T7- S7
T-Touch All in One Application
Technical Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T7 and is the answer not in the manual?

Questions and answers

Summary of Contents for Totalcomp T7

  • Page 1 T7- S7 T-Touch All in One Application Technical Manual...

  • Page 2: Table Of Contents

    CONTENTS 1. Specifications..…………………………………..................2 1.1. General..……………………..…………………………………………………………………….2 1.2. Analog Input.………………………………………………………………………………………2 2. Installation………………..………..…………………………………………………………………………...3 2.1. Requirements..……………………………………………………………………………………3 2.2. Installation Ports………………………………………………………………………………….3 2.3. Load cell Connection……….…………………………………………………………………….4 2.4. RS-232 Connection…………..…………………………………………………………………..5 2.5. Power………………………………………………………………………………………………6 3. Operation…………………………...…………….……………………………………………………………..7 3.1. Basic Operation…………………………………..……………………………………………….7 3.2. Panel key Functions………………………………………………………………………………7 3.3. Touch Key Functions……………………………………………………………………………..8 3.4. Indications…………………………………………………………………………………………9 3.5. On-Screen Key Board……………...…………………………………………………………..10 4.
  • Page 3 5 in 1 T-Touch Application A1.15D INTRODUCTION The 5 in 1 application is designed for multiple use, such as CLASS weighing, Take Out Operation, Target Operation, Counting and Check weighing. This application can use for all of the T Touch products. - 1-...

  • Page 4: Specifications

    5 in 1 T-Touch Application A1.15D 1. SPECIFICATIONS 1.1. General Capacity Free setting External Resolution 6000e Tare range Max-1d AD Type Sigma delta AD Speed Max. 60 times/second Internal Counts 1,000,000 Weighing Units kg, g, tj, gj, lb, oz, lz Calibration Unit kg, g, lb（lb only for NTEP model）...

  • Page 5: Installation

    2. INSTALLATION 2.1 Requirements The mounting location must be a stable surface and free of heat, water and humidity. The Indicator should be placed convenient and easy operation. 2.2 Installation Ports of T7 RS-232 / RS-422 Load Cell RS-232 Adaptor Jack...

  • Page 6: Load Cell Connection

    5 in 1 T-Touch Application A1.15D 2.2.1 Installation Ports of S7 Load Cell RS-232 2.3 Load Cell Connection 5 Pin Air Connector Connection AD - PCB Connection Wire Color Signal + Green Signal - White Shield Blue Excitation - Black Excitation + Note: if using 7 wire load cell, please short-circuit SEN+ to EXC+, and SEN- to EXC- for to connect - 4-...

  • Page 7: Rs-232 Connection

    5 in 1 T-Touch Application A1.15D 2.4 RS-232 Connection The RS-232 port is located on the side or rear of the scale (refer to component description). It is a DB9 (T 7 Indicator) and Round Air (S 7 Indicator) connector, and its signals are defined in the following.

  • Page 8: Power

    5 in 1 T-Touch Application A1.15D 2.5 Power The power supply accepts the voltage of charger 12VDC/2500mA from the external power adaptor with input from 100~240 VAC 50/60 Hz. Adaptor polarity should be Battery: The Indicator can optionally be operated from the internal rechargeable battery 6V/4Ah. Connect Adaptor and Charging: To charge the battery, insert the adaptor pin to the jack.

  • Page 9: Operation

    5 in 1 T-Touch Application A1.15D 3. OPERATION 3.1 Basic Operations 3.1.1 Power on Press and hold key until to hear a beep sound. It will take around 30 seconds for to run the TOS operating system and application software. 3.1.2 Standby Press key for to keep display standby / sleep.

  • Page 10: Touch Key Functions

    5 in 1 T-Touch Application A1.15D 3.3 Touch Key Functions Keys Description Class Simple weighing Takeout Target. Count Check Accumulation Pre-Tare Print Sum Details Load Operation Unload Operation - 8-...

  • Page 11: Indications

    5 in 1 T-Touch Application A1.15D 3.4 Indications Indications Description when the scale back to zero or by pressing When Tare, by pressing When the scale is in stable. Maximum capacity of the scale Minimum weight of the scale Division of the scale Software version Battery status Date and time...

  • Page 12: On-Screen Keyboard

    5 in 1 T-Touch Application A1.15D 3.5 On-Screen Keyboard On-Screen Keyboard will be open automatically for to edit or input new data, If close key board, by clicking required space to input data, it will open again. Backspace : When input text, use this key to change line : Special symbols and numeric keys.

