Preethi Peppy Plus MG246 Instruction Manual

R
Peppy Plus- MG246
Peppy- MG245
Transforms regular food into superfood.
Supports increase in Bio accessibility of essential nutrients.*
Instruction manual - MG244, MG245 and MG246
*Disclaimer: Based on research papers and sample (Chia Seeds) tested and validated by NABL accredited external Lab. Efficiency of grinding exhibited particle size
reduction and better nutrient extraction from the ground particles than its raw form during testing thereby supporting increase in bio accessibility.
# Lifelong free service (Applicable only on products purchased in India). Lifelong free service does not cover any replacement of the parts including motor
post expiry of the warranty period.
Preethi brings to you new mixer grinders, Blush, Peppy and Peppy plus.
Model name Blush - MG244 Peppy - MG245
Base unit, 1.25 L Wet jar,
Specifications
0.75 L Dry jar, 0.3 L Chutney jar
Voltage 230V~50Hz
Power consumption
600W
Protection Class II
Insulation Class F
Motor
Universal
No load speed of motor 17500-18500 RPM 19500 - 20500 RPM
Material of jars Stainless steel
Blade assemblies Stainless steel, machine ground polished
Speed controls Rotary switch with 3 speeds and pulse
Flexi cord PVC flexi cord with PVC flexi cord with plugtop and earthing -
plugtop 3core pin
and earthing - 2core
pin
Rating Ordinary total rated ON time 30 minutes (max),
Continuous ON for 5 minutes (max.) and off for 2 minutes (min.)
Rest time 45 minutes.
Protection against ingress IPXO
of water
Protection against dust and Ordinary
moisture
Country of origin
INDIA
Gross weight 4 kgs
Size of carton (mm) 368 (L) x 217 (W) x 348 (H)
Guarantee
2 year guarantee on the product
Warranty 5 years warranty on the motor
1. Base unit with universal motor
2. Switch knob
3. Over load protector
4. Anti-slip rubber feet
5. 1.25 L Wet jar with fixed blade and lid
Wet jar
Dry jar
Chutney jar
Blush- MG244
Blender/ Superfood jar
NA: Not applicable
Note : The provided stirrer has to be used only with blender/ Superfood jar (Peppy Plus)
3.0 Do's
1. When operating the mixer grinder for the first time after long storage or when the mixer has been
shifted from the long distance, rotate the motor shaft by hand through the motor coupler, until the
motor shaft rotates freely.
2. Unplug the appliance from the main socket before fixing or removing accessories, when cleaning
and when not in use.
3. Ensure that the jar is locked properly in the locking grooves provided inside the top cap.
4. Ensure the blades are fitted properly before running.
5. Ensure proper locking of jar on the power unit and proper locking of lid on the jars to switch on the
appliance.
6. If the supply cord is damaged, it must be replaced by the manufacturer or authorized service
centre only in order to avoid hazards. On violation, the warranty becomes void.
7. Check if the voltage indicated on the base of the appliance, corresponds to the local electrical main
voltage before connecting the appliance.
8. Always unplug the appliance after use.
3.1 Don't's
1. Do not place the appliances on an unstable surface.
Peppy Plus- MG246
2. Do not move the appliances during operation.
Base unit, 1.25 L Wet jar, 0.75 L Dry
3. Do not touch the moving parts when operating the mixer grinder.
jar, 0.3 L Chutney jar, 1.0 L
Blender jar with stirrer 4. Do not overload the mixer grinder. When hot air emanates from the openings of the top cap.
Switch off the motor and wait for 3-5 minutes before re-starting.
5. Do not add solid ingredients when the motor is running.
750W
6. Do not operate with damaged power cord.
Class I
7. Do not tamper with or attempt to repair the appliance. Contact your nearest Preethi Customer care
8. Do not grind hot ingredients in the mixer grinder.
9. Do not lock the jar on the base unit when the Knob is in 'ON ' Condiion.
Stainless steel,
Plastic (Blender jar) 10. Do not put your hand inside the mixer when the appliance switched ON.
11. Do not run the unit without locking the jars and lid properly.
12. Do not use accessories other than those provided with the products.
13. Do not clean the mixer accessories using a dishwasher.Always rinse under tap water.
14. This appliance should not be used 2000metres above the sea level.
15. Children should be supervised to ensure that they do not play with the appliance.
16. Children should not be involved in cleaning and user maintenance. Keep the appliance and its
cord out of reach of children.
17. Do not use the appliance when the mains cord, the plug or other components are damaged. Only
the company or service center authorized by Preethi must replace it.
18. Never touch food in the jar by hand. Always use a spatula.
19. Never leave the appliance running unattended.
20. Keep the appliance away from the source of heat like gas or electric stove.
5.5 kgs
21. Do not run the appliance with the jar empty.
503 (L) x 220 (W) x 350 (H)
22. Never load the jar with ingredients beyond the maximum level (See "Maximum jar capacity" and
"Standard recipe" tables for more details).
23. Do not use any attachment other than those provided or recommended by the manufacturer. It
may cause hazards.
6. 0.75 L Dry jar with fixed blade and lid
7. 0.3 L Dry jar with fixed blade and lid
8. 1.0 L Blender jar with lid and lid cap
9. Stirrer (applicable only for blender jar)
10. Spatula
8
6
9
Blush - MG244 Peppy - MG245 Peppy Plus- MG246
1.25L
0.75L
0.3L
NA 1.0L
Dry Jar
Suitable to powder cereals, raw rice, dal, red chillies, jeera, dhaniya, garam masala,dry curry leaves,
coffee beans. also suitable for preparing sambar and rasam powders
10
Wet Jar
Idli, dosa, uthappam, appam, pesarattu, vadai
Chutney Jar
Coconut, tomato, onion, coriander, mint chutney
Pulse
4.2 How to use blender/ superfood jar (For Peppy Plus)
For recipes like milkshakes, lassi, juices
1. Add all ingredients in the blender jar till max level
2. Close the lid and fix the lid cap onto lid
3. Fix the jar in base unit and start blending in 1,2,3 speeds as required (Fig 1)
For thick recipes like chutneys , smoothies.
1. Add all ingredients in the blender jar till max level
( Refer recipe book for interesting recipes)
2. Close the lid and fix the stirrer
3. Fix the jar in base unit and start blending in 1,2,3 speeds as required (Fig 1)
4. For best results, use the provided stirrer to scrape the walls of the blender jar
intermittently while the mixer grinder is running till you get the desired consistency.
Refer recipe book for more varieties of chutneys, smoothies and smoothie bowls.
Fig1 Fig2
