Page 1: User Manual
USER MANUAL uSign™ Signature Capture Module Models uSign 100 & uSign 200 80084501-001-A 04-24-2007... -
Page 2: Fcc Warning Statement
Value through Innovation are trademarks of International Technologies & Systems Corporation. USB (Universal Serial Bus) Specification is Copyright by Compaq Computer Corporation, Intel Corporation, Microsoft Corporation, and NEC Corporation. Windows, Excel, & Notepad are registered trademarks of Microsoft Corporation. -
Page 3: Limited Warranty
uSign User Manual LIMITED WARRANTY ID TECH warrants to the original purchaser for a period of 12 months from the date of invoice that this product is in good working order and free from defects in material and workmanship under normal use and service. ID TECH’s obligation under this warranty is limited to, at its option, replacing, repairing, or giving credit for any product which has, within the warranty period, been returned to the factory of origin, transportation charges and insurance prepaid, and which is, after examination, disclosed to ID TECH’s... -
Page 4: Table Of Contents
Table of Contents Introduction...6 Features ...6 Model Designations ...7 Installing uSign ...7 Communication Interface ...8 USB-CDC Setup ...10 Terms & Abbreviations ...7 Specifications ...10 Power requirement...10 Physical housing uSign 100 ...10 Physical housing uSign 200 ...11 LCD screen & Resistive touch pad ...11 Communication interface ...11 LED...11 Agency Approvals ...11... - Page 5 uSign User Manual 7.4.6 Get data 0x00 0x01 ...15 7.4.7 Calibrate the device ...15 7.4.8 Set offset position ...15 7.4.9 Get data 0x01 ...15 7.4.10 Offset using control ...15 7.4.11 Stop Capturing...16 7.4.12 Start Capturing use FBP format 1...16 7.4.13 Clear display screen ...16 7.4.14 Draw line...16...
-
Page 6: Introduction
uSign User Manual Introduction The use of electronically captured signatures has become common for Point of Service (POS) applications. Electronic signature capture reduces transaction time, eliminates sorting & sending paper, provides convenient electronic storage & transmission, and gives legal accountability (non-repudiation) for POS transactions. uSign™... -
Page 7: Model Designations
Model Designations uSign 100 IDUA-01x100 * uSign 200 IDUA-01x500 * * The “x” defines the communication interface, 2 = RS232 and 6 = USB-CDC. Terms & Abbreviations Host communication port Host Personal Computer, Terminal, or similar device Liquid Crystal Display Light Emitting Diode Milli-Amperes of electrical current RS232... -
Page 8: Communication Interface
uSign User Manual Communication Interfaces RS232 The uSign has a communication cable with a DB25 (100 Model) or DB-9 (200 Model) connector that fits the computer serial (RS232) COM port connection. See the Specifications, Interface Section for COM port settings. Connect the RS232 connector to the PC and insure it is fully seated into the connector. - Page 9 uSign User Manual Figure 1 New Hardware Wizard opening window Browse and select the folder where the uSignUsbCDC.inf and companion usbser.sys files are located. Click Next > to continue. Figure 2 Browse for File Copyright © 2006, International Technologies & Systems Corp. All rights reserved. Page 9 of 18...
-
Page 10: Usb-Cdc Setup
There is a warning window that the INF file is not registered; Click “Continue Anyway”. Click Finish to complete the INF installation. Figure 3 Installation Warning Message USB-CDC Setup The following steps provide a check on the USB-CDC COM port selected by the operating system. -
Page 11: Physical Housing Usign 200
Physical housing uSign 200 Overall size 129mm wide (5.1 in) 146mm length (5.75 in) 40mm thick including back plate (1.57 in) Display 3.3-inch diagonal signature area LCD screen & Resistive touch pad Touchpad Resistive, transparent, pressure-sensitive screen Display STN monochrome LCD Sampling Rate Up to 190 samples per second Touchpad Resolution... - Page 12 uSign User Manual 10% to 95% non-condensing Copyright © 2006, International Technologies & Systems Corp. All rights reserved. Page 12 of 18...
-
Page 13: Usign Commands Description
uSign commands description (Version: 0.02 Date: 2007-03-19) Note: digits are given in little-endian format. Command protocol: Host to device: STX LenL LenH CommandData Lrc1 Lrc2 ETX STX: 0x02. 1 byte. LenL+LenH: sizeof(CommandData). 2 bytes. CommandData: main command string. Several bytes needed. Lrc1: Exclusive or of CommandData. -
Page 14: One Byte Commands
One byte commands 7.3.1 Stop Capturing Command string: C0 Response string: C0 7.3.2 Start Capturing use FBP format 1 Command string: C1 Response string: C1 7.3.3 Start Capturing use FBP format 2 Command string: C2 Response string: C2 7.3.4 Turn red led on Command string: C3 Response string: C3 7.3.5... -
Page 15: Start Capturing Use Fbp Format 0
7.3.12 Start Capturing use FBP format 0 Command string: D6 Response string: D6 Multi-byte commands 7.4.1 Initialize device Command string: 28 10 00 00 Response string: DC 05 7.4.2 Get PW120 Version Command string: 2A 10 00 00 Response string: 01 00 7.4.3 Test device Command string: 52 12 00 00... -
Page 16: Stop Capturing
7.4.11 Stop Capturing Command string: 40 30 00 00 Response string: 7.4.12 Start Capturing use FBP format 1 Command string: 41 30 00 00 Response string: 7.4.13 Clear display screen Command string: 40 32 00 00 Response string: 7.4.14 Draw line Command string: 43 32 08 00 X1(2 bytes) Y1(2 bytes) X2(2 bytes) Y2(2 bytes) Response string: Line is defined by two points: (x1,y1) --- (x2,y2) -
Page 17: Figure 4 Outline Drawing For Usign 100
uSign User Manual uSign™ 100 SIGNATURE CAPTURE PAD Figure 4 Outline Drawing for uSign 100 Copyright © 2006, International Technologies & Systems Corp. All rights reserved. Page 17 of 18... -
Page 18: Figure 5 Outline Drawing For Usign 200
uSign User Manual uSign™ 200 SIGNATURE CAPTURE PAD Figure 5 Outline Drawing for uSign 200 Copyright © 2006, International Technologies & Systems Corp. All rights reserved. Page 18 of 18...
