RemoteLock 2500 Series Manual

Wall or door mounted keypad
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
2500 SERIES
WALL OR DOOR MOUNTED KEYPAD
1
Hardware Installation
Do this first:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2500 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for RemoteLock 2500 Series

  • Page 1 2500 SERIES WALL OR DOOR MOUNTED KEYPAD Hardware Installation Do this first:...
  • Page 2 Introduction These instructions show how to install the 2500, 12V series keypad, enclosure, power supply & electric strike on a typical door. Your door setup may differ, but the same principles will apply. The 2500 will work with most 12V DC lock mechanisms, including electric strikes, magnetic locks, solenoid locks, gate locks and multi-point motors.

  • Page 3: Installation

    Installation 3. Using the included security 4. Position the white enclosure wrench, remove the T10 screw in the preferred position. In this from the underside of the white instance we will install it close to the enclosure. The cover unclips from strike.
  • Page 4 5. Mark up the position of the 6. Fix the enclosure to the wall cable and mounting screws and using the included fixings. drill a ¾” (19mm) cable hole. 9. Drill out these holes. 10. Plug in the red/black and blue/green cables as per the wiring diagram.
  • Page 5 Optional 13. Feed the 4 cables through the 12. In this instance we will use the hole, making sure to pull them rubber gasket. Place the gasket over through the hole in the enclosure. the pre-drilled holes and then align the Do not pull tight, you should leave backplate over the gasket.
  • Page 6 16. Remove the electric strike and 17. Refit the electric strike and fit the diode as per the wiring carefully feed the cables through diagram. The diode has a white ring the door frame. on one side. This should connect to the +12V wire.

  • Page 7: Set Pin Code

    New PIN Code You should hear two beeps and see green lights when successful. Additional PINs can also be added via the RemoteLock app after connecting the lock to Wi-Fi. 21. Connect the Wi-Fi antenna 22. Snap the enclosure cover back NOTE: PIN Codes cannot be single digit codes (1111) or all sequential numbers (1234).

  • Page 8: Programming Functions

    The keypad can be used to program lock functions. These functions can also Your lock is now installed. be performed remotely from the RemoteLock app. None of the following functions are required for setup. All keypad programming functions follow the same general steps: 1.
  • Page 9 120: Delete Local User Code 100: Change Programming Code If you would like to remove your Local User Code or Default 4321, enter the The programming code is essentially a password. This code allows you to following on the lock’s keypad: program the lock directly, using the keypad.
  • Page 10 380: Turn off SmartCard reads. 381: Turn on Always Scanning For Cards mode. The 2500 series keypad can be mounted on a door, panel or thin wall up 390: Require # to be pressed after a user code is entered.

  • Page 11: Troubleshooting

    Troubleshooting Notes The strike does not release. Electric strikes are sensitive to pressure. If the door does not close properly and the latch rubs against the side of the strike, the strike can jam and not release. When the door is closed, there should be a small amount of movement when you push/pull the door.

  • Page 12: Battery Wiring

    12V Wiring Battery Wiring Contact us for additional wiring diagrams.
  • Page 13 Visit us online. support.remotelock.com We’re here to help. 1 (877) 254 5625 support@remotelock.com...
