  • Page 1 User manual...
  • Page 2: Table Of Contents

    1.2.2 Safety Precautions .................................... 4 1.2.3 Chapter 2 Product Composition ....................... 6 Ezi-IO CC-Link IE TSN DIO Product Name ......................6 Product List ................................6 System Diagram ..............................7 Chapter 3 Product Specifications ..................... 8 CC-Link IE TSN Specifications ..........................8 Product Standard ..............................
  • Page 3 Function Explanation ..................... 27 Open Collector Output ............................27 Open Collector Motion .................................. 27 8.1.1 Open Collector Method ................................28 8.1.2 Ezi-IO CC-Link IE TSN DIO Input/Output ......................29 Output Signal ....................................29 8.2.1 Input Signal ......................................30 8.2.2 DIO Control ................................31 Digital I/O Output .....................................
  • Page 4: Chapter 1 Safety And Installment Precautions

    DIO.  Please use the Ezi-IO CC-Link IE TSN DIO safely after a full comprehension of the User Manual.  Make sure that the end users read this manual and then keep the manual in a place for future reference.
  • Page 5 Please use non-flammables such as metals in place of handling the product. There is a risk of fire. If there are several Ezi-IO CC-Link IE TSN DIO installed in a closed space, please install cooling fans to keep the temperature around the modules below 50℃.
  • Page 6: Chapter 2 Product Composition

    Chapter 2 Product Composition 2.1 Ezi-IO CC-Link IE TSN DIO Product Name 2.2 Product List...
  • Page 7: System Diagram

    2.3 System Diagram...
  • Page 8: Chapter 3 Product Specifications

    Chapter 3 Product Specifications 3.1 CC-Link IE TSN Specifications Communication CC-Link IE TSN method Ethernet – 100BASE-TX Physical layer RJ45 Connector LA P1/LA P2 Station type Remote device station Authentication Class B class Communication 1 Gbps speed Topology Line/Star, Ring Communication Over 200 μs cycle...
  • Page 9: Product Standard

    3.2 Product Standard Product name Ezi-IO-CT-I32N-E Ezi-IO-CT-O32N-E Ezi-IO-CT-I16O16N-E Input voltage DC24V±10% · Control power: · Control power: · Control power: Maximum 150mA Maximum 180mA Maximum 170mA · Input/ output power: · Input/ output power: · Input/ output power: Current consumption Maximum 110mA Maximum 70mA Maximum 90mA...
  • Page 10: Product Size

    3.4 Installing Product ② ① The Ezi-IO CC-Link IE TSN DIO can be installed on a DIN rail with a width of 35mm. The installation order is as follows. ① Hang the notch on the back on the DIN rail.
  • Page 11 Information The Ezi-IO CC-Link IE TSN DIO comes with 2 hook levers and 2 fixation levers. The hook levers and fixation levers each have holes for M4 screws so the module can be installed and fixated with screws. * The fixation levers are not used for the DIN rail installments.
  • Page 12: Chapter 4 Exterior Names And Functions

    Chapter 4 Exterior Names and Functions -12-...
  • Page 13: Cc-Link Ie Tsn Ip Setting Switch (Sw1, Sw2)

    4.1.1 CC-Link IE TSN IP setting switch (SW1, SW2) The switch that sets the IPv4 of CC-Link IE TSN communication IP address. Ex) SW1 is 7, SW2 is 5 (5×16)+(7×1) = 87 IP: Set to 192.168.3.87. * The IP set by the rotary switch is applied when the power of the module is turned on. 4.1.2 Status display LED Display...
  • Page 14: Power Connector (Cn1)

    4.1.3 Power connector (CN1) Number Function Input/ Output DC24V Input Input 4.1.4 Input / Output connector (CN2) Number* Display* Function Input/Output ① EXT_DC24V Output 0~31 ② 0~31 SIGNAL Input/Output 0~15 / 0~15 ① ② ③ ③ EXT_GND Output * In the case of Ezi-IO-CT-I16O16N-E modules, it is displayed as 0~15 / 0~15. -14-...
  • Page 15: Cc-Link Ie Tsn Communication Connection Connector (Cn3, Cn4)

    • STP(Shielded Twisted Pair) Cable CC-Link IE TSN CGNR-EC-0002F • Category 5e or higher communication • Maximum usage: 100m CGNR-EC-0003F connection (CN3, CN4) • Fixed cable CGNR-EC-0005F * For lengths not mentioned in the figure above (in 1m units), please inquire FASTECH. -15-...
  • Page 16: Chapter 5 External Wiring Diagram

