1
12
3
4
5
6A
6B
7
Please follow assembly instructions carefully to ensure optimal product performance.
Questions? Contact us at info@marchingusa.com or (469) 422-2681.
© Marching USA |
2317 Chester Street Fort Worth, TX 76103 |
2
12
3
11
10
9
8
(469) 422-2681 |
P23-MTBB T-Max Marching Bass Drum Carrier
PARTS LIST
PART DESCRIPTION
T-Max Arm Hook (Right)
1
T-Max Arm Hook (Left)
2
Arm Hook Foam Pad Set (R & L)
3
T-Max Top
4
T-Max Bottom
5
Bass Support Bar (A & B)
6
T-Max Belly Plate
7
T-Max Tongue (3/8")
8
Mini Dynasty Logo (white)
9
Belly Plate Foam Pad
10
Bass Tongue Foam Pad
11
J-Hook Assembly Pack:
12
5/16" J-Hooks
5/16" Serrated Flange Lock Nuts
Frame Hardware Pack:
13
1/4" Serrated Flange Lock Nuts
1/4" x 3/4" Carriage Bolts
1/4" x 1" Carriage Bolts
12
4X
13
12X
8X
DynastyDrums.com
Updated 2022
SKU
QTY
P600-0050
1
P600-0051
1
P600-0066
1
P600-0044
1
P600-0045
1
P23-MTBR
1
P600-0048
1
P600-0047
1
P900-0030
P600-0017
2
P600-0009
2
P600-0022K
2
2
4
P900-TMF5
12
8
4
2X
4X
1
Advertisement
Table of Contents
Summary of Contents for Dynasty P23-MTBB
- Page 1 ASSEMBLY INSTRUCTIONS P23-MTBB T-Max Marching Bass Drum Carrier Updated 2022 PARTS LIST PART DESCRIPTION T-Max Arm Hook (Right) P600-0050 T-Max Arm Hook (Left) P600-0051 Arm Hook Foam Pad Set (R & L) P600-0066 T-Max Top P600-0044 T-Max Bottom P600-0045 Bass Support Bar (A & B)
- Page 2 ASSEMBLY INSTRUCTIONS | P23-MTBB T-Max Marching Bass Drum Carrier Install the J-Hooks from the J-Hook Assembly Find the Arm Hook Foam Pads (part 3) and peel Pack (part 12) onto the Arm Hooks (parts 1 & 2) o the Velcro backing. Trim the loose strip of using two 5/16”...
- Page 3 ASSEMBLY INSTRUCTIONS | P23-MTBB T-Max Marching Bass Drum Carrier Attach the Bar Top (part 4) to the Bar Bottom Assemble the Bass Support Bar (part 6A & 6B) (part 5) using two 1/4” x 3/4” Carriage Bolts using two 1/4” x 3/4” Carriage Bolts and two 1/4”...
- Page 4 ASSEMBLY INSTRUCTIONS | P23-MTBB T-Max Marching Bass Drum Carrier Install remaining foam pads. Attach Arm Hooks (parts 1 & 2) to Bar Top using four 1/4” x 3/4” Carriage Bolts and four lock nuts. Front Back Questions? We can help! Contact us at (469) 422-2681 or email info@marchingusa.com.
