Summary of Contents for George & Willy HANGING DRYING RACK
- Page 2 Suspended using a pulley system that utilities the warm air trapped in the ceiling, The Hanging Drying Rack is a fun and functional solution for drying your laundry. Enjoy...
-
Page 3: Care Guide
CARE GUIDE Where you install your product depends on its material/s. Wooden and Steel Products: We recommend using these products inside or under a shelter where they are protected from any exposure to rain or water. Aluminum Products: These products are non-corrosive and suitable for use outside. - Page 4 COMPONENTS 2 x Side Bar 12 x Dowel 2 x Rope 1 x Cleat 3 x Pulley 14 x Large Screws 18 x Small Screws 1 x Allen Key...
- Page 5 Please use a qualified professional to ensure safe assembly and installation of this product. Before you start assembly please lay your Hanging Drying Rack out on the floor like above, ensuring that the rope is not twisted and in the correct position before...
- Page 6 Once you are happy your Hanging Drying Rack is in the correct position place the dowels in the middle evenly so they match up to the correct holes on the outside brackets, using the Allen key to tighten the screws.
- Page 7 Select a suitable location to install the Hanging Drying Rack. Ensure the chosen space allows enough room for the rack to be raised and lowered easily.
- Page 8 Screw Pulley into the ceiling. Make sure the pulley is secured to a beam.
- Page 9 1 08 5 m m ( C e n tre to ce n te r ) Install pulley 1085mm back from pulley . Ensure they are perfectly aligned.
- Page 10 Install Pulley further back from pulley , close to the Corner of the ceiling and wall. Ensure all three pulleys are perfectly aligned.
- Page 11 Install the Rope Cleat vertically below pulley on the wall. Please ensure the screws find a stud. All three pulleys and the rope cleat must be aligned.
- Page 12 Thread Rope through Pulley . Continue across to pulley and then through pulley...
- Page 13 . Pull both ends of rope ( ) until the Hanging Drying Rack is raised off the ground. Adjust each end accordingly until the rack becomes level in the air - A builders level should be used for complete accuracy.
- Page 14 Raise the Hanging Drying Rack to the desired height attended for use (chest height recommended). Tie a knot in the two ropes just behind pulley .This stops the rack from lowering any further. Tie off rope around the cleat. Cut any excess rope off and melt the...
- Page 15 We recommend tying two separate knot positions to sit under the cleat. Trim any excess rope off.
- Page 16 To keep excess rope out of reach, loop the rope up over the cleat.
- Page 17 Warning: Please note that when the Hanging Drying Rack is in its up right position, take extra care when lowering as the weight of the rack will increase when fully loaded with garments when off the cleat. The minimum height of the cleat needs to be installed at 170cm/67.0"...
- Page 18 George & Willy Ltd holds no liability for any harm or damage that is caused by incorrect installation or use of a Hanging Drying Rack. The Hanging Drying Rack must be installed by a certified professional who will be able to advise the correct type of fixing for the ceiling that it will be installed into.
- Page 19 CONTACT US @georgeandwilly www.pinterest.com/georgeandwilly/ sales@georgeandwilly.com www.georgeandwilly.com...
- Page 20 THANK YOU Don’t forget to tag us on Instagram @georgeandwilly For 10% off your next purchase, use the discount code: WITHTHANKS...
