Assembly
Step 4:
NOTICE
• Connect the rear guard (B) with the main unit (E). Align the rear
guard's small round holes with the 3 pins on the main unit's
front.
• Secure the rear guard (B) with the fixing ring.
Step 5:
NOTICE
• Place the large blade (C) on the shaft. Align
the cross pin on the shaft with the groove
on the rear side of the large blade (C).
• Place the small blade (D) on the shaft.
Align the pin on the rear side of the small
blade with one of the three holes on the
large blade (C).
• Hold the large blade (C) with one
hand and screw on the cap nut in the
counter-clockwise direction to secure the
blades.
8
The product features a timer, which lets the
user to set an automatic switch off time. You
can choose from 0.5 to 7.5 hours.
Remove the plastic tube
from the shaft before
installing the blades (C)
and (D).
B
E
D
C
