AXYS TRIAXYS User Manual

Directional wave buoy
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
D
IRECTIONAL
This Operations Manual contains trade secrets and confidential information, which are proprietary to Axys
Technologies Inc. Its use, reproduction, or disclosure in whole or part without the express written permission of Axys
Technologies Inc. is prohibited. This Operations Manual is also an unpublished work protected under copyright laws. If
this work becomes published, the following shall apply:
TRIAXYS™
USER'S MANUAL
Version 13
Manufactured by:
AXYS Technologies Inc
2045 Mills Road West
Sidney, British Columbia
Canada V8L 5X2
Telephone: (250) 655-5850 Fax: (250) 655-5856
Email:
info@axys.com
August 2012
Copyright 2012 AXYS Technologies Inc
All Rights Reserved
0226113Z
August 2012
W
AVE
B
UOY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRIAXYS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AXYS TRIAXYS

  • Page 1 This Operations Manual contains trade secrets and confidential information, which are proprietary to Axys Technologies Inc. Its use, reproduction, or disclosure in whole or part without the express written permission of Axys Technologies Inc. is prohibited. This Operations Manual is also an unpublished work protected under copyright laws. If...
  • Page 2 The TRIAXYS™ Directional Wave Buoy and the TRIAXYS™ Digital Receiver are identified by unique Serial Numbers. Software version numbers are identified for the two EPROMs in the TRIAXYS™ Sensor and Telemetry Module and for the WaveView software. Always provide the TRIAXYS™ Directional Wave Buoy serial numbers in any correspondence with AXYS Technologies Inc.
  • Page 3 International Air Transport Administration (IATA) Dangerous/Hazardous Goods Regulations. You must open the buoy and reconnect the batteries prior to testing and deploying your TRIAXYS™. Please follow the instructions below for connecting the batteries. If you have questions please call AXYS Technologies Customer Service at 1-877-792-7878, or email: info@axys.com...
  • Page 4 TRIAXYS™ Directional Wave Buoy User Manual version 13 SPA Handle Fig 3: VHF antenna/IR Port: do not use Fig 4: Prop open the SPA. Do Not these as handles when propping open the Remove the SPA completely. SPA. Locate the Power Distribution Module: The Power Distribution Module is located beside the TAS module as shown.
  • Page 5 TRIAXYS™ buoys are shipped with a spare desiccant pack. The TRIAXYS™ was shipped with a desiccant pack sealed inside a plastic bag. It is located in a pouch attached to the inside wall of the buoy's hull. Just before sealing up the buoy please remove the desiccant pack from its plastic bag and replace it inside the netting bag.
  • Page 6 Hydrogen Gas in quantities sufficient to combust in the presence of an open flame or spark. Although the TRIAXYS Directional Wave Buoy carefully controls the battery voltage in order to prevent overcharging, it is recommended that proper handling procedures be followed.

  • Page 7: Table Of Contents

    TRIAXYS™ Directional Wave Buoy User Manual version 13 ONTENTS 1. I .............................. 1 NTRODUCTION Features and Specifications .......................... 1 Polycarbonate Dome - Part #1439 ........................ 5 Stainless Steel (AISI 316) Hull - Part #1522 ....................6 Rechargeable Batteries ..........................7 1.4.1 Power Budget ..........................
  • Page 8 TRIAXYS™ Directional Wave Buoy User Manual version 13 System Diagnostics Menu .......................... 42 2.8.1 Sensor Display at 4Hz ........................43 2.8.2 System Display at 1Hz ........................43 2.8.3 Voltage and Current Display ......................43 2.8.4 Wave Processing Diagnostics......................44 2.8.5 System Tests ..........................46 2.8.6 Reset Boot Times ..........................
  • Page 9 7.2.4 Solar Panel Assembly ........................79 TRIAXYS™ Sensor and Telemetry Module ....................80 7.3.1 Retrieving Data from the Sensor and Telemetry Module .............. 80 7.3.2 Replacing the TRIAXYS™ Sensor and Telemetry Module ............81 Batteries ..............................81 7.4.1 Removal of Batteries ........................82 7.4.2 Replacement of Batteries .......................

