IMPORTANT: The following applies when downloading videos to a Computer.
1). Plug the USB Cable into the USB port on the side of the LE15; then plug into an USB port on
the computer
2). Once the camera is plugged in, you will see it's looking for a password;
press the (OK) six times which is the password: 000000
3). Once the password is accepted; the computer will automatically define the camera as a
drive (i.e. D:\) - Whatever the next drive letter is on your computer
4). Go to the computer and you can view, copy, or delete any videos / pictures on the LE15
NOTE: Do you try to download using the dock. This is another security feature of the LE15 and
is not available on the LE15 Body Cameras unless VeriPic Software was purchased.
QUESTIONS: FORCE PROTECTION VIDEO - 855.746.0245

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LE15 and is the answer not in the manual?

Questions and answers

Summary of Contents for Force Protection Video LE15

  • Page 1 IMPORTANT: The following applies when downloading videos to a Computer. 1). Plug the USB Cable into the USB port on the side of the LE15; then plug into an USB port on the computer 2). Once the camera is plugged in, you will see it’s looking for a password;...
  • Page 2 LE15 can also take up to 20 high-resolution snapshots, which, together with video, can be viewed on backlit, 2-inch LCD color screen or on an HDTV screen using a HDMI connector. Security protocols of the device are secure to prevent accidental deletion of evidence or modification of system settings.
  • Page 3: Technical Specifications

    LE15 Body Worn Camera – Force Protection Video 2. Technical Specifications Camera Sensor 5MP CMOS Wide Angle 140 degree wide angle lens Video 2560X1080 30p/ 2304x1296 30p/ 1920x1080 30p /1280x720 60p /1280x720 Video Resolution 30p / 848x480 60p Video Compression H.264/MPEG4...
  • Page 4 LE15 Body Worn Camera – Force Protection Video Working Temperature -40~60 degrees Celsius Storage temperature -20~55 degrees Celsius Dimension 3.54" x 2.17" x 1.10" Weight 175g Charging dock, USB cable, Adapter, User Manual, Universal metal 360 Degree Standard Accessories Rotatable Clip, Shoulder Clip 3.
  • Page 5 LE15 Body Worn Camera – Force Protection Video Records clear image in low light situation. Enable Clear face view with up to 10 4. Infrared LEDs meters 5. 6. Light Sensor Detect changes in light and auto turn on IR for low-light recording 7.
  • Page 6 LE15 Body Worn Camera – Force Protection Video Red blinking record status icon indicates camera is on recording, white solid is in Record Status standby mode. Video Recording Time Recorded time of current clip Battery Charge Current battery charge level...
  • Page 7 LE15 Body Worn Camera – Force Protection Video Setting Description Options 2304×1296 30P 1920×1080 30P 1440×1080 30P 1280×720 60P Resolution The image resolution for video 1280×720 30P 848×480 60P 848×480 30P 720×480 30P 32M (7600×4275 16:9) 30M (7304×4104 16:9) 28M (7056×3968 16:9) 25M (6664×3752 16:9) 23M...
  • Page 8 LE15 Body Worn Camera – Force Protection Video When on, camera will overwrite the oldest video file with Loop Recording Off, On the most current video file once its memory is full. This setting can be selected only when car DVR mode is on.
  • Page 9: Infrared Night Vision

    LE15 Body Worn Camera – Force Protection Video Use this to return camera to its original settings. This does Default setting O (Yes), X (No) not erase the memory. Snap Shot Turns the PHOTO option on / off O (Yes), X (No) 5.
  • Page 10: Video Recording

    LE15 Body Worn Camera – Force Protection Video 5.6 Video Recording In standby mode, PRESS record ( ) button, indicator LED flashes Alternate Red and Green, then camera “beep” and vibrates, starts video recording. If the voice is on, camera will start video recording with indication voice.
  • Page 11 6. Download Videos / Photos 1) Plug the USB Cable into the USB port on the side of the LE15; then plug into an USB port on the computer 2) Once the camera is plugged in, you will see it’s looking for a password;...
