Optima WorkPro K8X Supplementary Manual

Configuring sata hard drive(s) (controller: nvidia nforce 430)
Hide thumbs

Advertisement

Table of Contents

Configuring SATA Hard Drive(s) (Controller: Nvidia nForce 430) ......................................................2
(1)
Installing SATA hard drive(s) in your computer ...................................................................... 2
(2)
(3)
Configuring RAID set in RAID BIOS ........................................................................................ 6
(4)
Making a SATA controller driver disk ..................................................................................... 9
(5)
Installing SATA controller driver during OS installation ......................................................... 11
(6)
Configuring a bootable RAID array with Microsoft Windows 2000 ...................................... 14

Table of Contents

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WorkPro K8X and is the answer not in the manual?

Questions and answers

Summary of Contents for Optima WorkPro K8X

  • Page 1: Table Of Contents

    Table of Contents Configuring SATA Hard Drive(s) (Controller: Nvidia nForce 430) ...2 Installing SATA hard drive(s) in your computer ... 2 Configuring SATA controller mode and boot sequence in BIOS Setup ... 2 Configuring RAID set in RAID BIOS ... 6 Making a SATA controller driver disk ...

  • Page 2: Configuring Sata Hard Drive(S) (Controller: Nvidia Nforce 430)

    Configuring SATA Hard Drive(s) (Controller: Nvidia nForce 430) To configure SATA hard drive(s), follow the steps below: (1) Install SATA hard drive(s) in your system. (2) Configure SATA controller mode and boot sequence in BIOS Setup. (3)* Configure RAID set in RAID BIOS. (4) Make a floppy disk containing the SATA controller driver.
  • Page 3 CMOS Setup Utility-Copyright (C) 1984-2005 Award Software } SATAII RAID Config On-Chip IDE Channel0 On-Chip IDE Channel1 IDE1 Conductor Cable IDE2 Conductor Cable Serial-ATA-II 1 Serial-ATA-II 2 On-Chip USB USB Keyboard Support USB Mouse Support Onboard Audio Function Onboard LAN Function Onboard LAN Boot ROM Onboard 1394 Function Onboard Serial Port 1...
  • Page 4 Step 2: If you do not create RAID, select Hard Disk Boot Priority under the Advanced BIOS Features menu. In the Hard Disk Boot Priority submenu, select the model of the SATA hard drive onto which you wish to install Microsoft Windows 2000/XP. You should see a screen similar to Figure 3 below. CMOS Setup Utility-Copyright (C) 1984-2005 Award Software 1.
  • Page 5 Step 3: To boot from Windows installation CD-ROM, set First Boot Device under the Advanced BIOS Features menu to CDROM (Figure 5). CMOS Setup Utility-Copyright (C) 1984-2005 Award Software } Hard Disk Boot Priority First Boot Device Second Boot Device Third Boot Device Boot Up Floppy Seek Password Check...

  • Page 6: Configuring Raid Set In Raid Bios

    (3) Configuring RAID set in RAID BIOS Enter the RAID BIOS setup utility to configure a RAID array. Skip this step and proceed to Section 4 if you do not want to create RAID. Step 1: After the POST memory test begins and before the operating system boot begins, look for a message which says "Press F10 to enter RAID setup utility"...
  • Page 7 Step 5: Next, select the hard drives which you wish to be included in the disk array. The Free Disks section displays the information about the currently installed SATA hard drives. Press the TAB key to move to the Free Disks section. Select the target hard drives using the UP or DOWN ARROW key and use the RIGHT ARROW key to add the hard drives to the Array Disks section (Figure 8).
  • Page 8 After that, the Array List screen displaying the RAID array you created will appear (Figure 10). If you want to set the disk array as boot device, use the UP or DOWN ARROW key to select the array and press B. The Boot section will show Yes. Boot [Ctrl-X] Exit To read more information about the RAID array, press ENTER to enter the Array Detail screen (Figure...

  • Page 9: Making A Sata Controller Driver Disk

    (4) Making a SATA controller driver disk To install Windows 2000/XP onto a SATA hard drive/RAID array on the nVIDIA nForce430 controller successfully, you need to install required driver for the SATA controller during OS installation. Without the driver, the hard drive/RAID array may not be recognized during the Windows setup process. First of all, you need to copy the driver for the SATA controller from the motherboard driver CD to a floppy disk.
  • Page 10 Step 4: Double-click MENU.exe. An MS-DOS prompt screen similar to Figure 14 below will appear Step 5: Insert an empty floppy disk and select the nVIDIA Serial ATA driver by pressing the corresponding letter from the menu (for example, from the menu in Figure 14, press I to select nVIDIA C51 Series Raid (XP) if you wish to install Windows XP or press J to select nVIDIA C51 Series Raid (2K) if you wish to install Windows 2000).

  • Page 11: Installing Sata Controller Driver During Os Installation

    (5) Installing SATA controller driver during OS installation Now that you have prepared the SATA driver disk and configured BIOS settings, you are ready to install Windows 2000/XP onto your SATA hard drive with the driver. The following is an example of Windows XP installation.
  • Page 12 Step 3: If Setup correctly recognizes the driver in the floppy disk, a controller menu similar to Figure 17 below will appear. Use the ARROW keys to select NVIDIA RAID CLASS DRIVER* (Figure 17) and press ENTER. Later, when a screen similar to Figure 18 appears, you must press S to select additional driver. The screen will return to previous screen as shown in Figure 17.
  • Page 13 Step 4: When the next screen (Figure 19) appears, press ENTER to continue the SATA driver installation from the floppy disk. Windows Setup Setup will load support for the following mass storage device(s): NVIDIA RAID CLASS DRIVER (required) NVIDIA nForce Storage Controller (required) * To specify additional SCSI adapters, CD-ROM drives, or special disk controllers for use with Windows, including those for which you have a device support disk from a mass storage device...

  • Page 14: Configuring A Bootable Raid Array With Microsoft Windows 2000

    (6) Configuring a bootable RAID array with Microsoft Windows 2000 Problem: Users cannot install Windows 2000 with Service Pack 2 (or previous versions) to a bootable RAID volume. There are two solutions to resolve this issue. Solutions 1: Use the NVRAID tool (nForce Driver Version 5.xx) to convert the boot volume to a RAID array. Here are the detailed step-by-step instructions: Step 1: Install Windows 2000 onto a selected hard drive.
  • Page 15 Step 3: After system restarts, press F10 to enter the NVIDIA RAID setup utility. Select Striping in the RAID Mode filed (Figure 23). Move to the Free Disks section with the TAB key. Select the desired disk and use the RIGHT ARROW key to add it to Array Disks menu.
  • Page 16 Ác Step 5: Install the NVIDIA nForce Driver Package while in Windows 2000 and reboot the system. Go to Åé START>Programs>Nvidia Corporation and select NVRAID manager. You should see the single disk RAID array (in striping mode) that was created from the boot disk. Select the single boot disk RAID Array ¤¤...