  • Page 10: Introduction

    1. 1. I NTRODUCTION The TRIAXYS™ Directional Wave Buoy can be used to measure non-breaking waves in any of the World's Oceans where a surface following buoy can be deployed. The TRIAXYS™ Directional Wave Buoy is a precision instrument designed and manufactured by AXYS Technologies Inc, which incorporates new technologies that make it an easy to use, rugged and economical buoy for accurate measurement of directional waves.
  • Page 11 Internal Flash Ram data logger for Processed and Raw 4Hz data Optional Components/Features • The TRIAXYS™ Directional Wave Buoy may have some, or all, of the following options: VHF Transmitter System (29-50 MHz) One Synthesised VHF TRIAXYS™ Transmitter with antennae One Synthesised VHF TRIAXYS™...
  • Page 12 TRIAXYS™ Directional Wave Buoy User Manual version 13 Axys Technologies Inc.
  • Page 13 TRIAXYS™ Directional Wave Buoy User Manual version 13 Table 1.1 TRIAXYS™ Directional Wave Buoy System Specifications Item Specification Physical Description 1.10m (43.5 inches) Outside bumper Diameter: 0.91m (36 inches) SS hull Weight (including four batteries) 197 kg (435 lb) Weight (excluding batteries)

  • Page 14: Polycarbonate Dome - Part #1439

    1.2. Polycarbonate Dome - Part #1439 One of the unique features of the TRIAXYS™ Directional Wave Buoy is the polycarbonate dome. This dome is manufactured from a polycarbonate known as Lexan SE. It is extremely strong and resistant to impact (see specifications). It allows the TRIAXYS™ Directional Wave Buoy to be solar powered as well as providing access to the processing unit in the Sensor and Telemetry Module via the Infrared port.

  • Page 15: Stainless Steel (Aisi 316) Hull - Part #1522

    *Note: TRIAXYS should not be left "ON" with the batteries connected and dome 'cap' on while awaiting deployment, as batteries will be run down.

  • Page 16: Rechargeable Batteries

    GpF1 5 (20)s 0.06 The following graph shows a typical charge-discharge curve for a TRIAXYS™ Buoy deployed in latitudes North or South of 40ø. This shows the importance of ensuring the buoy is fully charged prior to any new deployments. As a general rule, operators should de-rate the total reserve battery capacity to 350Ahrs to take into account a number of factors such as cold temperatures, age of the batteries, cloudier conditions, and incomplete charging, to name a few.

  • Page 17: Power Regulation And Monitoring

    1.4.2. 1.4.2 Power Regulation and Monitoring The TRIAXYS™ Buoy uses an advanced temperature compensated solar charge control module which features accurate pulse width charge modulation, full overload and reverse current protection. They include field adjustments for either sealed or flooded batteries, and the "L" models feature a low battery load disconnect.

  • Page 18: Triaxys™ Sensor And Telemetry Module (Tas)

    The connections to the Sensor and Telemetry Module are as indicated in the drawing above. The actual layout of the connections in your buoy may be different to that shown. The TRIAXYS™ Buoy may be configured with either INMARSAT D+ transceiver or ARGOS satellite transmitter, but not both (note: if ARGOS is selected a separate GPS unit is required).

  • Page 19: 1.6.1 Power Distribution Module

    1.6.1. 1.6.1 Power Distribution Module The TRIAXYS™ Buoy uses an advanced temperature compensated solar charge control module which features accurate pulse width charge modulation, full overload and reverse current protection. They include field adjustments for either sealed or flooded batteries, and the "L" models feature a low battery load disconnect.

  • Page 20: Internal Data Logging

    1.6.2 Internal Data Logging The TRIAXYS™ Buoy comes with an internal data logging capability which can be used either as a back- up system in the event of marginal telemetry conditions or as a stand-alone feature. At present, the processed wave data and 4Hz RAW data files can be logged onto a 1 Gbyte PCMCIA Flash RAM card in a format as per Section 4.3 of this manual.

  • Page 21: Water Temperature Sensor

    1.8. Telemetry Options Described below are some of the types of telemetry presently available with the TRIAXYS™ Buoy. The VHF, Orbcomm, Iridium and ARGOS modules are installed within the Sensor-Telemetry enclosure. The GSM and INMARSAT D+ modules are mounted externally to the Sensor-Telemetry enclosure.
  • Page 22 Buoy will dial a number, obtain a connection and begin to download the data. At the completion of the data transfer, the TRIAXYS™ Buoy Cellular Module will terminate the call. On receipt of the buoy the client is required to install a SIM (Subscriber Identity Module) card for account activation. Refer to Section 2.3.1.2 for set-up procedures, testing and operation.

