Summary of Contents for Omnia OSRW-001
- Page 1 Smart Universal Remote Control OSRW-001...
-
Page 2: Light Status
Network connect Configuration successfully Steady on Network disconnect Blue Configuration successfully, Blinks one time sending Data Access Learning mode Steady on Learning instruction Off receive Keep pressing reset Reset button 5s Add Omnia SMART IR 1: Download Smart Life APP... - Page 3 2: Registration or log in • Download “Smart Life” Application. • Enter the Register/Login interface: tap ”Register” to create an ac- count by entering your email to get verification code and “Set pass- word”. Choose “Log in” if you already have Smart life account 3: Configure the APP to Smart IR Preparation: Ensure the device is connected to the electricity;...
-
Page 4: Copy Button
Copy Button Operation If you cannot find the remote which is able to control the appli- ance, you can learn the function through copy button. (Notice: Cur- rently copy button function only supports TV / STB /TV BOX / FAN, exclude Air conditioner) Step 1: Click to enter the connected device... - Page 5 If you need to change or add more buttons, you can choose up right corner “Edit” button. NOTICE 1: Support learning of 38K carrier frequency, if you cannot receive instruction from original remote, the main reason maybe mis- matching of carrier frequency. In this case, you cannot learn the in- struction from original remote.
- Page 6 Choose your own WiFi and wait for a few minutes. After an intro- duction video, click next step, it will enter Home page automatical- ly. Now the Echo has connected to Wi-Fi successfully. Enable Smart Life Skill in Alexa App Step 1: Choose “Skill”...
-
Page 7: Control Device
Control the device by voice After the above operation is successful, you can control the device via Echo. 1: Discover Device First, you need to say to the Echo: Echo (or Alexa), discover my devices. Echo will start to find the device which is added in the Smart Life APP. It will take about 20 seconds, then Echo will tell you the result. - Page 8 Note: Echo is one of the wake up names, which can be any of the three names (Settings) Alexa, Echo, Amazon. 3: Support Skill List You can control the devices by instructions like these: Alexa(or Echo), turn on the Devices Alexa(or Echo), turn off...
- Page 9 Step 1: Open Google Home App; tap ( ) on the upper left corner; select "More Settings": to enter the next interface.
- Page 10 Step 2: Choose “Services” in the options bar and select “Smart Life” to enter the next interface.
- Page 11 Step 3: Tap “ Link Account “, then sign in your smart Life Account. Tap “Link Now”, after your Smart Life account has linked to Step 4: Google Assistant, the smart devices will automatically appear.
- Page 12 Command the Device through Your Voice First, you need to say “OK Google, talk to Smart Life” to wake up Smart Life. Then you can control the device by instructions like these: Turn on the/Turn off the Note: After Smart Life has been waken up, you may say “Cancel“ or “Stop”...
-
Page 13: Voice Control
Voice Control Instruct Device Alexa command list Alexa, turn on 'device name' Alexa, turn off 'device name' Alexa, set 'device name' temperature to ** degrees Alexa, increase 'device name' temperature Alexa, decrease 'device name' temperature Alexa, turn on 'device name' Alexa, turn off... - Page 14 1. Product 1.1：Built-in Battery included？ A：No built-in battery，need to connect with power directly (USB line & Power adapter available) 1.2：5G wifi supportable？ A：Only support 2.4G wifi, no 5G wifi acceptable 1.3：Is this IR universal works with internal code library？ A：Code library is kept in the cloud, you must connect with internet 2.
- Page 15 7. What is the range Smart IR can work A: Within Diameter 16 meters. 8. How to use Smart IR learning function? A：Please check copy button instruction. Model OSRW-001 Power Input DC 5V/1A（Micro Usb2.0） Stand-by Power ≤0.5W Infrared distance ≤10m (affected by the environment)
- Page 16 Trouble Shooting Guide Why Smart Universal Remote can’t control the appliance? Step 1: Make sure if the network works well in Smart IR (Touch any remote button on the smart life app, if the device indicator light flashes network is ok) Step 2: Check if there is obstacle between remote and appliance, within 8 meters...
- Page 17 Smart Universal Remote Control OSRW-001 User Manual w w w . s m a r t o m n i a . c o m smart.omnia smartomniacr...