  • Page 13: Application Operation

    5 in 1 T-Touch Application A1.15D 4. APPLICATION OPERATION Class Operation Class operation can use for goods packing, it can define different grade depend the weight for packing. It can set up to 5 different grade as A, B, C, D and E Each grade can setup high - low limits, during the operations it will count and show totals in the each grades.
  • Page 14 5 in 1 T-Touch Application A1.15D Product Search: 1) By using keys can scroll display up and down. 2) By touching alphabetic keys can search product name 3) By sliding page up or down can change product name page Note: Product ID Search / Add / Edit operation will be same in all applications (Class / Target / Takeout / Count / Check Weigh).
  • Page 15 5 in 1 T-Touch Application A1.15D High Limit Settings Once finish low limit setting and by pressing OK key to confirm, display will be show Hi limit settings. Input limit value and press OK key to confirm Display will be show the limit A and will show accordingly Lo Limit and High Limit values As per above Low &...
  • Page 16 5 in 1 T-Touch Application A1.15D Display will be show the number of times and total of the class. If it’s different class operations, it will show accordingly for the each number of the class and total. Total Accumulation Press key to view the total accumulation, display will be show By using...
  • Page 17 5 in 1 T-Touch Application A1.15D 4.1.4 Printer Operation. Press key to print current data. If Print key shown ; Communication settings not selected for the mode of printer operation. If select communication settings, mode of printer OS 2130, printer key will be show Note: Printer operations will be same in all applications (Class / Target / Takeout / Count / Check Weigh).
  • Page 18 5 in 1 T-Touch Application A1.15D 4.1.6 Pre -Tare Press key, display will be show Pre-Set Tare Keys Pre-Tare Direct input Key Pre-Set Tare Keys Four different known Tare weight can be store into the Pre-Set Tare keys. Press and hold Pre-Set Tare key 3 seconds, display will be show numeric keys to input tare value.

  • Page 19: Take Out Operation

    5 in 1 T-Touch Application A1.15D Take Out Operation Press key, from the home display, display will be show Set alarm for Take out operation. Press key , display will show to input alarm percentage. Input alarm (it will be show as percentage), and press OK to confirm.
  • Page 20 5 in 1 T-Touch Application A1.15D Remove the goods from the pan and press key, Removed goods weight will be show in extracted window It can follow to remove goods and by pressing key to save memory. It will be extracted and will start to beep once reach the alarm value.

  • Page 21: Target Operation

    5 in 1 T-Touch Application A1.15D Target Operation Press key, from the home display, display will be show Target operation window Press key to select product name from the list, Press key to select target, display will be show numeric keys to input target value. Input target value and press OK to confirm.
  • Page 22 5 in 1 T-Touch Application A1.15D This operation can be continue to reach the target value, Target graph will be increase and will change color once reach the target. Total weight value and graph will be change accordingly once press key.

  • Page 23: Counting Operation

    5 in 1 T-Touch Application A1.15D Counting Operation Press key, from the home display, display will be show counting / Sampling operation window Sampling / counting operation Select key display will be show direct sampling keys. Direct sampling keys x5 , x10 and x20 Sample Enter key Direct Sample: Place the goods on the pan and press direct...
  • Page 24 5 in 1 T-Touch Application A1.15D High –Low Limit Operation: Press key or press directly to Lo or Hi windows Press to input Hi-Low key Input Low limits Input High Limits Low Limit Display, below the limit Ok display, between the limits High Limit display, exceed the limit Accumulation Weighing data can save by pressing...
  • Page 25 5 in 1 T-Touch Application A1.15D Total Accumulation Press key to view the total accumulation, display will be show By using keys can scroll display up and down. Memory Clear Press key to clear all displayed accumulation data. Print data Press key print data.

  • Page 26: Check Weighing Operation

    5 in 1 T-Touch Application A1.15D Check Weighing Operation Press key, from the home display, display will be show check weighing operation window. High –Low Limit Operation: Press key or press directly to Lo or Hi windows Press to input Hi-Low key Input Lo –...
  • Page 27 5 in 1 T-Touch Application A1.15D Ok display, between the limits High Limit display, exceed the limit Accumulation Weighing data can save by pressing key to the memory. Total window will be show the Total and count window will be show the times of accumulation. Total Accumulation Press key to view the total accumulation,...

  • Page 28: Menu Settings

    5 in 1 T-Touch Application A1.15D 5. MENU SETTINGS Press key, a menu bar will be show at the middle of the display. 5.1. Setting Note: During the settings it will ask password for settings, Default Settings password: 0000 Press key to enter the parameter settings.