    Chapter 5 External Wiring Diagram Ezi-IO CC-Link IE TSN DIO provides e-CON connector type products. e-CON connectors responds to the industry standards and can be easily connected to various equipment thus simplifying and reducing wiring work. Figure 5-1. e-CON plug connector binding 5.1 External Wiring Diagram (Ezi-IO-CT-I32N-E)
  • Page 17: External Wiring Diagram (Ezi-Io-Ct-O32N-E)

    5.2 External Wiring Diagram (Ezi-IO-CT-O32N-E) All e-CON connector signals consist of inputs. It can receive up to 32 digital data from peripheral devices. Figure 5-3. Ezi-IO-CT-O32N-E 5.3 External Wiring Diagram (Ezi-IO-CT-I16O16N-E) The e-CON connector signals are a combination of inputs and outputs. It can receive up to 16 digital data from peripheral devices and can output up to 16 digital data from peripheral devices.
  • Page 18: Internal Circuit Diagram

    5.4 Internal Circuit Diagram 5.4.1 Input Figure 5-5. NPN input internal circuit diagram 5.4.2 Output Figure 5-6. NPN output internal circuit diagram -18-...
  • Page 19: Peripheral Device Wiring

    5.5 Peripheral Device Wiring The Ezi-IO CC-Link IE TSN DIO can easily connect to peripheral devices with simple wiring using the e-CON connector. The information of various peripheral devices wiring are as below. Sensor name Module type Possible Ezi-IO models...
  • Page 20: Position Sensor

    5.5.2 Position Sensor ① S125TL-1-24-R(NPN) SMAT-8T Module type Possible Ezi-IO models Pin number Wire color e-CON connector Function Brown White Ezi-IO-CT-IN32N-E Ezi-IO-CT-IN16O16N-E Blue Black 5.5.3 Limit Switch ① SS-5GL2T(NPN) SMAT-8T Module type Possible Ezi-IO models Pin number Wire color e-CON connector Function Brown White...
  • Page 21: Brake

    ③ GX-F12A(NPN) GX-F12A Module type Possible Ezi-IO models e-CON Pin number Wire color Function connector Brown Ezi-IO-CT-IN32N-E Blue Ezi-IO-CT-IN16O16N-E Black 5.5.5 Brake ① BXW-03-10R(NPN) BXW-03-10R Module type Possible Ezi-IO models e-CON Pin number Wire color Function connector Black Ezi-IO-CT-O32N-E Ezi-IO-CT-IN16O16N-E Black OUT(GND) 5.5.6...
  • Page 22: Cc-Link Ie Tsn Communication

    Chapter 6 CC-Link IE TSN Communication 6.1 CC-Link IE TSN Specifications CC-Link IE TSN is a CC-Link communication method based on Ethernet adopted TSN (Time Sensitive Network) technology. CC-Link IE TSN applies the time synchronization technology (IEEE802.1AS) and the time-sharing method (IEEE802.1Qbv) for real time communication, enabling high-speed, high-precision control communication.
  • Page 23: I/O Device Map

    6.3 I/O Device Map 6.3.1 Ezi-IO CC-Link IE TSN IN32 Remote Register Output Remote Input Input filter count Input channel 00 not used Input channel 01 not used Input channel 02 not used Input channel 03 Input channel 04 Input channel 05 Input channel 06 Input channel 07 Input channel 08...
  • Page 24: Ezi-Io Cc-Link Ie Tsn Out32

    6.3.2 Ezi-IO CC-Link IE TSN OUT32 Remote Output Output channel 00 Output channel 01 Output channel 02 Output channel 03 Output channel 04 Output channel 05 Output channel 06 Output channel 07 Output channel 08 Output channel 09 Output channel 10 Output channel 11 Output channel 12 Output channel 13...
  • Page 25: Ezi-Io Cc-Link Ie Tsn In16Out16

    6.3.3 Ezi-IO CC-Link IE TSN IN16OUT16 Remote Output Remote Input Output channel 00 Input channel 00 Output channel 01 Input channel 01 Output channel 02 Input channel 02 Output channel 03 Input channel 03 Output channel 04 Input channel 04 Output channel 05 Input channel 05 Output channel 06...
  • Page 26: Network Parameter Settings

    Communication Period Setting Set the communication cycle of the master station. The Ezi-IO CC-Link IE TSN DIO supports 1 Gbps communication speed so the master station communication cycle can be set on a broad range. There is a difference in the communication cycles available according to the "Setting in Units of 1us"...
  • Page 27: Chapter 8 Function Explanation