  • Page 23: Iridium

    The INMARSAT system can fill the role of either the primary or secondary telemetry option. 1.8.4.1. FTP INMARSAT D+ Data FTP data is uploaded hourly to a secure FTP site hosted by AXYS Technologies Inc., and includes all data collected during the hour. Nomenclature for the uploaded files consists of the INMARSAT identifier, the data type, and a date code (i.e.
  • Page 24 TRIAXYS™ Directional Wave Buoy User Manual version 13 Poll 9 file data format: Datatype, Date, Time (UTC), Inmarsat ID, Latitude, Longitude, Altitude, Temperature, Battery Voltage. Example Data: Poll 9,20040602,012205,59416558,48.654444,-123.415833,0,20,14.0 Wave data format: Datatype, Date, Time (UTC), Inmarsat ID, TAS #, Sample Start Time, Hmax, Hm0, Havg, Tp, T13, Tavg, Mdir, Spread, Pos.

  • Page 25: Orbcomm Satellite Transceiver

    To log onto the Web Interface application, enter www.inmarsatd.axystechnologies.com into the address line of your web browser. The username is your four-digit AXYS Customer ID, and a password will be provided by AXYS. Further instructions can be found in the Inmarsat D+ Web Interface User Manual.

  • Page 26: Argos Satellite Transmitter

    1.11. Magnetic On/Off Switch The TRIAXYS™ Directional Wave Buoy has a magnetic on/off switch mounted on the inside of the buoy hull under the rubber fender above the purge port (Section 1.3). Using the Magnetic Key (see Section 1.12.1) activates the switch.

  • Page 27: Magnetic Key

    1.12. Cover and Shipping Palette The TRIAXYS™ Directional Wave Buoy is supplied with a shipping palette and storage cover. It is recommended that the buoy remain on the shipping palette with the storage cover on when not in use. The cover should be removed when recharging with Solar (sunlight).
  • Page 28 TRIAXYS™ Directional Wave Buoy User Manual version 13 Figure 12: TDR Axys Technologies Inc.

  • Page 29: Triaxys ™ Programming , Operation And Test Menus

    PERATION AND ENUS When the Magnetic Key is removed from the hull, the TRIAXYS™ Directional Wave Buoy is turned on, and the infrared port is activated. Using a PC with an infrared serial device and configured to the specifications listed in Section 1.11 for serial communications, the operator will be able to configure and program the buoy through the Lexan Dome without disassembling the buoy.

  • Page 30: 2.1.1 Starting Hyperterminal

    Plug the JETEYE into an available 9-pin Serial COM port on the computer. Make a note of the COM port number used (1,2,3,4...). Secure with the strap provided (or hold) the JetEye about 1550cm from the IR port on TRIAXYS™. 2.1.2.
  • Page 31 TRIAXYS™ Directional Wave Buoy User Manual version 13 communications. Remember to keep the JetEye IR device pointed at the IR port on the TRIAXYS. The menu-driven screens will prompt you for input. 7. To save the configuration of the buoy, select File|Exit or File|Save As from the menu bar.
  • Page 32 TRIAXYS™ Directional Wave Buoy User Manual version 13 TRIAXYS Menu Tree (Ver 3.41) Main Menu "X" reset default parameters 1. Run-Time 2. Telemetry Options 3. Real Time 4. Data Logger 5. Calibration 6. System Diagnostics Parameters Clock Modes 1. Station ID 1.

  • Page 33: Main Menu

    TRIAXYS™ Directional Wave Buoy User Manual version 13 Main Menu 2. Telemetry Options 2. Telemetry Options 2. Telemetry Options 2. Telemetry Options 2. Telemetry Options <VHF/INM D- Var #2> <GSM/ARGOS- Var #3> <GSM/INM D- Var #4 <Orbcomm/ARGOS- Var. #5> <Orbcom/INM D- Var. #6>...

  • Page 34: Run-Time Parameters Menu

    Not listed in the options under this menu is a command that will reset all settings on the buoy to the factory defaults. You should do this when you receive your buoy from Axys or when you want to globally reset all the settings.

