Belgard DESIGNFORMS BBQ SURROUND COMBO Installation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
BBQ SURROUND COMBO -
COUNTER COMBO A & 1 SHELVING UNIT

Advertisement

loading
Need help?

Need help?

Do you have a question about the DESIGNFORMS BBQ SURROUND COMBO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Belgard DESIGNFORMS BBQ SURROUND COMBO

  • Page 1 BBQ SURROUND COMBO - COUNTER COMBO A & 1 SHELVING UNIT...
  • Page 2 BBQ SURROUND COMBO - COUNTER COMBO A & 1 SHELVING UNIT 251/2" 25.50” 59" 59.00” 371/8" 37.10” 251/2" 30" 25.50” 30.00” 371/8" 37.10” COMPONENTS 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” Counter Combo A - Single Counter - 1 Shelving Unit & 1 Solid Unit (x1) Shelving Unit (x1)

  • Page 3: Required Tools

    BBQ SURROUND COMBO - COUNTER COMBO A & 1 SHELVING UNIT REQUIRED TOOLS MEASURING TAPE CARPENTER SQUARE RUBBER MALLET LEVEL DRILL DEEP HEX SOCKET SOCKET ADAPTOR SKILL SAW 7/16" WITH 1/4" DRIVE 1/4" HEX SHANK TO 1/4" DRIVE SAFETY EQUIPMENT SAFETY BOOTS GLOVES SAFETY GLASSES...
  • Page 4 BBQ SURROUND COMBO - COUNTER COMBO A & 1 SHELVING UNIT BASE PREPARATION ALWAYS LEVEL GROUND BEFORE INSTALLATION ON NEW OR EXISTING PATIO SLAB OR PAVER BEDDING SAND 1" COMPACTED AGGREGATES 6"- 8" SOIL ON POURED CONCRETE REINFORCED POURED CONCRETE FOUNDATION 2" COMPACTED AGGREGATES 6"- 8"...

  • Page 5: Tips And Tricks

    TIPS & TRICKS READ ALL INSTRUCTIONS BEFORE ASSEMBLY PREBUILD: • Prebuild all hardware prior to starting build. • When assembling hardware SNAP the bolt into place with the plastic sliders. Pressing down on something flat and hard will help. (Fig. A) •...
  • Page 6 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” 251/2" 25.50” 59" 59.00” 371/8" 37.10” COMPONENTS Build side by side. Wood top construction instructions follow in this guide. Single Counter (x1) Single Shelf (x1)
  • Page 7 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” 2" x 6" x 10' 2" x 4" x 8' OUTDOOR A #8 1¼" PRESSURE PRESSURE SILICONE DECK SCREW TREATED WOOD TREATED WOOD B #8 21/2"...
  • Page 8 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 2" x 2" x 8' 2' x 4' x ¾" 37.10” PRESSURE PLYWOOD TREATED WOOD WOOD CUTS Shelves only. 4 = 23" 5 = 19 x 231/2" 6 = 21 x 231/2"...
  • Page 9 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” BRACKET A BRACKET A1 BRACKET A2...
  • Page 10 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” BRACKET C BRACKET C1 ASSEMBLY I...
  • Page 11 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” Install Bracket A flat side up to hold the shelf wood. 90º 90°...
  • Page 12 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 13 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” 11" Install Bracket A flat side up to hold the shelf wood.
  • Page 14 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” 11"...
  • Page 15 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” Install Bracket A flat side up to hold the shelf wood.
  • Page 16 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” 6" 6” Install Bracket A flat side up to hold the shelf wood.
  • Page 17 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” 6" 6” Install Bracket A flat side up to hold the shelf wood.
  • Page 18 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” Install Brackets C and C1 flat side up to hold the shelf wood.
  • Page 19 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” 6" 6” Install Brackets C and C1 flat side up to hold the shelf wood.
  • Page 20 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 21 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 22 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 23 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 24 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 25 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 26 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 27 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 28 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 29 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 30 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 31 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” Next, build the enclosed single counter flush with the shelf unit.
  • Page 32 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” COMPONENTS Large Panel (x12) Hardware Kit (x3) 12" x 24"...
  • Page 33 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” BRACKET A BRACKET C...
  • Page 34 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” 90º 90° 6" 6”...
  • Page 35 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” d1 = d2 d1 = d2...
  • Page 36 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 37 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 38 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 39 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 40 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 41 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” 31/2" 31/2" 35/8" Center 2" x 4" between sides when constructing top 59"...
  • Page 42 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 43 COUNTER COMBO A - 1 SHELVING UNIT & 1 SOLID UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” Place the grill in position to line up the next build before starting construction of the single counter shelving unit.
  • Page 44 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” 251/2" 30" 25.50” 30.00” 371/8" 37.10” COMPONENTS Large Panel (x9) Small Panel (x2) Hardware Kit (x3) 12" x 24" 6" x 24"...
  • Page 45 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” A #8 1¼" 37.10” DECK SCREW B #8 21/2" DECK SCREW 2" x 6" x 10' 2" x 4" x 8' 2" x 2" x 8' 2' x 4' x ¾" PRESSURE PRESSURE PRESSURE...
  • Page 46 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” Install Bracket A flat side up to hold the shelf wood. 90º 90°...
  • Page 47 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 48 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” 6" Install Bracket A flat side up to hold the shelf wood.
  • Page 49 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” 6"...
  • Page 50 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” Install Bracket A flat side up to hold the shelf wood.
  • Page 51 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” 6" 6” Install Bracket A flat side up to hold the shelf wood.
  • Page 52 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” 6" 6” Install Bracket A flat side up to hold the shelf wood.
  • Page 53 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” Install Brackets C and C1 flat side up to hold the shelf wood.
  • Page 54 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” 6" 6” Install Brackets C and C1 flat side up to hold the shelf wood.
  • Page 55 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 56 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 57 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 58 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 59 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 60 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 61 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 62 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 63 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 64 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 65 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 66 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 67 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” 35/8" 3.625” 31/2" 3.5” 30" 18.¼" 31/2" 3.5” Center 2" x 4" between sides when constructing top...
  • Page 68 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10”...
  • Page 69 SINGLE COUNTER - SHELVING UNIT 25.50” 59.00” 25.50” 30.00” 37.10” 37.10” © Copyright 2022 Oldcastle, APG Inc. All Rights Reserved. BEL22-D-8950...
