PORTABLE HOT WATER SYSTEM
Model No. HWS0012
Portable instant hot water on demand
Automatic ignition starts when the pump is turned on,
stops when the pump is turned off
LCD temperature display screen
Multi-season mode
Low water pressure on start up
Easy temperature adjustment
Hanging / mounting carry handle
Flame failure system
Low pressure safety system
Includes showerhead, water hoses, filter, pump, gas
regulator and hose
Gas certified to Australia & New Zealand standards
Important: Retain these instructions for future use
NOTE: USE OUTDOORS ONLY
Gasmate
is a registered trademark of
®
Sitro Group Australia Pty Ltd www.gasmate.com.au
Aber Living, N.Z www.gasmate.co.nz
1
5371 02/22
Advertisement
Table of Contents
Summary of Contents for Gasmate HWS0012
- Page 1 Gas certified to Australia & New Zealand standards NOTE: USE OUTDOORS ONLY Important: Retain these instructions for future use 5371 02/22 Gasmate is a registered trademark of ® Sitro Group Australia Pty Ltd www.gasmate.com.au Aber Living, N.Z www.gasmate.co.nz...
-
Page 2: General Warnings
• NEVER check for leaks with a flame or pilot light. • This appliance must only be serviced by an • Using soapy water, coat all connections, if bubbles authorised service agent, contact GASMATE appear turn the cylinder gas control off and directly for your local service agent. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS This appliance shall only be used in an above ground open air situation with natural ventilation without stagnant areas where gas leakage is rapidly dispersed by wind and natural convection. Any enclosure in which appliance is used should comply with one of the following: A. -
Page 4: General Information
GENERAL INFORMATION The Gasmate Watertech is activated by water pressure. • If there is not enough water pressure, the Watertech unit will not function. Restricted water flow (kinked hose or dirty filter) will • affect the operation of the Watertech unit. - Page 5 SETTING UP The Gasmate Watertech Portable Hot Water System should only be located in a vertical position. The unit should be partly sheltered from the elements or the potential to be sprayed by the showerhead whilst in operation. This appliance is not designed to be used as a permanent shower or supply of hot water.
- Page 6 3. Insert 2 x “D” Cell batteries 4. Check that the power switch is in Connect Showerhead to (not included) in the battery the “OFF” position. Place the Red Water Outlet hose. Set compartment and secure pump in a suitable water reservoir Showerhead to ‘Open’...
-
Page 7: Operation
OPERATION It is IMPORTANT that the following steps are followed to ensure that the appliance will start correctly. 1. Turn Season Control to SUMMER. 2. Turn GAS Control to MIN. If the source water temperature is above 10ºC, keep the season control knob at SUMMER. -
Page 8: Adjusting Water Temperature
ADJUSTING WATER TEMPERATURE SUMMER MODE NOTE: The unit will switch off automatically if the water temperature exceeds 50ºC. To increase the Water 2. Adjusting the Water Flow will also Temperature when in SUMMER help to achieve the desired Water mode, turn GAS Control to Temperature (i.e. -
Page 9: Troubleshooting
You can inadvertently activate please switch the unit off and contact Gasmate this safety feature without having a gas leak. This Customer service on 0800 161 161 (NZ). -
Page 10: Maintenance And Service
MAINTENANCE & SERVICE CARE INSTRUCTIONS Using warm soapy water with a mild detergent, During operation if it is noted that the burner flame wipe down all surfaces and areas of the appliance, is unstable, is changing colour from blue to yellow or has a distinct smell it is important that you take taking care not to allow water to enter the burner the appliance to your local authorised gas appliance... -
Page 11: Year Warranty
1 YEAR WARRANTY Aber Living warrants the purchaser of this product against defects in workmanship and material, for a period of up to 12 months from the date of purchase. The warranty is non-transferable and becomes void if used for commercial or rental purposes.
