Summary of Contents for Amit ALP3C1810/A1
- Page 1 ALP3C1810/A1 Information LED panel for rolling stock Operation manual Version 1.01 alp3c1810a1_g_en_101...
- Page 2 ALP3C1810/A1 AMiT, spol. s r.o. does not provide any warranty concerning the contents of this publication and reserves the right to change the documentation without any obligation to inform about it. This document can be copied and redistributed under following conditions: 1.
-
Page 3: Table Of Contents
ALP3C1810/A1 Contents History of revisions ..................4 Related documentation ................... 4 Introduction ..................5 Technical parameters ................6 2.1. Dimensions ..................... 8 2.2. Recommended drawing symbol ..............8 2.3. Temperature dependence ................9 Conformity assessment ..............10 3.1. Other tests ....................11 Power supply .................. -
Page 4: History Of Revisions
ALP3C1810/A1 History of revisions Document name: alp3c1810a1_g_en_101.pdf Author: Ondřej Rott Revision Date Changes 25. 6. 2014 New document Related documentation Application Note AP0016 – Principles of using RS485 interface file: ap0016_en_xx.pdf alp3c1810a1_g_en_101 4/20... -
Page 5: Introduction
ALP3C1810/A1 1. Introduction ALP3C1810/A1 is an indoor information LED panel intended to be built-in to rolling stock interior. Device is designed in accordance with EN 50155:2007 standard. LED panel is shipped from production with loader and AMiT software. Viewing area (1296 ×... -
Page 6: Technical Parameters
ALP3C1810/A1 2. Technical parameters (1296 × 90) mm Viewing zone Viewing area (216 × 15) pixels Resolution LED grid 6 mm LED colour Red, 633 nm typ. Luminance Typ. 200 cd/m 120 ° *) Viewing angle Note: *) Luminance drop to 50 % at viewing angle border. - Page 7 ALP3C1810/A1 Mechanics Mechanical design Steel tub, casing with covering polycarbonate Colour Black fine matte RAL 9005 1 × for power supply + RS485 Inlet cables 1 × for geographic addressing Inlet cables length 4 × M5 nuts on the sides Mounting 6 ×...
-
Page 8: Dimensions
ALP3C1810/A1 2.1. Dimensions Inlet cables length is 1 m. 1296 1322 Fig. 1 - Information panel ALP3C1810/A1 outer dimensions 2.2. Recommended drawing symbol Following drawing symbol recommended information panel ALP3C1810/A1. ALP3C1810/A1 X1 - PWR X2 - ID GND-RS Fig. 2 - Recommended drawing symbol for ALP3C1810/A1... -
Page 9: Temperature Dependence
ALP3C1810/A1 2.3. Temperature dependence Information panel is equipped with internal temperature sensor; depending on measured temperature is controlled the maximum brightness according to following table. Internal temperature Function -40 °C to 45 °C Full brightness 45 °C to 85 °C Linear brightness decreasing 85 °C... -
Page 10: Conformity Assessment
ALP3C1810/A1 3. Conformity assessment The equipment meets the claims of Czech government decree NV616/2006; the conformity assessment has been performed in accordance with harmonized standard EN 50121-3-2:2006 in obligatory scope given by EN 50155:2007 Tested in accordance Type of test... -
Page 11: Other Tests
ALP3C1810/A1 3.1. Other tests This product was assessed and approved for use in railway applications according to standards: Tested in accordance Type of test Classification with standard EN 50155:2007 Electronic equipment used on rolling Complies stock Railway applications – Electromagnetic... -
Page 12: Power Supply
ALP3C1810/A1 4. Power supply Information panel ALP3C1810/A1 can be powered only with DC supply voltage. Supply voltage is connected to X1 connector with 6 pins; connector is also common for RS485 interface. Connector Signal Signal description Supplying connector Device chassis... -
Page 13: Communication Lines And Peripherals
5. Communication lines and peripherals 5.1. Geographic addressing Information panel ALP3C1810/A1 geographic address is set by interconnecting the address inputs ADx with COM pin on connector X2. Combination of bits AD1 (LSB) to AD4 (MSB) represents by itself the binary form of geographic address. -
Page 14: Light Sensor
ALP3C1810/A1 Table of Logical levels Address addresses Examples Leaving the X2 connector unwired causes that address is set to 64. By connecting COM, AD2 and AD3 pins is the address set to 70. 5.2. Light sensor Information panel is equipped with light sensor that is used for measuring of ambient light. -
Page 15: Rs485
ALP3C1810/A1 5.3. RS485 The information panel ALP3C1810/A1 contains single galvanic separated interface RS485. RS 485 line is connected to 6-pin connector X1, which is also common for panel powering. RS485 Connector Signal Signal description connector RS485 line, signal A wiring... - Page 16 ALP3C1810/A1 Fig. 10 - End station terminator connection Termination resistor Rz must be connected to X1 connector counterpart, type WAGO 231 2306/026 000. Pins of terminating resistor must be covered with protective sleeve on all length. WAGO231-2306/026-000 Fig. 11 - Terminating resistors connection...
-
Page 17: Mounting
ALP3C1810/A1 6. Mounting Information panel is designed to be mounted onto rail coach interior with four mounting holes located on the panel sides, or with six mounting holes located on the panel back. Information panel is attached by bolts, fastened to M5 nuts. -
Page 18: Ordering Information And Completion
ALP3C1810/A1 7. Ordering information and completion Information ALP3C1810/A1 Complete, see chapter Completion panel 7.1. Completion ALP3C1810/A1 Part Quantity Information LED panel WAGO 231-306/102-000 X1 connector counterpart WAGO 231-305/102-000 X2 connector counterpart Routine testing protocol Insulation testing protocol Quality and completion certificate 7.2. -
Page 19: Maintenance
ALP3C1810/A1 8. Maintenance Warning The maintenance mentioned above can be performed by manufacturer or authorized service only. Cleaning Cleaning of front polycarbonate should be made by dry or moisten cloth and such cleaning agents which does not cause scratching of viewing surface. -
Page 20: Waste Disposal
ALP3C1810/A1 9. Waste disposal Electronics The disposal of electronics is subject to the regulations on handling electrical disposal waste. The equipment must not be disposed of in common public waste. It must be delivered to places specified for that purpose and recycled.
