- Page 1 Quick Start Guide Xencelabs Pen Display 24 next...
-
Page 2: What Is In The Box
What is in the Box Xencelabs Pen Display 24 Pen Display 24 Pen Clips (Two sizes) Quick Keys Drawing Glove Medium Quick Keys Holder Cleaning Cloth 0.6m USB-C to USB-A 3.0 (standard) cable Xencelabs Decal Pen Case AC Power Adapter with L-Shaped Connector... -
Page 3: Getting Started
Getting Started Xencelabs Pen Display 24 Pen Display 24 AC Power Adapter with L-Shaped Connector Quick Keys Power Cable(s) (Varies by region) Quick Keys Holder 2m USB-C to USB-C (L-shaped) cable Wireless Dongle (For use with Quick Keys) 2m USB-C to USB-A 3.0 (L-shaped) cable 3 Button Pen v2 2m HDMI2.0 to HDMI2.0 (L-shaped) cable... - Page 4 USB-A Ports Power Connector. Use with the Wireless Dongle to connect the Quick Keys. Because the Pen Display 24 is designed to radiate heat out the back, no fans or heat vents are needed making it very quiet. What is in...
- Page 5 Connecting the Pen Display 24 Video and pen data The Pen Display’s video-data-power ports are located on the back of the display. To easily view and access these ports, we suggest using the foam packing pad the display was shipped with as a cushioned mat. Place the foam pad on a flat surface such as a tabletop, then lay the display face down on the foam pad.
-
Page 6: Download The Driver
Connecting the Download Key Features of Connecting Charging the Key Functionality Key Functionality Register Your the box Started Pen Display 24 Pen Display 24 the Driver the Quick Keys Quick Keys Quick Keys of the of the New Product Wirelessly... - Page 7 Connecting the Download Key Features Connecting Charging the Key Functionality Key Functionality Register Your the box Started Pen Display 24 Pen Display 24 the Driver of the Quick Keys Quick Keys of the of the New Product Quick Keys Wirelessly...
- Page 8 Connecting the Quick Keys Wirelessly Connection Indicator Solid Blue - Con Solid Blue – Connected Solid Blue - Con Xencelabs Pen Display 24 Solid Blue - Con Breathing Blue Breathing Blue – Wired Connection Breathing Blue Breathing Blue Blinking Blue – Trying to Connect...
- Page 9 Charging the Quick Keys Charging Indicator Solid Amber - Solid Amber - Solid Amber – Low Charge Xencelabs Pen Display 24 Solid Amber - Breathing Gr Breathing Green – Charging Breathing Gre Breathing Gre Solid Green – Fully Charged Solid Green -...
- Page 10 Key Functionality of the Pen Display 24 Device Control Buttons Three convenient device control buttons give you quick access to the Pen Display 24’s fully configurable options. Launch Settings: Bring up your Settings Panel. Adjust Pressure: Easily tweak your pen pressure.
- Page 11 Key Functionality of the Pen Display 24 Quickly Launch the Settings Panel The left device control button launches the Settings Panel. This is where you can access and customize the settings for all your devices and pens. What is in...
- Page 12 Key Functionality of the Pen Display 24 Adjust Your Pen Pressure The middle device control button pulls up the pen pressure adjustment panel for your active pen. By default, the pen tip pressure is set to the profile that works best for most users. In the Settings Panel you can individually adjust the pressure of each of your pens to match your drawing style.
- Page 13 Key Functionality of the Pen Display 24 Create Application-Specific Settings Default Settings: The Settings Panel comes programmed with default settings for the Pen Display, pens and Quick Keys. These will be used in applications for which you don’t have specific settings.
- Page 14 Key Functionality of the Pen Display 24 Switch Displays Using the Virtual Tablet With the Virtual Tablet feature, you don’t need to move to your mouse to reach items on other displays. Now you can simply press the right device control button and bring up your Virtual Tablet.
- Page 15 Key Functionality of the Pen Display 24 Using All Displays Mode In the All Displays mode you can even drag items from one display on to another, including on to your pen display. What is in Getting Key Features of the...
- Page 16 Key Functionality of the Pen Display 24 Customize Your Virtual Tablet & Display Switch Cycle In the Settings Panel you can choose the size and placement of your Virtual Tablet, and which displays to include in your Display Switch Cycle. This makes it easy to only toggle between the displays you want to control with your pen.
- Page 17 Key Functionality of the Pen Display 24 Professional Color Settings Options The Pen Display 24 offers seven different color settings options. These include five standard color spaces, a Pantone mode that provides Pantone Validated ® and Pantone SkinTone Validated color, and a fully customizable user mode setting.
- Page 18 Key Functionality of the Pen Display 24 Easily Calibrate Your Pen Your pen ships already factory calibrated. However, if you feel the need to adjust how your cursor sits under your pen tip, you can do so using the recalibration tool in the Settings Panel.
- Page 19 Key Functionality of the Pen Display 24 Create a Cursor Offset Should you find your hand in the way of system windows or want to purposefully offset your cursor for any other reason, you can do so using our tool in the Settings Panel.
- Page 20 Key Functionality of the Quick Keys Xencelabs Pen Display 24 Quick Keys Dial Modes The Quick Keys dial can be customized to perform four dual actions, such as zoom in/zoom out. The dial will glow the color of your choice to identify the current mode.
- Page 21 Key Functionality of the Quick Keys Xencelabs Pen Display 24 Quick Keys Sets The eight buttons on the Quick Keys can also be customized in the Settings Panel. You can create and save up to five sets of actions for each application.
- Page 22 Key Functionality of the Quick Keys Xencelabs Pen Display 24 Adjust Your Quick Keys Orientation Because the Quick Keys can be used in any orientation, and attached to all edges of the Pen Display, you can also adjust its orientation within the Settings Panel. This feature can be found under the customize dropdown.
- Page 23 Register Your New Product Xencelabs Pen Display 24 Locate Your Serial Number Register your New Product Your product serial number can Register to join the growing community be found on both your box, and of creatives using Xencelabs products the back of your pen display below the connection ports.
-
