Summary of Contents for NANO CEQ
- Page 1 Quick guide...
- Page 2 Double check the power cord polarity. If you plug the module backwards you might damage its electronic circuits. If you flip over your CEQ, you will find the “RED” mark at the PCB power connector, which must match the colored line on the ribbon cable.
- Page 3 CEQ is an analog 3-band Equalizer and Compressor module in 4HP. What is a 3 Band Equalizer? CEQ has 3 equalization controls, which allow the user to adjust the tonal balance of the input audio signal: high, mid, and low.
- Page 4 Resonance factor Q = 0.5 Cutoff frequency: 256Hz Compressor Boost the signal and balance its dynamics, from Level Indicator COMP no compression to heavy Shows the strenght of the and untamed distortion. output signals (L and R) NANO Modules - València 2023 ©...
- Page 5 COMP This One-knob compressor also includes automatic makeup gain, which automatically adjusts the output Fig.3 Detail of COMP Control level of the audio signal after compression so that the overall level remains consistent. NANO Modules - València 2023 ©...
- Page 6 Audio is normalled from L to R. • Stereo Outputs L · R Stereo outputs allow you to send separate signals to each side of a stereo sound system. Fig.4 Inputs & Outputs Close-up View Modular voltage levels [±10V] NANO Modules - València 2023 ©...
- Page 7 EN 61000-3-3. Limitation of voltage changes, voltage fluctuations and flicker in public low-voltage supply systems. • EN 62311. Assessment of electronic and electrical equipment related to human exposure restrictions for electromagnetic fields. • RoHS2: 2011/65/EU • WEEE: 2012/19/EU NANO Modules - València 2023 ©...
- Page 8 Unauthorized mods. Exposure to extreme temperature or moisture levels. Please contact our customer service - jorge@nano-modules.com - for a return authorization before sending the module. The cost of sending a module back for servicing is paid for by the customer.
