Summary of Contents for kube Kubebooth Kwe
- Page 1 Kubebooth Kwe ASSEMBLY GUIDE...
- Page 2 FS201 x16 - Self tapping screw Door handle set x1 for units corners assembly FS202 x48 - Self tapping screw for flat frame assembly FS203 x28 - Stand-off cap M10 for glass assembly FS205 x4 - Black M6 screw for flat frame (door side) assembly FS206 x2 - Door magnets set Door hinges x2 Stand-off cap key...
- Page 3 Outside View Inside View 1. Holes for unit corners assembly 2. Holes for metal frame and glass/door assembly 3. Cutouts for wiring 4. Airflow grill Kwe_GU_P02 Configuration Stage Page WALL UNIT (prefabricated) PACKAGE...
- Page 4 Unit View Removed panel View 1. Holes for assembly 2. Cutouts for wiring 3. Power/Data outlet Top w/Brackets to be installed upon assembling completion Kwe_GU_P03 Configuration Stage Page CONSOLE UNIT w/Power & Data (prefabricated) PACKAGE...
- Page 5 As delivered 1. Holes for unit corners assembly 2. Holes for metal frame and glass/door assembly 3. Cutouts for wiring 4. Casters w/Leveler 5. Leveler bolt 6. Cutouts for seismic bracket 7. Floor access panel Floor access panel removed Kwe_GU_P04 Configuration Stage Page...
- Page 6 1. Holes for unit corners As delivered assembly 2. Holes for metal frame and glass/door assembly 3. Cutouts for wiring 4. Cutouts for fans 5. Knock out hole for sprinkler (optional) 6. Roof access panel 7. Power control system inc. Roof access (power box w/outlets, panel removed...
- Page 7 ST221 - Frame metal part (2 on front, 2 on back) ST221 with self taping screws (FS201 x 8) per piece. This part has 5 holes for glass assembly. ST225 ST221 ST225 - Frame metal part on the rear of the unit with Self tapping screws (FS201 x 6).
- Page 8 GL211 GL211 - Sidelight glass panel has 7 holes for assembly by M10 countersunk screw FS203 GL212 with plastic socket cap FS204 two pairs of holes for door hinges GL213 assembly GL214 GL212 - Sidelight glass panel has 7 holes for assembly by M10 countersunk screw FS203 with plastic socket cap FS204 GL213 - Door glass panel has...
- Page 9 Floor access panel removed FS201 screws x4 for each corner Ensure a minimum of 48" area is left clear behind the unit to allow the unit to be stood up Kwe_GU_P08 Configuration Stage Page UNITS ASSEMBLY (on floor) ASSEMBLY...
- Page 10 Floor access panel removed FS201 screws x4 for each corner Roof access panel removed Kwe_GU_P09 Configuration Stage Page UNITS ASSEMBLY (on floor) ASSEMBLY...
- Page 11 Self tapping screws ST225 FS202 x20 Self tapping screws Self tapping screws FS202 x20 FS202 x20 ST225 Self tapping screws FS202 x20 Self tapping screws FS202 x20 Kwe_GU_P10 Configuration Stage Page ASSEMBLY BACK METAL FRAME ASSEMBLY...
- Page 12 Screws FS203 x14 with Screws FS203 x14 with Plastic sleeves Plastic sleeves GL214 GL214 Insert Acrylic seal between glass. Be sure to remove plastic to expose glazing tape, this ensures a good bond. Kwe_GU_P11 Configuration Stage Page ASSEMBLY BACK GLASS PANEL ASSEMBLY...
- Page 13 Ensure levelers have been retracted so that wheels are exposed. This will allow the unit to be rolled into its final installation location. Then level the unit. Kwe_GU_P12 Configuration Stage Page POD ASSEMBLY (raised vertically) ASSEMBLY...
- Page 14 Self tapping screws M6 screws FS205 x4 FS202 x24 ST226 Self tapping screws FS202 x24 Self tapping screws FS202 x24 Self tapping screws FS202 x24 M6 screws FS205 x4 ST226 M6 screws FS205 x4 Kwe_GU_P13 Configuration Stage Page ASSEMBLY FRONT METAL FRAME ASSEMBLY...
- Page 15 Remove front panel (with electrical) Draw both cables of console unit. Bring inside to the thrue the hole glass and aligne with floor panel edges. Screw to the floor/ceiling panels. Console unit skin panel removed Draw main cable thrue the hole Kwe_GU_P14 Configuration Stage...
- Page 16 Screws FS203 x14 with Plastic sleeves GL211 Screws FS203 x14 with Plastic sleeves GL212 Door handle Hinges x2 Screws FS203 x14 with Plastic sleeves Screws FS203 x14 with GL213 Magnets x2 Plastic sleeves Kwe_GU_P15 Configuration Stage Page ASSEMBLY FRONT GLASS PANEL & DOOR ASSEMBLY...
- Page 17 Cross connect fan wire and install roof Install top Install floor Kwe_GU_P16 Stage Page Configuration CABIN ASSEMBLY (completion) ASSEMBLY...
- Page 18 Connect fan YELLOW labeled wires to the splitter Draw both cables from Console Unit Connect the main cable to the BLUE labeled outlet Connect wall electrical outlet cable to the RED labeled outlet Kwe_GU_P17 Configuration Stage Page ASSEMBLY ELECTRICAL JUNCTIONS...
