CYCLONE - Manual Table of Contents Congratulations on your purchase of powder applicator In order to work professionally with the machine and start production, please make sure you read this manual carefully, Reproduction of this manual requires written consent. Errors and amendments of technical details excepted, all rights reserved. We are not liable for any direct or indirect damages caused by the use of this product Table of Contents ...... -
Page 4: Machine Parts Diagram
- Manual CYCLONE Machine Parts Diagram <FRONT> * Please refer to the page. Control Panel Cyclone(inside) (Page.12) Top Hopper Start Button (Page.16) Acrylic Lid Powder Ventilator Heat Platen (inside) (Page.15) Emission filter (Page.20) Circuit Breaker (inside)(Page.12) Ventilation (Page.12) <BACK> Sensor (Page.16) Film Stand (Page.8) - Page 5 - Manual CYCLONE Specifications Dimensions Applicator 67 cm(W) x 126 cm(L) x 196 cm(H) 26.4 inch(W) x 49.6 inch(L) x 77.2 inch(H) 66 cm(W) x 120 cm(L) x 95 cm(H) 2nd Conveyor for Dryer 26 inch(W) x 47.2 inch(L) x 37.4 inch(H) ( Optional ) About 200 kgs (about 441 lb) Conveyor Belt...
-
Page 6: Installation
CYCLONE - Manual Installation Gently open the back door of the machine and find the zipper bag inside the machine and please check if all the components are in the zipper bag. <Open the circled door> <Inside the door> <Components in zipperbag> ②... - Page 7 CYCLONE - Manual Installation 1. Machine Leveling Please ensure the machine is properly placed and leveled. Otherwise, powder in the machine will not applied consistently. To level the machine, turn the machine feet clockwise to decrease height and counter clockwise to increase the height.
- Page 8 CYCLONE - Manual Installation 3. Install the film stand. Film stand is wraped with a tinfoil and is inside the bottom door. Unpack the film stand and install as the shown picture. <Open the circled door> <Film stand is packed with tinfoil> <Components>...
- Page 9 CYCLONE - Manual Installation 4. Install the film sensor. Film sensor is in the zipper bag. Unpack the film sensor in the zipper bag and install as the shown picture. <Film sensor is packed in the zipper bag> <Assemble the film sensor> <Assemble the film sensor>...
- Page 10 CYCLONE - Manual Installation 5. Connect the vacuum cleaner Connect the vacuum cleaner to the labeld hoses as shown in the picture. After connecting the vacuum cleander, make sure to tighten the vacuum cleaner with insulating tape and the bands. <Labeled hose>...
- Page 11 Installation - Manual CYCLONE A Tube B Tube C Tube E Tube D Tube 5-1. Connect A tube to the inlet on the front of the Vacuum 1. 5-2. Connect B tube to the inlet on the fron of the Vacuum 2. 5-3.
- Page 12 CYCLONE - Manual Installation 6. Ventilation(Option) Ventilation should be installed according to working enviorment. *Required Ring blower spec* diameter 4”, over 170CFM 7. Connect the powder cord The country that uses 110V must be electrically constructed by an electronic expert. As 110V requires a lot of current, AC wire and Earth wire must be connected upon user’...
-
Page 13: Control Panel
- Manual CYCLONE Operation Control Panel ① ② ③ ④ 1. Power On / Off ⑤ ⑨ 2. Emergency Button 3. Manual / Auto Button ⑥ ⑦ ⑧ Under the auto mode - Conveyor speed, powder mix speed, lap time can be set. - By pressing the start button and placing the film, the powder will be automatically applied on the film Under manual mode... - Page 14 CYCLONE - Manual Operation 1) Turn on the circuit breaker which is inside the machine. <Open the circled door> <Circuit breaker> 2) Turn on the power switch which is located on the control pannel. * Ensure the emergency button on the right side of the panel is not locked. If the emergency button is locked, unlock by turning the button clockwise.
- Page 15 CYCLONE - Manual Operation (Continued) 4) Gently place the film on the heat platen. Heat platen allows ink dry for a while for better quality at 50℃ or 122℉. Additionally, it will get rid of humidity in the film. *For some areas with high humidty, we recommend you to dry the the film. *Press the button on the back side to lift the platen.
- Page 16 - Manual CYCLONE Operation (Continued) 6) Press the start button or step on the foot switch to run the machine. *Before pressing the start button, make sure to close the acryl lid. <Start Button> <Foot Switch> 7) The film will go through the powder box and will stop by the sensor at the end. * The sensor at the back detects the film after applying the powder.
- Page 17 CYCLONE - Manual Daily Maintenance ① Filter Step 1 : Turn off the power switch and unplug all the vacuum cleaners. Step 2 : Open the lid of powder box. Step 3 : Go in to manual mode and press vacuum button. <Manual Mode>...
- Page 18 - Manual CYCLONE Daily Maintenance ② Nozzle Step 1 : Go in to manual mode like the shown picture below. Press Powder On / Off button to empty the powder box. Otherwise, it would be difficult to see inside the top hopper. <Manual Mode>...
-
Page 19: Vacuum Cleaner
- Manual CYCLONE Daily Maintenance ④ Vacuum cleaner Step 1 : Turn off the power switch and unplug all the vacuum cleaners. Step 2 : Open up the vacuum cleaner and check the amount of powder inside. Step 3 : Get rid of the powder in the vacuum cleaner. Step 4 : Clean up the filter inside the vacuum cleaner with a brush. -
Page 20: Weekly Maintenance
- Manual CYCLONE Weekly Maintenance ① Emission filter Step 1 : Turn off the power switch and unplug all the vacuum cleaners. Step 2 : Unscrew the emission filter which is located in the front part of the machine. Step 3 : Clean up the emission filter with a brush. Weekly Maintenance ②... -
Page 21: Trouble Shooting
CYCLONE - Manual Trouble Shooting Problem Possible Reasons Solutions 1. Clean the nozzles and filter. -Nozzle is clogged. 2. Go in to the manual mode, and inspect "Cyclone" -Uneven Powder application -Cyclone is not woriking well. 3. Check the vacuum cleaner. -Machine is not well leveled. - Page 22 Warranty Terms and Conditions has to be operated with DTF materials like DTF powder, and DTF Film Mister-T Cyclone is designed to use with Ecofreen DTF films and powder. Other DTF films or powder may not have ideal results. Mister-T Cyclone comes up with 12 months warranty.
