ENGO CONTROLS EREPEATERZB Quick Manual

REPEATER
ZigBee network repeater
EREPEATERZB
Quick Guide
Ver. 1
Release date: III 2023
Producer:
Engo Controls S.C.
43-200 Pszczyna
3E Górnośląska St.
Poland
Distributor:
QL CONTROLS Sp z o.o. Sp. k.
43-262 Kobielice
4 Rolna St.
Poland
www.engocontrols.com

INTRODUCTION:

Repeater increases wireless network signal range for all Engo devices which works over
ZigBee 3.0 protocol. It helps to improve radio signal range in places, where wireless
network is disturbed by distance or other obstacles (concrete walls, reinforced ceilings,
etc.). This device cannot operate standalone. IIn order to use it EGATEZB ZigBee 3.0
gateway is needed.
WARNING:
This product must be used with EGATEZB ZigBee 3.0 gateway (purchased separately).

PRODUCT COMPLIANCE:

This product complies with the following EU Directives:
2014/30/EU, 2014/35/EU, 2014/53/EU, 2011/65/EU.

SAFETY INFORMATION:

Use in accordance with national and EU regulations. Use the device only as intended,
keeping it in a dry condition. The product is for indoor use only. Please read the entire
manual, before installation or use.
WARNING:
For the entire installation, there may be additional protection requirements, which the
installer is responsible for.

Technical specification:

230V AC
Power supply
50Hz
ZigBee 3.0
Communication
2,4GHz
Dimensions
40 x 24 x 82
[mm]

LED diode indications

EXPLANATION
The device is in pairing
mode with ZigBee
LED diode network (when device
flashes didn't previously
blue added to the ZigBee
3.0 network, or after
recovery factory reset)
LED diode The device has been
lights up
added to the ZigBee
blue 3.0 network
Repeater is not
LED diode
connected to power
is off
supply 230V
