About this Practice:
This practice has been reissued to:
• Replace Fig. 2.
Reissued Practices: Updated and
new content can be identified by a
banner in the right margin.
Issue date: January 1998
Copyright 1998 by Dantel, Inc. • Dantel is a registered trademark of Dantel, Inc. • ISO 9001 Registered
400-T
YPE
Table of Contents
Ordering Information ........................................................................... 2
General Description .............................................................................. 2
Installation ............................................................................................ 2
Technical Specifications ....................................................................... 4
Warranty ............................................................................................... 6
CAUTION
•
Install or remove modules from the shelf only when the power is off.
If you install a module in the shelf with the power on, the internal
circuitry may suffer damage and the product warranty will be void.
•
Remove and install circuit boards only in a static-safe environment
(use antistatic wrist straps, smocks, footwear, etc.).
•
Keep circuit boards in their antistatic bags when they are not in use.
•
Do not ship or store circuit boards near strong electrostatic, electromag-
netic, magnetic, or radioactive fields.
•
For more complete information on electrostatic discharge safety
precautions, refer to Bellcore
Printed in the U.S.A.
I
NSTALLATION
41078
E
QUIPMENT
TM
Technical Reference # TR-NWT-000870.
& O
M
PERATION
ANUAL
41078-0198 <90-00017>
S
HELF
Advertisement
Table of Contents
Summary of Contents for Dantel 41078
- Page 1 For more complete information on electrostatic discharge safety Issue date: January 1998 precautions, refer to Bellcore Technical Reference # TR-NWT-000870. Copyright 1998 by Dantel, Inc. • Dantel is a registered trademark of Dantel, Inc. • ISO 9001 Registered Printed in the U.S.A.
- Page 2 41078 400-Type Equipment Shelf is a steel housing for two 400-type Dantel modules (or those manufactured by other suppliers). The 41078 shelf can be installed in 19-inch or 23-inch equipment racks. The shelf has plastic card guides. Ground lugs are provided for each module.
- Page 3 . 2 - M OUNTING IAGRAM ESD LABEL FRAME RAIL ESD LABEL ESD STUD ESD LABEL STANDARD LOCKWASHER SCREW ESD STUD ESD STUD LOCKWASHER STANDARD STANDARD SCREW SCREW STANDARD SCREW SHELF SIDE VIEW SHELF FRONT VIEW REAR FRONT 41078-0198 <90-00017>...
- Page 4 23" x 9.25" x 1.72" Dimensions Between Rack Mounting Holes 19" 18.3" (on center) 23" 22.3" (on center) Weight 4.6 lbs. Housing Material Steel PC Card Guide Material Plastic Terminal Block Wire-wrap Pin Dimensions Diameter 0.045" Length 0.75" 41078-0198 <90-00017>...
- Page 5 NOTES 41078-0198 <90-00017>...
- Page 6 To ensure expedient processing of your order, provide a purchase order number and shipping and billing information when requesting an RMA number. Also, when the units are returned to Dantel, include a descrip- tion of the failure symptoms for each unit returned. Send defective equipment to: Dantel, Inc.
