- Page 1 Squeezer Mini version of Dan Armstrong’s Orange Squeezer Compressor Contents of this document are ©2016 Pedal Parts Ltd. No reproduction permitted without the express written permission of Pedal Parts Ltd. All rights reserved.
- Page 2 IMPORTANT Before you start... Grab the general build doc that covers all FuzzPup builds. Most of the information you need for this build is in there. Read it? OK, carry on. uzzPups Lovely little boxes of joy with a totally standardised build pattern Contents of this document are ©2016 Pedal Parts Ltd.
- Page 3 Schematic + BOM Parts in blue are mods to make the circuit more suitable for bass. 470K 470K *Not shown on schematic. Optional polarity 470K (1u) protection diode. See later in document. 390K (10u) 220K (200K) 47u** **Power smoothing cap. See later in document.
- Page 5 Notes C8 - power filtering capacitor. NOTE: PCB shown below is the EPic Boost, but it’s the same deal. This was added on the underside of the PCB, but the anode was connected to the wrong net, so don’t add it in this position.
- Page 6 Set up... Not a lot to do here. Simply adjust T1 until you get your desired level of sustain without distortion. FuzzDog.co.uk...
