morse PailPRO Series Instruction Manual

The Specialist In Drum Handling Equipment
• Pail Handlers with BATTERY POWER Lift
• Ergonomic solutions to handle 5-gallon (20L) pail
• Increase efficiency and improve worker safety
• Prevent repetitive motion injuries
• Easily maneuverable, compact design
• Reduce chance of worker's compensation claims
PailPRO Pail Handlers provide ergonomic advantage to reduce risks of
TM
repetitive motion injury from lifting heavy 5-gallon (20L) pails. Commonly
used in manufacturing, food, pharmaceutical, processing, chemical, paint
and coating industries.
Secure pail in holder with web strap. Then push toggle switch to elevate
pail. Turn pail with hand wheel. Lock pail in pouring position. Dispense up
to 5' (152 cm) high. Set floor lock to prevent Pail Handler from rolling.
Lightweight and extremely manageable. Easily maneuver through tight
spaces and standard doorways. Enclosed moving parts avoid pinch points.
MADE
IN
Model 83S-XR-125
USA
Model 83S-XR-125
Extended Reach
• Battery Power Lift
• Pour 20" (50.8 cm)
beyond front wheels
• Counter weighted,
reversed base
• Swivel casters
at front
• Capacity:
75 Lb.
(34 kg)
Counter
Weight
morsedrum.com
Copyright 2023 - Morse Mfg. Co., Inc.
5-Gallon Pail Handlers with Battery Power Lift
service@morsedrum.com
Spec Sheet F83-125
Pail Handlers with Battery Power Lift
• Lift, tilt and pour 5-gallon (20 liter) pail with ease
• Battery Power pail lift and lower
• Hand wheel tilt control with 1:1 tilt ratio
• Lock at various angles to dispense
• Handle 11" to 12" (28 to 30.5 cm) diameter pail
• Dispense up to 5 feet (152 cm) high
• Turn pail 360 o in either direction
Model 83-125
Model 83-125
Pour
Between Legs
• Battery Power Lift
• Swivel casters
at rear
• Capacity: 100 Lb.
(45 kg)
Shown with
Limited Edition
*GOLD* finish
ACCESSORY
Kit # 3930-P Counter Weight Kit
for CUSTOMER to convert EXISTING model 83-125
to model 83S-XR-125.
IMPORTANT: Reduces capacity to 75 Lb. (34 kg).
(315) 437-8475
(Updated 17 Mar, 2023)
(NOT shown)
103 Kuhn Rd.
Syracuse, NY, 13208 USA
