Techno Sun ACU0613 Instruction Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Instruction

Manual

Cover installation and removal

V.032323

Table of Contents

Need help?

Do you have a question about the ACU0613 and is the answer not in the manual?

Questions and answers

Summary of Contents for Techno Sun ACU0613

Page 1 Instruction Manual Cover installation and removal V.032323...
Page 2 Table of contents 1. Notice! Before opening the cover 2. Remove cover and disconnect connections 2.1. Open cover 2.2. Cover removal 2.3. Disconnecting the temperature sensor 2.4. Disconnecting the heating resistor 2.5. Disconnecting the temperature sensor 2.6. Removing the anode and cathode 3.
Page 3 1. Notice! Before opening the cover !! Disconnect the water heater from any electrical wiring !! !! The exchange of the circuit board may only be carried out exactly according to instructions and only by persons with a basic electrical understanding !! 2.
Page 4 2.3. Disconnecting the temperature sensor Pull the white plug of the temperature sensor out of the board holder. This requires some force. 2.4. Disconnecting the heating resistor Disconnect the marked red and black cable from the contact plugs. TIP: Grasp the cable at the connector with transparent protection and rock slightly to the right &...
Page 5 2.6. Removing the anode and cathode The last step is to remove the cathode and anode cables. Once these are disconnected, you can remove the cover from the boiler and start to insert a new cover. V.032323...
Page 6 3. Installation of the cover ATTENTION: The replacement board is different from the defective one. 3.1. Connecting the temperature sensor Take the temperature sensor plug and press it onto the prefabricated board holder. The sensor is then firmly seated when you hear a slight “click”. 3.2.
Page 7 3.4. Installation of the temperature sensor ATTENTION: The replacement board has only two wires to the temperature sensor. Connect the pluggable cable to the sensor. Loosen the screws and attach the other cable so that they are opposite each other. The two other connections of the temperature sensor remain free. Ignore the black wires in the pictures.
Page 8 Techno Sun S.L.U. C/ Villa de Madrid 32, P.I. Fuente del Jarro +34 963 826 565 www.technosun.com 46988 Paterna, Valencia. España comercial@technosun.com b2b.technosun.com...
