicate that it is working, disconnect the power supply, making sure that there is no voltage and that the fans have stopped�...
Page 32 Turbine savety screw Replacement of the power board or fuse Before changing the power board or fuse, notify and indicate that work is being done, discon- nect the power supply, make sure that there is no voltage and that the fans have stopped� Fuse changing: remove the pcb from the curtain for better maneuverability, remove the fuse protection ca- sing and remove the fuse by hand or with the help of a screwdriver�...
Page 33 Recommendation: installation with silentblocks To reduce the sound level and the vibrations of the curtain, it is recommended to carry out an installation with silentblocks: Coil replacement Water coils: close the building’s water inlet and outlet valves up to the air curtain� Open the suction grille and drain the water coil with the drain plug of the main collector as shown in the photograph and disconnect the coil from the installation�...
Page 34 Electric batteries: disconnect the power supply from the battery itself. To remove the battery, unscrew the fixing screws. Air curtain size Nº lateral fixing screws 1000 1500 2000 Instruction manual - Air curtain Recessed Optima...
Page 35: Troubleshooting
TROUBLESHOOTING More than 95% of the claims occur during the start-up of the equipment and are due to installation errors� Reviewing the following 3 points solves more than 90% of the incidents: A) RJ45 cable manipulated: the cable connecting the control to the air curtain is an 8-way crossover RJ45 cable�...
Page 36: Accessories
ACCESSORIES Clever Control Interface II External temperature probe Smart proactive regulation, ad- Allows connection to a centrali- Allows you to take the tempera- vanced functions, automatic/ zed management system ture in a different place than the manual operation, door delay, (BMS, PLC, etc)�...
Page 37: Declaration Of Conformity
DECLARATION OF CONFORMITY Instruction manual - Air curtain Recessed Optima...
Page 38 Instruction manual - Air curtain Recessed Optima...
Page 39: Identificator
IDENTIFICATOR Each air curtain is identified by a unique serial number printed in a label located inside the door service� There is also indicated the model and Model WINDBOX M 2000 P86 their technical characteristics (flow, fans technical characteristics and Modelo power heating)�...
Page 40 Conca de Barberà, 6 - Pol. Ind. Pla de la Bruguera E-08211 Castellar del Vallès (Barcelona) Spain ☏ + 34 93 715 99 88 airtecnics@airtecnics.com www.airtecnics.com AIRDOM05042-R14(01/22) Airtècnics reserves the right to modify some of the specifications in this manual.
