- Page 1 USER MANUAL EX- AURA001 EX- AURA002 Expion360 AURA Manual Rev A 03/13/2023...
-
Page 2: Disclaimer
Quality • With all the Li-ion players in the market, Expion360 strives to ensure that our products meet the highest quality standards to maintain our advantage over the competition. Expion360 battery uses cylindrical 26650, stainless steel encased LiFePO cells. The cells are UL 1642 recognized (File No. MH64383). They are certified to the highest standard in safety and performance. -
Page 3: Warnings
• DO NOT use any third- party electrical parts with the unit. • DO NOT expose the unit to dirt, fire, liquid, extremely hot, or extremely cold. • DO NOT operate/store the unit outside the stated specifications of the manual. Expion360 AURA Manual Rev A 03/13/2023... -
Page 4: Table Of Contents
Charging ..............................11 Discharging ..............................12 Storage ................................ 12 Warning ............................... 13 Trouble Shooting............................13 Bluetooth and App ..........................13 Warranty ............................14 WARRANTY DISCLAIMER ..........................14 LEGAL RIGHTS .............................. 14 CLAIM ................................14 Expion360 AURA Manual Rev A 03/13/2023... -
Page 5: Overview
120W Portable Solar Panel (EX-PSP-120W) 10A MPPT Solar Charger (EX-10ASC) AURA Powercap 800 30A MPPT Solar Charger (EX-30ASC) 3. Cables Solar Panel Extension Cable – 8ft (EX-CA-SAE001) Solar Panel Extension Cable – 16ft (EX-CA-SAE002) Expion360 AURA Manual Rev A 03/13/2023... -
Page 6: Unit Diagram
1.2 Unit Diagram Front View • Back View • PD Port On/Off Switch USB-C Port Display USB-A Port Mounting Bracket Nut Insert 12V DC Port Vent DC/Converter Switch 110V AC Output Input Port AC/Inverter Switch Expion360 AURA Manual Rev A 03/13/2023... -
Page 7: Display
1.3 Display Expion360 AURA Manual Rev A 03/13/2023... -
Page 8: Installation
• Before installation, make sure all the switches are in the OFF position (flush and LED off). P1 Make sure Aura and the Expion360 battery are in the same orientation. The POSITIVE terminal of ○ Aura must align the POSITIVE terminal 1 on the battery. - Page 9 Fasteners for securing the Mounting Base Plate are not included. Depending on the different types of surfaces, use the proper fasteners. Drill pilot holes if needed and follow the fastener manufacturer's guide. Follow the same procedure for installing AURA Powercap 800 with Expion360 Group 27 batteries. Expion360 AURA Manual Rev A...
-
Page 10: Specifications - Aura Powercap 600
Protection DC Input Over Current 110 A DC Input Low Voltage 10.6 V DC Input Over Voltage 15.0 V AC Output Over Current 6 Aac Input Short Circuit Internal Fused Output Short Circuit Programmed Expion360 AURA Manual Rev A 03/13/2023... -
Page 11: Operation
3.1 Initialization Depending on your application, AURA Powercap 600 and 800 can be installed with different capacities of Expion360 Group 24 and 27 batteries. The pre-set total capacity on AURA Powercap 600 or 800 may not match your installation. Expion360 Group 24 battery has capacities of 60, 80 and 95Ah. -
Page 12: Discharging
DO NOT exceed the power rating on each port. Always check the power rating of the load before connecting. 3.4 Storage Power off the unit and store at 14°F to 104°F (-10°C to 40°C) and RH 5% to 90%. Always check the voltage and recharge the unit before the next trip. Expion360 AURA Manual Rev A 03/13/2023... -
Page 13: Warning
• Warranty voided. Contact Expion360 technical support for further assistance. 4. Bluetooth and App Please refer to the Expion360 App Walkthrough for details. The walkthrough can be found at expion360.com > Support (drop-down tab) > Customer Support https://expion360.com/pages/customer-support Expion360 AURA Manual... -
Page 14: Warranty
Valid warranty claims can only be applied once. Upon receiving the unit, Expion360 will repair or replace the unit if defects in material or workmanship are determined to be the cause of malfunction, or Expion360 will deny or charge a reasonable amount for repairment and shipping.
