Infinity KP PERFORMANCE ANTENNAS KP-6DCN-4-C5X Quick Start Manual

4.9 - 6.4 GHz, MIMO, Directional Dish Antenna
with C5x Mimosa Adapter, 4-foot
KP-6DCN-4-C5X

Features

• Twist-on antenna for Mimosa C5x, C6x and B5x PTP
• 4-Foot parabolic antenna
• All aluminum dish material

Applications

• Long distance backhaul
• Point to point data links
• 4.9/5.1/5.3/5.4/5.8/6 GHz ISM and UNII band
• Wi-Fi 2.4 and Wi-Fi 5

Description

The KP Performance KP-6DCN-4-C5X is a 4.9 - 6.4 GHz directional dish antenna with a gain of 36 dBi and a C5X type connector. This
MIMO parabolic antenna has a front to back ratio of 42 dB with a +/-45 Deg. Slant or V/H polarization. This antenna is well suited for
multiple-input and multiple-output (MIMO) and a variety of telecom applications. Our 4 foot MIMO dish antenna supports B5x, C6x and
C5x MIMOSA easy twist-on adapters for radio heads. This directional dish antenna is designed to withstand harsh environments and
temperatures between -40 to +70 deg C.
Our CSPD4-6C5X has a radome made of aluminum with a mounting mast diameter from 1.1 in–3.1 in. This 4-foot dish antenna comes
with a reliable, rugged, and flexible MIMOSA adapter and features dual linear polarization. This antenna is suitable for the enterprise,
industrial, telecom operators, radio OEMs, network deployment, backhaul engineers, and telecom industries.
This multi band dish antenna comes with an impedance of 50 Ohms and a max input power of 50 Watts. Our 4 foot long multi band
directional antenna has a maximum VSWR of 2.5:1. This directional dish antenna operates at 4.9 to 5.1 GHz/ 5.1 to 5.9 GHz/ 5.9 to 6.4
GHz frequency bands. This parabolic antenna is solid, rugged, and strong enough to withstand harsh environments.
KP Performance has the largest in-stock selection of 4.9 - 6.4 GHz MIMO dish antenna with a C5X MIMOSA adapter with same-day
shipment. Make your online purchase right now to take advantage of our same-day shipping. For further information on similar prod-
ucts, our expert technical support and knowledgeable sales team can help you get the perfect 4.9 - 6.4 GHz C5X antenna for your
requirements.

Configuration

Design
Application Band
Band Type
Radiation Pattern
Polarization
Connector Type
Lightning Protection

Electrical Specifications

Description
Frequency Range
Input VSWR
Click the following link (or enter part number in "SEARCH" on website) to obtain additional part information including price, inventory and certifications:
4.9 - 6.4 GHz, MIMO, Directional Dish Antenna with C5x Mimosa Adapter, 4-foot KP-6DCN-4-C5X
1
Minimum
4,900
Antennas Engineered to Exceed
• Wooden crate packaging
• Dual linear polarization (V/H or +/-45 deg.)
• 4900 to 6400 MHz, 36dBi Gain
• MIMO capability available
• 4.9 GHz public safety
• Licensed frequencies up to 6.4 GHz
Dish
MIMO
Multi
Directional
45 Deg. Slant
C5X
DC Ground
Typical
2:1
© 2020 Infinite Electronics, Inc. KP Performance Antennas is a registered trademark of Infinite Electronics, Inc.
+1 (855) 276-5772 | info@kpperformance.com |
Maximum Units
6,400 MHz
2.5:1
