INSTALLATION

3/V390/U to 3/V590/U

Dispenser

Conversion Kit

Table of Contents

Need help?

Do you have a question about the 3/V390/U and is the answer not in the manual?

Questions and answers

Summary of Contents for DRESSER Wayne 3/V390/U

Page 1 INSTALLATION 3/V390/U to 3/V590/U Dispenser Conversion Kit...
Page 3 Installation Manual for 3/V390/U to 3/V590/U Dispenser Conversion Kit...
Page 5: Table Of Contents
Table of Contents Section 1: Before You Start 1.1 Introduction ............... . 1-1 1.2 Kit Overview and Parts List .
Page 6 Table of Contents Part. No. 920680 Rev A June 2003...
Page 7: Section 1: Before You Start
Before You Start Introduction This manual describes how to install the Wayne 3/V390/U to 3/V590/U Conversion Kit in a Vista dispenser without Wayne Trac. Refer to the following table for identification of the retrofit kit. Table 1-1 3/V390/U TO 3/V590/U Retrofit Kit...
Page 8: Kit Overview And Parts List
Section 1: Before You Start Kit Overview and Parts List Refer to Photo 1 and the Parts List Table 1-2 below and make sure you have all the parts. Table 1-2 889336-001 Kit Parts List Item No. Part No. Description Qty.
Page 9: Unpacking And Inspection
Section 1: Before You Start Unpacking and Inspection Complete the following steps: 1. Before opening any cartons, count the number of cartons and verify the carton count against the supplied packing list. 2. Inspect the cartons for damage made during transit. 3.
Page 10: Required Tools
Section 1: Before You Start Required Tools Refer to Table 1-3 for a list of tools required to install the retrofit kit. Table 1-3 Required Tools Quantity Description Phillips Screwdriver (medium and small) Slotted Screwdriver (medium and small) 1/4" to 3/4" Combo Wrenches 12"...
Page 11: Section 2: Removing Old Hardware
Section Removing Old Hardware Introduction This section explains how to remove the old hardware in preparation for the installation of the conversion kit. Removal of Old Components To remove the old components from the dispenser, perform the following steps. 1. Record all totalizer readings and unit prices on the dispenser. 2.
Page 12 Section 2: Removing Old Hardware Top Cover Screw Locations Right Side Outer Column Jucntion Box Side Figure 2-1 Outer Column Screw Locations 7. Close all emergency shut-off valves then try to dispense from each grade on both side 1 and side 2 of the dispenser, verifying that the valves are closed. 8.
Page 13 Section 2: Removing Old Hardware Figure 2-2 Disconnect Wire Harness from ISB X1 and X2 valve connections Valve Conduit/ Potted Fittings Figure 2-3 Remove Solenoid Valve Connections June 2003 Part No. 920680 Rev A...
Page 14: 2.3 Removal Of Product Tubes And Valves
Section 2: Removing Old Hardware 2.3 Removal of Product Tubes and Valves To remove the old product tubes from the dispenser, perform the following steps. Important: Be sure that excess product is captured when removing product tubes and disposed of properly.
Page 15 Section 2: Removing Old Hardware Product tubes removed in Step 1. Remove valve/conduit ass’y on each side Figure 2-5 Right Meter June 2003 Part No. 920680 Rev A...
Page 16 Section 2: Removing Old Hardware Part No. 920680 Rev A June 2003...
Page 17: Section 3: Installing New Hardware
Section Installing New Hardware Introduction This section explains how to install the new hardware from the conversion kit into the dispenser and electronic head. June 2003 Part No. 920680 Rev A...
Page 18: Installation Of The New Hardware
Section 3: Installing New Hardware Installation of the New Hardware To install the new components from the conversion kit, perform the following steps. Lubricate the O-Rings from the kit p/n 1-921130 with vasoline and install onto the outlet plugs p/n 1-202047. See Figure 3-1. O-Ring Figure 3-1 Outlet Plug with O-Ring 2.
Page 19 Section 3: Installing New Hardware Remove this tube and install PLUG. Figure 3-3 Hose Outlet Right Side (Side 1) 4. Install the new pulser/nozzle switch harness p/n 5-302140-HRN into the vapor barrier. See Figure 3-4. Reuse hardware that was removed earlier and ensure that a washer is used above and below the vapor barrier.
Page 20 Section 3: Installing New Hardware Pulser Cable Label Nozzle Switch Cable Pulser Meter Figure 3-5 Pulser Cable Installation 6. Connect the new pulser/nozzle switch harness cable labelled HI to the middle pulser and the cable labelled LO to the left pulser. Re-use grommet and cover removed earlier. See Figure 3-5.
Page 21: Testing The Installation
Section 3: Installing New Hardware 10. Make the electrical connections in the junction box (terminals 3 and 4) for the Relay Select lines according to the wiring diagram 5-6632-D provided in the manual. 11. Make any additional wiring harness connections according to wiring diagram 5-6632-D. 12.
Page 22 Section 3: Installing New Hardware Part No. 920680 Rev A June 2003...
Page 23: Wiring Diagram
Appendix Wiring Diagram Refer to the following wiring diagram, 5-6632-D, when installing the 3/V390/U to 3/V590/U Conversion kit. June 2003 Part No. 920680 Rev A...
Page 24 Appendix A: Wiring Diagram Part No. 920680 Rev A June 2003...
Page 25 INSTALLATION MANUAL 3/V390/U to 3/V590/U DISPENSER CONVERSION KIT Written by S. G. Martin Technical assistance by James Christ Produced using Adobe® FrameMaker® and Adobe® PhotoShop® Page design uses Times New Roman and Arial Fonts Manuals were electronically produced on a Xerox Docutech P ublishing System at 600 dpi ©...
Page 26 Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be re- quired to correct the interference at his own expense.” Dresser Wayne, Dresser, Inc. 3814 Jarrett Way, Austin, TX 78728 (512) 388-8311 Part No.