    Chapter 8 Function Explanation 8.1 Open Collector Output 8.1.1 Open Collector Motion An open collector is a common type of output scheme which functions like a switch where the output port is either connected to the ground (ON) or disconnected (OFF) as shown in figure 8-1. The port does not output a particular voltage/current but is connected with the base of an internal NPN transistor whose collector is externalized (“Open”...
  • Page 28: Open Collector Method

    8.1.2 Open Collector Method • NPN type (N type) NPN type uses an NPN transistor at the output and when the transistor is turned ON, load current flows inward. Also referred to as 'SINK type'. The 2 external connection methods have been marked in figure 8-2. The first is when the NPN output provides a passage to the load current.
  • Page 29: Ezi-Io Cc-Link Ie Tsn Dio Input/Output

    Output Signal All of Ezi-IO CC-Link IE TSN DIO outlets are open collector types and there are NPN(N type) and PNP (P type) products depending on the type of open collector method they support. The output circuit is based on 24V and the maximum output current is 200mA for each channel (Option A products maximum 500mA/CH) Please check the standards of peripheral devices before using.
  • Page 30: Input Signal

    8.2.2 Input Signal All of Ezi-IO CC-Link IE TSN DIO inputs are photocouplers and there are NPN(N type) and PNP (P type) products depending on the type of output method of connecting peripheral devices. • NPN type (N type): The outputs of connected peripheral devices are NPN open collectors and in the stance of peripheral devices, current flows in (SINK type) •...
  • Page 31: Dio Control

    8.3 DIO Control 8.3.1 Digital I/O Output The output can be controlled by adjusting the RY0 ~ RY31 value of the I/O device map. The n in RYn controls the output status of the nth channel and the output status according to each value is as follows. Value Instruction When the output signal (transistor) is off and current dos not flow out...
  • Page 32: Input Filter

    This function prevents the change of data when there is high frequency noise such as chattering included in the incoming signals. Ezi-IO CC-Link IE TSN DIO samples input signals every 200us. When the same input signal as the predetermined value of the input filter is sampled consecutively, it accepts it as valid input data.
  • Page 33: Settings And Operation

    Chapter 9 Settings and Operation 9.1 System configuration example CC-Link IE TSN Figure 9-1. System configuration example • Master station (IP address: 192.168.3.253) Base module: R33B Power supply module: R61P CPU module: R08CPU Communication master module: RJ71GN11-T2 • Remote station (IP address: 192.168.3.1) I/O Module: Ezi-IO CC-Link IE TSN IN16OUT16 •...
  • Page 34: Produce Setting Steps

    9.2 Produce Setting Steps 1. Add CSP+ file. • Click on [Tool] – [Profile Management] – [Register] menu above GX-Works3. • Find CSP+(.zip file) downloaded from FASTECH homepage. Figure 9-3. CSP+ file registration 1 Figure 9-4. CSP+ file registration 2...
  • Page 35 2. Create project. • Create project with [Project]-[New] menu. • Select CPU type and language then press 'OK' to create project. Figure 9-5. Create project 3. Set module. • Double click on [Module Configuration] on the left side's Navigation. • First, add base module from right side's Element Selection then add power module, CPU, network module considering user's system.
  • Page 36 4. Set CPU module. • You can set the CPU parameter on [Parameter]-[R08CPU]-[CPU Parameter] on the left side's Navigation. • To use as the CC-Link IE TSN master in this setting, [Memory/Device Setting]-[Link Direct Device Setting] must be changed to Extended Mode (iQ-R Series Mode). Figure 9-7.
  • Page 37 • Double click [Basic Setting]-[Refresh Settings] and set link device. The details for the settings are as the following figures. Figure 9-9. Communication module link device setting 1 Figure 9-10. Communication module link device setting 2 -37-...
  • Page 38 • Double click on [Basic Setting]-[Network Configuration Settings] and set network configuration. The details for the settings are as the following figures. Figure 9-11. Communication module product setting 1 Figure 9-12. Communication module product setting 2 6. Use with PLC programming. -38-...
  • Page 39 #1202, 401-dong, Bucheon Techno-Park without prior notification. (Postal code: 14502) ⚫ Ezi-IO CC-Link IE TSN DIO is a registered trademark TEL: 032-234-6317 FAX: 032-234-6302 of FASTECH. E-mail: sales@fastech-motions.com ⓒ Copyright 2022 FASTECH Co.,Ltd. Jan 27, 2023 Rev.1 Homepage: www.fastech-motions.com...
