Revision: 0 (September 14, 2016)
Operator's Manual
Tri-Star Type III Ambulance
MODEL TS63
September 14, 2016
Revision: 0
TRI-STAR INDUSTRIES LIMITED
88 Forest Street, Yarmouth, Nova Scotia, Canada, B5A 4G6
Phone: +1 (902) 742-9254 | Fax: +1 (902) 742-7632
www.tri-star.ca
Tri-Star Industries Limited | Ambulance Operator's Manual
Page | 1
Advertisement
Table of Contents
Summary of Contents for Tri-Star TS63
- Page 1 Tri-Star Type III Ambulance MODEL TS63 September 14, 2016 Revision: 0 TRI-STAR INDUSTRIES LIMITED 88 Forest Street, Yarmouth, Nova Scotia, Canada, B5A 4G6 Phone: +1 (902) 742-9254 | Fax: +1 (902) 742-7632 www.tri-star.ca Tri-Star Industries Limited | Ambulance Operator’s Manual Page | 1...
- Page 2 If you have any questions on the operation or maintenance of this ambulance, do not hesitate to call us. Phone Number………………………………... (902) 742-9254 Fax Number……………………………………… (902) 742-7632 Email………………………………………………... info@tri-star.ca Website……………………………………………. www.tri-star.ca Mailing Address………………………………… 88 Forest St, Yarmouth, Nova Scotia, B5A 4G6 Tri-Star Industries Limited | Ambulance Operator’s Manual Page | 2...
-
Page 3: Table Of Contents
EMT light ................................11 Cabinet Light ..............................11 Suction................................11 Patient Compartment Control Display – Rear Heating Ventilation and Air Conditioning (HVAC) ......12 Set Default ................................12 Max Output ................................ 12 Tri-Star Industries Limited | Ambulance Operator’s Manual Page | 3... - Page 4 Number Pad Lock ............................... 16 Code red ..................................16 110 Volt System ................................. 17 Shoreline ................................17 Inverter / Charger ..............................17 110v outlets ................................17 Heater 110v ................................17 Tri-Star Industries Limited | Ambulance Operator’s Manual Page | 4...
-
Page 5: Vehicle Passenger & Cargo Capacity
Revision: 0 (September 14, 2016) Vehicle Passenger & Cargo Capacity GVWR 5670 kg 12500 lbs MAXIMUM DRIVER & PASSENGER CAPACITY 7 People MAXIMUM CARGO CAPACITY 1590 kg 3511 lbs Tri-Star Industries Limited | Ambulance Operator’s Manual Page | 5... -
Page 6: Operators Manual
The Tri-Star Electronic Control System operates the ambulance electrical conversion including emergency lighting, siren, internal lighting, heating and air-conditioning, etc. The Tri-Star Electronic Control System is a state of the art multiplex system primarily consisting of solid state control modules and control display screens. The control display screens are located in the cab and patient compartment and include buttons to control various ambulance electrical components. -
Page 7: Sleep-Display On Mode
12 volts. This is achieved by either running the engine or providing power to the shoreline. Note that the communications equipments and 12 volt outlets are connected directly to the deep cycle battery; therefore remain active in Down Mode. Tri-Star Industries Limited | Ambulance Operator’s Manual Page | 7... -
Page 8: Control Displays
Pressing the Battery boost button while the ignition key is in the rum position will connect the boost battery to the chassis battery for ten seconds to provide supplemental power for starting the engine. Tri-Star Industries Limited | Ambulance Operator’s Manual Page | 8... -
Page 9: Traffic Advisor
Pressing the Anti-theft button will allow the user to remove the ignition key while keeping the engine running. While Anti-theft is active and engaged, it can be deactivated if the park brake is released, service brake applied or the ignition key is turned to the run position. Tri-Star Industries Limited | Ambulance Operator’s Manual Page | 9... -
Page 10: Cab Control Display Indicators
The driving lights will only function when the vehicle’s lights are on and in the “High Beam” setting while the engine is running and not in shift park. Tri-Star Industries Limited | Ambulance Operator’s Manual Page | 10... -
Page 11: Patient Compartment Control Displays - Ambulance Electrical Switches
Pressing the Cabinet light a fourth time turns the Cabinet light off. Suction Pressing the Suction button once turns on the Suction pump. Pressing the Suction button a second time turns off the Suction pump. Tri-Star Industries Limited | Ambulance Operator’s Manual Page | 11... -
Page 12: Patient Compartment Control Display - Rear Heating Ventilation And Air Conditioning (Hvac)
Press the button four times to turn the fan on MEDIUM settings. Press the button five times to turn the fan on Lo settings. Press the button six times to turn the fan OFF. Tri-Star Industries Limited | Ambulance Operator’s Manual Page | 12... -
Page 13: Manual Mode
If conversion battery voltage drops below 8v the clock will flash 00:00:00 until the time is set. To set the time; the cab control display must be used through the Menu System (see below). Tri-Star Industries Limited | Ambulance Operator’s Manual Page | 13... -
Page 14: Siren - Whelen
Activating the MAN button results in the AIRHORN tone until the MAN button is released. Activating the HORN RING input results in the AIRHORN tone until the HORN RING input is released. Tri-Star Industries Limited | Ambulance Operator’s Manual Page | 14... - Page 15 Pressing the MAN button will result in the AIRHORN tone until the MAN button is released. Pressing the HORN RING button will result in the AIRHORN tone until the HORN RING button is released. Tri-Star Industries Limited | Ambulance Operator’s Manual Page | 15...
-
Page 16: Spotter Switch
The vehicle is fitted with a Code red switch located under the EMT area display. Code red will show on all displays until either the vehicle is placed in park, or the switch is held for about 2 seconds. Tri-Star Industries Limited | Ambulance Operator’s Manual Page | 16... -
Page 17: 110 Volt System
- 110v outlets are GFI protected. GFI is located on inverter outlet. - 1 or more outlets are lighted when supplied 110v power. Heater 110v - A heater is powered from the shoreline through a breaker in the 110v electrical box. Tri-Star Industries Limited | Ambulance Operator’s Manual Page | 17...