  • Page 35: Start Time Offset

    TRIAXYS™ Directional Wave Buoy User Manual version 13 2.3.4. Start Time Offset By selecting 4 at the Run-Time Parameters Menu, the user can offset the sample start time from the top of the hour. The default factory setting is set to 0.
  • Page 36 TRIAXYS™ Directional Wave Buoy User Manual version 13 If the deployment location is not known, the Clear WatchCircle Centre command is selected. Once this command has been initiated the buoy can be left to run or restarted (attach Magnetic Key and remove at any later time), resulting in the buoy waiting for a default of 20 minutes, at which time the position acquired by the GPS will be saved as the WatchCircle Centre.

  • Page 37: Telemetry Options

    TRIAXYS™ Directional Wave Buoy User Manual version 13 NOTE: If no WatchCircle centre has been entered when the Buoy starts up, the GPS will be turned on for this specified time. At the end of the time period, the buoy will obtain a GPS fix, and use the fix as the WatchCircle Centre.
  • Page 38 TRIAXYS™ Directional Wave Buoy User Manual version 13 2.4.1.2. VHF Settings If your buoy is configured with a VHF transmitter, the following menu will be displayed when selecting Option 1 at the Telemetry Menu. The user can access the Primary Data telemetry transmitter settings.
  • Page 39 This parameter may need to be changed depending on the specific network that the system is operating, but only on the recommendation from AXYS Technical Support. The factory default setting is 30 seconds.
  • Page 40 TRIAXYS™ Directional Wave Buoy User Manual version 13 By selecting 7 at the VHF Menu, the user can transmit the data which is currently in the transmit buffer. If there is nothing in the buffer, the user can load a test message as stated above. This is a diagnostic tool, and WaveViewT will not decode this message.
  • Page 41 TRIAXYS™ Directional Wave Buoy User Manual version 13 CONNECT 9600 +++ <CR> AT+CHUP <CR> NO CARRIER After dialing, the phone will connect to the receiving modem and respond with a CONNECT 9600, at which point data can be transferred or any keystrokes pressed on the keyboard will be transferred to the receiving modem.
  • Page 42 It does not archive redundant data. The TRIAXYS™ Directional Wave Buoy transmits the data in binary format. The data files are transmitted as separate blocks with CRC error checking. On being received at the base station, WaveView first verifies that the data was received from a registered platform, then will process the data into the various files listed below.

  • Page 43: Secondary Telemetry Options

    TRIAXYS™ Directional Wave Buoy User Manual version 13 2.4.2. Secondary Telemetry Options By selecting Option #2 at the Telemetry Menu, the user can access the Secondary telemetry transmitter settings. These include the following transmitters: INMARSAT D+ and ARGOS. Each of these transmitters will have a specific set of parameters that must be set to ensure proper operation.
  • Page 44 TRIAXYS™ Directional Wave Buoy User Manual version 13 transmitter (Enabled or Disabled), as used for a position and data transmitter. This can be "Disabled", but will still be activated if the WatchCircle mode has been "Enabled" (Section 2.1.5.1) and the buoy moves off station.
  • Page 45 The Wave Threshold is a mechanism unique to the TRIAXYS™ Directional Wave Buoy that allows all transmitted data to only be transmitted when the wave threshold is met or exceeded. Each individual file can be independently associated with the wave threshold.
  • Page 46 Figure 15: Enabling data transmission based on wave threshold setting Note: Settings 3 and 4 are for use by Axys technical personnel for advanced diagnostic purposes. Do Not Use Settings 3 and 4. Settings 3 and 4 will not be decoded by WaveView.
  • Page 47 2.4.2.5. Data Transmit Duration This table shows the amount of time required to transmit the data files from the TRIAXYS™ buoy using a 1200 baud configuration and binary format, based on an ACDUR of a 25 Minute Sample Record. It is...

  • Page 48: Real Time Clock

    TRIAXYS™ Directional Wave Buoy User Manual version 13 Stat 0.120K 1 second Wave 0.110K 1 second Fourier 8.0K 66 seconds NonDireSpec 2.0K 16 seconds 100 seconds MeanDir 0/75K 6 seconds 2.5. Real Time Clock By selecting 3 at the Main Menu, the user can configure the system time of the buoy.

  • Page 49: Logging Of Processed Data

    Enabled if the option is installed. The 1G flash cards on the TRIAXYS™ Wave Buoy data logger are formatted FAT 16 on a computer running Windows 9 5/98 Operating System for use by the TRIAXYS™ “Internal Data Logger". The flash cards supplied with the TRIAXYS™...