  • Page 29: System Settings

    5 in 1 T-Touch Application A1.15D 5.1.2. System settings 5.1.2.1. Gravity settings Gravity can enter as per your local gravity for to avoid calibration errors. Note: Please assure that you have input correct gravity value every time before calibration 5.1.2.2. Date and Time It can set date and time as per the country Enter date and time by using built-in keyboard or an outlet keyboard.
  • Page 30 5 in 1 T-Touch Application A1.15D 5.1.2.4. Backlight Back light can adjust as per your convenient Move Scroll bar left (decrease) or right (increase) for to adjust brightness of the backlight. Press << key at the top of the left corner for to go back to last step, or press other options to go to next step.

  • Page 31: Weighing Setting

    5 in 1 T-Touch Application A1.15D Password is required for to access parameter settings. Default password : 0000 Note: If modified password, it will ask password, when want to access menu settings. And follow to use new password. 5.1.2.9. Reset database Reset Product data, system will clear all product ID from the database.
  • Page 32 5 in 1 T-Touch Application A1.15D Note: If selected OIML, weighing setting functions can’t access. If want to access weighing settings, press CAL switch for to access. CAL switch is locating bottom of the housing. 5.1.3.2. Range Mode Range mode. Can select signal range, dual interval, dual range.
  • Page 33 5 in 1 T-Touch Application A1.15D Note: If it’s selected dual interval or dual range, it’s required to input capacity Max1 and Max 2 It is required to set max2 > max1. Press << key at the top of the left corner for to go back to last step, or press other options to go to next step.

  • Page 34: Operating Setting

    5 in 1 T-Touch Application A1.15D 5.1.3.9. Zero Tracking Select the desired range from the list. Note: This setting can’t access if in approval mode. Press << key at the top of the left corner for to go back to last step, or press other options to go to next step.
  • Page 35 5 in 1 T-Touch Application A1.15D 5.1.4.2 Measure Unit Select the desired weighing unit from the list for to change weighing unit. Press << key at the top of the left corner for to go back to last step, or press other options to go to next step.

  • Page 36: Calibration

    5 in 1 T-Touch Application A1.15D 5.1.5 Calibration 5.1.5.1. Calibration Press START key ; Display will be show 1: Empty scale then press NEXT key option, Keep empty platform Press NEXT key, Display will be show Previous calibration weight value and will be blink for to enter weight, Input calibration weight value and press OK option to confirm.
  • Page 37 5 in 1 T-Touch Application A1.15D Press NEXT key, Display will be show PASS Calibration has been finished. If its show, FAIL, Please Start again Please do the calibration again. Next Cal Reminder If want to remind next calibration date, click the cal reminder box for to enable next cal date option. It will remind when its reach due date while initial start up.

  • Page 38: Communication

    5 in 1 T-Touch Application A1.15D 5.1.6. Communication Com 1 or Com2 operations Select the serial port options, including transmit mode, baud rate, data bits, and stop bits. Mode: Selectable Off ; (Comport Off). / Continue; (Continues data send to PC) / ASK: (control by PC key board) EPM205, OS2130..etc.;...

  • Page 39: Total Operating Settings

    5 in 1 T-Touch Application A1.15D Auto ACC (load): When place the goods on the pan, it will accumulate and print automatically once get stable. Auto Acc (Unload): When unload goods from the pan, it will accumulate and print automatically. 5.3.

  • Page 40: Data Export Settings

    5 in 1 T-Touch Application A1.15D 5.6. Data Export Settings Press key for to export data to USB disk. Before select this option, should be want to connect USB disk. 5.7. Help Settings Press key to read basic operation tutorial. Tutorial display page can be change by pressing key for next page and key for previous...

  • Page 41: Error Message

    5 in 1 T-Touch Application A1.15D 6. ERROR MESSAGE Problem Possible cause Common solutions Mains power is turned off Check power switch is turned on, and Power supply not plugged in power LED is working. Can’t turn on power Power supply faulty Verify the voltage going to the scale Internal battery not charged matches the power supply labels on the...
  • Page 42 5 in 1 T-Touch Application A1.15D Housing assembled by over tighten. touch screen. Loose housing screws, if overtighten. Hold ON/OFF key for 6 seconds to restart the scale. System hang Software error, need restart Disconnect battery and charger, connect again and turn on the power Verify the batteries are rechargeable types and charging voltage getting Disconnect AC...
  • Page 43 Weighing indicator for platform scales, floor scales and truck scales.  Hand push and pull gauge.  Customize auto weighing systems. Totalcomp Inc. Tel.: 800-631-0347 99 Reagent Lane Fax: 888-797-2288 Fair Lawn, NJ 07410 All information contained within this publication was to the best of our knowledge timely, complete and accurate when issued.
