Electric Patio Sweeper
L246
v01: 26/10/22
Please read and retain these instructions for future reference
Power Details:
Accessories:
Use: This item requires two hands to use safely.
Please read this instruction manual thoroughly before starting and ensure you are familiar with
the operation of your new Electric Patio Sweeper
ALWAYS USE HEAD, EYE AND EAR PROTECTION EQUIPMENT AND SAFETY SHOES AND HAND
VOLTAGE: 230V-240V a.c./50HZ
NO LOAD SPEED: 1200/MIN
MAX. BRUSH DIAMETER: 100MM
1x Nylon brush
1x Steel brush
RECOMMENDED FOR PERSONS OVER 18 YEARS OF AGE.
Dimensions
(H) 125 x (W) 22 x (D) 18cm
WEIGHT (including cable) 1.9KG
5M LONG STRETCH CABLE
Material
PP/NYLON/ALUMINIUM/COPPER/STEEL/RUBBER/ IRON
Technical Data
Model No.
Voltage / Frequency
Input Power
No Load Speed
Max. brush diameter
Net Weight
A-weighted sound pressure level
L
PA
A-weighted sound power level
L
WA
Uncertainty K
Guaranteed sound power
-
level
(in accordance with
-
2000/14/EC)
Vibration(in accordance with EN
28662-1)
Uncertainty K
GLOVES
DT3001
230V-240V~ , 50Hz
150W
1,200/min
100 mm
1.60kg
67.90dB(A)
82.44dB(A)
3dB(A)
96dB(A)
Main handle:
2
0.4904m/s
2
1,5 m/s
Advertisement
Table of Contents
Summary of Contents for Victor Tools L246
-
Page 1: Technical Data
Electric Patio Sweeper L246 v01: 26/10/22 Please read and retain these instructions for future reference Dimensions (H) 125 x (W) 22 x (D) 18cm WEIGHT (including cable) 1.9KG 5M LONG STRETCH CABLE Material PP/NYLON/ALUMINIUM/COPPER/STEEL/RUBBER/ IRON Technical Data Model No. DT3001... -
Page 2: Table Of Contents
Electric Patio Sweeper Instructions for Use L246 Please read and retain these instructions for future reference v001: 26/10/22 Contents Technical Data ..............................1 Symbol Explanation ..............................3 WARNING! ................................3 Read the user instructions carefully to make sure you understand all the controls and what they do..3 Remove plug from the mains immediately if the cable is damaged or cut. -
Page 3: Symbol Explanation
Electric Patio Sweeper Instructions for Use L246 Please read and retain these instructions for future reference v001: 26/10/22 Try to minimize the impact of vibration and noise. Exemplary measures to reduce vibration exposure include wearing gloves while using the tool, limiting working time, and using accessories in good condition. -
Page 4: General Power Tool Safety Warnings
Electric Patio Sweeper Instructions for Use L246 Please read and retain these instructions for future reference v001: 26/10/22 The use of eye protection is recommended. Head protection must be worn. Keep away from electric cables, whether overhead, on the ground or along outdoor buildings. - Page 5 Electric Patio Sweeper Instructions for Use L246 Please read and retain these instructions for future reference v001: 26/10/22 e) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep the cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
- Page 6 Electric Patio Sweeper Instructions for Use L246 Please read and retain these instructions for future reference v001: 26/10/22 b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
-
Page 7: Specific Safety Rules
Electric Patio Sweeper Instructions for Use L246 Please read and retain these instructions for future reference v001: 26/10/22 SPECIFIC SAFETY RULES Reduce noise generation and vibration as much as possible! Use only equipment that is in good condition. Maintain and clean the equipment regularly. Adapt your way of working to the equipment. -
Page 8: Operating Controls
Electric Patio Sweeper Instructions for Use L246 Please read and retain these instructions for future reference v001: 26/10/22 Operating Controls 1. Auxiliary handle 2. Main handle 3. Switch trigger 4. Cable strain-relief clamp 5. Motor body 6. Guard hood 7. Brush 8. - Page 9 Electric Patio Sweeper Instructions for Use L246 Please read and retain these instructions for future reference v001: 26/10/22 • Assemble motor housing and middle tube (see Figure 2) • Insert two parts together, fix two parts by the screw. • Assemble auxiliary handle (see Figure 3) •...
-
Page 10: Operation
Electric Patio Sweeper Instructions for Use L246 Please read and retain these instructions for future reference v001: 26/10/22 OPERATION The tool can be plugged into any socket-outlet (with 230 V AC) that is equipped with a 10A fuse or higher. The socket- outlet has to be safeguarded by an earth leakage circuit breaker (ELCB). -
Page 11: Plug Wiring (Uk & Ireland)
Electric Patio Sweeper Instructions for Use L246 Please read and retain these instructions for future reference v001: 26/10/22 recommend that you clean the equipment immediately after you use it. Clean the equipment regularly with a damp cloth and some soft soap. Do not use cleaning agents or solvents; these may be aggressive to the plastic parts in the equipment. - Page 12 Electric Patio Sweeper Instructions for Use L246 Please read and retain these instructions for future reference v001: 26/10/22 Notes Commonly recycled and collected from household recycling bins (packaging tape itself not recyclable but does not interfere with cardboard) Page no. 12...
-
Page 13: Uk & Eu Declaration Of Conformity
Electric Patio Sweeper Instructions for Use L246 Please read and retain these instructions for future reference v001: 26/10/22 UK & EU DECLARATION OF CONFORMITY We, Coopers of Stortford hereby declare under our sole responsibility, that the product named below has been designed to comply with all relevant sections of the below referenced standards and directives: - Description &... - Page 14 Electric Patio Sweeper Instructions for Use L246 Please read and retain these instructions for future reference v001: 26/10/22 The Test reports for this item are available from: Coopers of Stortford, 11 Bridge Street, Bishop’s Stortford, Hertfordshire, CM23 2JU Bill Stewart – Technical Manager CUSTOMER SERVICES: •...
