- Page 1 DATMF SERIES Concrete Cutter USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. RULES FOR SAFE OPERATION ......................2 2. OPERATION ............................. 3 3. MAINTENANCE - TROUBLESHOOTING ....................6 4. LUBRICATION AND SERVICE ......................... 9 5. SPECIFICATION ............................9 6. TRANSPORTATION ..........................9... -
Page 3: Rules For Safe Operation
1. RULES FOR SAFE OPERATION WARNING: Failure to fallow instructions in this manual may lead to serious injury or even death! This equipment is to be operated by trained and qualified personnel only! This equipment is far industrial use only. The fallowing safety guidelines should always be used when operating these Floor Saws: GENERAL SAFETY •... -
Page 4: Operation
• DO NOT operate this equipment unless all guards and safety devices are attached and in place. • Caution must be exercised while servicing this equipment. Rotating and moving parts can cause injury if contacted. • Keep all inexperienced and unauthorized people away from the equipment at all times. •... - Page 5 The machines used far the primary purpose of "flat" cutting. This type of cutting is described as "flat" because the pavement is cut somewhere clase to a horizontal plane. lt is the most common type of diamond blade cutting. Floor saws in the industry are available in a variety of types, sizes and styles, they range from manual or self propelled in horsepower from 7-72hp.
- Page 6 Caution - Set unit up in an open area. Avoid close proximity to structures or other equipment. Failure to do so may cause inadvertent injury to operator or other persons in the area. Cold start - Open the fuel valve under the gas tank all the way. Position the engine stop switch, located on the engine, to run.
-
Page 7: Maintenance - Troubleshooting
straight edge engine engine pulley blade shaft pulley 7. Line up the straight edge along the outside tace of both pulleys shown in the drawing. AII pulleys have (2) set screws in the bottom of their grooves. Set screws require thread locking lock title. 8. - Page 8 SEGMENT LOSS • Blade overheats because • (Wet Cutting) Check water lines. of lack of coolant (water or air). • Make sure flow is adequate on • Core is worn from undercutting. both sides of blade and there are • Detective collars/flanges set no blockages blade out of alignment.
- Page 9 • DO NOT use bent blade. Contact blade manufacturer. BLADE WILL NOT CUT • Blade is too hard far material • Select proper blade far material being cut. being cut. • Blade has become dull. • Sharpen by cutting on softer •...
-
Page 10: Lubrication And Service
4. LUBRICATION AND SERVICE • Check oil levels, wiring, hoses (air, fuel, water) and lubricate machine daily. • Repair or replace all worn or damaged components immediately. • Check drive belt tension, do not over-tension. • Make sure machine has full set of matched belts. •... -
Page 11: Transportation
DATMF20-2 Fuel: Diesel Max. output: 9 hp Max. cutting depth: 17 cm Blade size: 35-50 cm Depth adjustment: Handle rotation Driving: Semi-self propelled Water tank capacity: 40 L Dimensions: 115x55x100 cm Net Weight: 216 kg Gross Weight: 220 kg DATMF20-4 Fuel: Gasoline Max. - Page 12 Manufactured under license of Daewoo International Corporation, Korea...
