- Page 1 Evaporative air cooler user’s instruction manual Please keep the user’s instruction manual for reference. Please read this instruction manual carefully before using the product.
-
Page 2: Table Of Contents
CONTENT Ⅰ、Product Introduction----------------------------------------------- 1 Ⅱ、Specifications--------------------------------------------------------- 2 Ⅲ、Range of Application------------------------------------------------2 Ⅳ、Using Environment------------------------------------------------- 2 Ⅴ、Circuit wiring Diagram ------------------------------------------- 3 Ⅵ、Operating Instruction --------------------------------------------- 5 Ⅶ、Installing and Using Instruction------------------------------- 6 Ⅷ、Maintenance Instruction------------------------------------------ 6 Ⅸ、Common Faults and Troubleshooting------------------------- 7... -
Page 3: Ⅰ、Product Introduction
Continuously circulating pump draws water from the water tank, and then the water is distributed to the cooling pads. When the hot air enters into the cooling pads, evaporation of water in the pads occur cooling the hot air before it enters the greenhouse. Ⅱ、Specifications 3500VK 5800VK Cooler Model VABW06-EQ... -
Page 4: Ⅵ、Operating Instruction
V、Operating Instruction 1. The operating instruction of control panel (Picture 1) （1）ON/OFF Plug cooler in, and press this button to turn on the air cooler. During the initial use, the default setting is in the “cool mode”. Press button again to cut the unit off (turns off fan motor, pump and display). - Page 5 2. Operation of remote controller （Picture 2） （1）ON/OFF Plug cooler in, and press this button to turn on the air cooler. During the initial use, the default setting is in the “cool mode”. Press button again to cut the unit off (turns off fan motor, pump and display).
-
Page 6: Ⅶ、Installing And Using Instruction
VI、Installing and Using Instruction 1. The unit must be installed outside or in the area with enough return air volume and 0.15~0.6 m/pa water pressure. 2. The unit for open area using, if it working in closed area, must open the vent to keep balance between the air input and displacement. -
Page 7: Ⅷ、Maintenance Instruction
（7）Don’t keep the air outlet close to walls or window curtains cause the air will be blocked. （8）If the machine is not in use, please pull the power plug. VII、Circuit Wiring Diagram for PCB Ⅷ、Maintenance Instruction Turn the power off before maintenance or repair of the machine so as to prevent accidents due to illegal operation. -
Page 8: Ⅸ、Common Faults And Troubleshooting
Ⅸ、Commons Faults and troubleshooting Troubles Common Causes Solutions Power failure Check power supply Unable to start Fuse burned Change the fuse the fan Poor contacted PCB Check the PCB PCB damaged Change the PCB The motor starter’s capacitor Change the capacitor damaged The motor damaged Change the motor...
