USER'S GUIDE
Wearable Sleep Quality Tracker with Wellness & Activity Indicators
Includes Smart Soother & Audio Monitor + Wi-Fi HD Camera
Guardian Cam
The features described in this user's guide are subject to modifications without prior notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Guardian Cam and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hubble Guardian Cam

  • Page 1 USER’S GUIDE Wearable Sleep Quality Tracker with Wellness & Activity Indicators Includes Smart Soother & Audio Monitor + Wi-Fi HD Camera Guardian Cam The features described in this user’s guide are subject to modifications without prior notice.
  • Page 2 Please retain your original dated sales receipt for your records. For warranty service of your Hubble product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is requested but not required for warranty coverage.
  • Page 3 Overview of Guardian Cam Base Station Charging indicator for Smart Sensor Brightness up Charging pins Brightness down 10. Power ON-OFF switch Night light 11. Pairing LED indicator ConnectChat™ 12. Pair Button (HubbleClub and Soothing sound BT speaker) Volume down 13. Power Socket Volume up 14.
  • Page 4 11. Temperature Sensor Magnetic mount Important guidelines for installing your Guardian Cam • The signal strength may also be reduced by other solid structures, like walls, or by radio or electrical equipment, such as TVs, computers, cordless or mobile phones, fluorescent lights or dimmer switches.

  • Page 5: Table Of Contents

    3.2 Connecting the Power Supply for the Camera Unit ......7 3.3 Power on Base Station ...........8 4. Setting up Guardian Cam to HubbleClub by Hubble Connected App ......................8 4.1 Install HubbleClub by Hubble Connected App .........8 4.2 View on Compatible Smartphones and Tablets ......... 8 4.3 Connect Base Station to HubbleClub by Hubble Connect App ..9...

  • Page 6: Safety Instructions

    • Do not use Guardian Cam as an excuse for unsafe sleep habits. • Do not use Guardian Cam as a replacement for or in lieu of adult care. The guardian is an aid. It is not a substitute for adult supervision.

  • Page 7: System Requirements Of Smart Device

    2. System Requirements of Smart Device Smartphones/Tablets: Android™ and iOS® only. Minimum System Requirement: iOS 12.0, Android 8.0, BT 4.2. 3. Getting Started 3.1 (Optional) Fixing magnetic mount on the wall • Mark the position of the screw holes on the wall. •...

  • Page 8: Power On Base Station

    HubbleClub App to create your HubbleClub account. 4.2 View on Compatible Smartphones and Tablets Connect to Internet Compatible Camera Unit ® via Wi-Fi Viewing Devices Setting up Guardian Cam to HubbleClub by Hubble Connected App...

  • Page 9: Connect Base Station To Hubbleclub By Hubble Connect App

    1. Open the HubbleClub by Hubble Connected App on your compatible smartphone or tablet. 2. Select Wellness on home page, then tap Guardian Cam and Guardian Camera to access to camera setup, follow the in-app instructions to connect to your device.

  • Page 10: Operation Of Base Station

    5.3 ConnectChat™ ConnectChat™ in Guardian Cam is designed in such a way that both parent and child can send voice recorded messages to each other. Tap and hold ConnectChat™ icon until a beep tone is heard from the Base Station, release tapping and start recording a voice message.

  • Page 11: Use Base Station As A Bt Speaker

    5.4 Use Base Station as a BT Speaker Press and hold the Pair button on the bottom of Base Station for 2s. You will hear a beep tone and the Pair LED indicator blinks in blue color when the device enters BT pairing mode. Go to the Set-Up menu of your mobile phone.

  • Page 12: Using Of Smart Sensor

    6. Using of Smart Sensor 6.1 Device Power and Charging Install the power adaptor and insert the plug into Base Station. Power on and off using the switch under the device. Charge the device by laying the sensor on the charging pins of the base station.

  • Page 13: Device Placement

    6.2 Device Placement Place the sensor on the smallest part of your child’s ankle just above the ankle bone. The sensor must be facing the outside of the ankle (as shown in the picture below). Use the Velcro on the straps to secure the device in place.

  • Page 14: Disposal Of The Device (Environment)

    WIFI signal. Network issue • If Guardian Cam is showing offline on the APP, restart the unit. You can also try closing the APP and open it again. • If the issue persists, factory reset the unit by holding down the Hubble Pair button for 10 seconds.
  • Page 15 Android™ device. iOS devices? – Select Search – Type in “HubbleClub by Hubble Connected” – The results will show the Hubble – Select to install it iOS Device: – Open the App Store™ – Select Search – Type in “HubbleClub by Hubble Connected”...
  • Page 16 Please wait a few minutes and refresh your email account. HubbleClub Cannot find my product There are more than one Hubble App. model on APP. Check if you download correct App “HubbleClub By Hubble Connected” and select Wellness.
  • Page 17 Station or using the HubbleClub App. Feature Cannot hear sounds, Increase volume on Base Station. music, or stories. Increase volume in Hubble Club. Sounds, Music, or Story is paused. Feature Cannot pair to BT. Make sure you are pressing the Pairing button on the bottom of the Base Station.

  • Page 18: General Information

    • Damage caused by or resulting from contact with foreign substances, including, but not limited, to liquid, water, rain, humidity, perspiration, sand, dirt, and/or food; • Damage caused by or resulting from the use of Non-Hubble Smart Nursery branded or certified Products or Accessories or other peripheral equipment;...
  • Page 19 DURATION OF THIS LIMITED WARRANTY. REPAIR OR REPLACEMENT IS YOUR SOLE AND EXCLUSIVE REMEDY AGAINST HUBBLE AND Hubble Smart Nursery. IN NO EVENT SHALL HUBBLE OR Hubble Smart Nursery’s LIABILITY TO REPAIR OR REPLACE YOUR PRODUCT OR ACCESSORY EXCEED THE ORIGINAL PURCHASE PRICE OF THE PRODUCT AND ACCESSORY AND HUBBLE AND Hubble Smart Nursery’s TOTAL LIABILITY...
  • Page 20 What will HUBBLE do? HUBBLE or its authorized distributor at its sole discretion will, at no charge, repair or replace any Products or Accessories that do not conform to this Warranty. In the event that replacement is necessary to remedy a defect...
  • Page 21 HUBBLE or representations made by any agent, employee or staff of HUBBLE, that may have been made in connection with your purchase of any Product and/or Accessory. FCC and IC regulations (FCC Part 15)

  • Page 22: Technical Specifications

    10. Technical Specifications BASE STATION AND SMART SENSOR Wi-Fi version 802.11 b/g/n, 2.4GHz BT 4.2 Maximum radio-frequency 20dBm power Operating Temperature F - 104 4 Ω , 5W Speaker Type Night Light RGB, 7 colors, and auto cyclic mode Volume Control 8 Levels Brightness Control 8 Levels...
  • Page 23 CAMERA UNIT Wi-Fi version 802.11 b/g/n Frequency 2400 MHz to 2483.5 MHz Image sensor color CMOS 2M Pixels IR LED 8 pcs Maximum radio- 20dBm frequency power Operating F - 104 Temperature Power Adaptor Input: 100-240V AC, 50/60Hz, 300mA; Output: 5.0V DC, 1000mA Technical Specifications...
  • Page 24 Manufactured, distributed and sold by Hubble Baby . Apple logo is trademark of Apple Inc., (HK) Limited registered in the U.S. and other countries. App Store is a service mark of Apple Inc. Google Play and Android are trademarks of Google Inc. Wi-Fi is a trademark of the Wi-Fi Alliance.