  • Page 50: Erasing Logged Data Without Opening The Buoy

    To erase information from the data logger flash card without opening up the buoy, set up IR communications with the buoy as described in the TRIAXYS™ User Manual, section 1.11. Reset the buoy using the magnetic key so that the buoy main menu is displayed on the terminal screen, and follow the steps illustrated below to access the data logger.

  • Page 51: Calibration Mode - Service Technicians Only

    By selecting 5 at the Main Menu, the user can access the calibration mode routines for the buoy. Warning: These calibration routines are to be used by service technicians trained in advanced TRIAXYS™ operation procedures. Unauthorized use of these commands may affect the performance of the TRIAXYS™...

  • Page 52: Sensor Display At 4Hz

    TRIAXYS™ Directional Wave Buoy User Manual version 13 Diagnostics 1 Sensors Scan at 4 Hz 2 Status at 1 Hz 3 System V & I 4 Wave Processing 5 System Tests 6 Reset Boot Times : 5 M Return to Main Menu Select an option..

  • Page 53: Wave Processing Diagnostics

    TRIAXYS™ Directional Wave Buoy User Manual version 13 PC-104 off Motion Sensors off Radio off SysV 13.27 SysI 0.143 BatI -0.146 Chrg 0.000 Hit P to toggle PC-104 power M for Motion Sensors R for Radio <ESC> to exit 2.8.4.
  • Page 54 TRIAXYS™ Directional Wave Buoy User Manual version 13 Got Hs=0.000 Tp=9.50 Hmx=0.000 MnDir=269.0 MnSprd=7.0 Vers.txt is 1.19,16AUG2001 2.8.4.2. Pipeline to Wave Processor By selecting 2 at the Wave Processing Diagnostics Menu, the user can access the Wave Processor (PC 104) and perform general DOS based commands.

  • Page 55: System Tests

    TRIAXYS™ Directional Wave Buoy User Manual version 13 This opens a console window into the PC 104 wave processing computer. From the console window, DOS commands are permitted, such as DIR<enter> which displays the current directory. If the data logging option is installed, follow the instructions below to view the logged data.

  • Page 56: Reset Boot Times

    If the number changes during the course of a standard deployment, please report the condition to AXYS. Please note that the Boot Time number will increment each time the user interrupts the normal run mode of the buoy.
  • Page 57 TRIAXYS™ Directional Wave Buoy User Manual version 13 WVN_F1,F2 3.000E-02 6.400E-01 WVN_STR 1.000E-02 RS_FREQ 1.280E+00 01030 TxFiles 1 1 1 1 0 0 Aux="" Hm0_th= 0.00 Boottimes Inmarsat On Inmarsat state= Enabled with 64 bit Wave Data Inmarsat Check-In Disabled...
  • Page 58 TRIAXYS™ Directional Wave Buoy User Manual version 13 CC1(1) = .1000000E+03 CC1(2) = .4883000E+00 CC1(3) = .4883000E+00 CC1(4) = -.4883000E+00 CC1(5) = .7629400E+02 CC1(6) = .7629400E+02 CC1(7) = .7629400E+02 SUB. RPW2: WRMS = .1007790E-02 Iteration Residual Error 1 .7420894E-05 2 .2077080E-07 Stop - Program terminated.
  • Page 59 TRIAXYS™ Directional Wave Buoy User Manual version 13 C:\TEMP>if exist rs_hne3.dat frame block3.fra rs_hne3.dat 00000 0 Output file: block3.fra, size = 1589 byte(s) Input file: rs_hne3.dat, size = 1578 byte(s) crc= 6def52bf C:\TEMP>if exist rs_hne4.dat frame block4.fra rs_hne4.dat 00000 0 Output file: block4.fra, size = 1589 byte(s)
  • Page 60 TRIAXYS™ Directional Wave Buoy User Manual version 13 .. <DIR> 01-01-02 12:00a TEMP_WAV BIN 2556 10-21-08 7:21p V_NORTH DAT 31074 10-21-08 7:21p V_WEST DAT 31074 10-21-08 7:21p ETA DAT 31074 10-21-08 7:21p D_NORTH DAT 31074 10-21-08 7:21p D_EAST DAT 31074 10-21-08 7:21p...
  • Page 61 TRIAXYS™ Directional Wave Buoy User Manual version 13 TEMP4 WAV 2126 10-21-08 7:21p 60 file(s) 408298 bytes 14043136 bytes free C:\TEMP>cd \ C:\>echo QQQ C:\> C:\> C:\> C:\> C:\> PC WST NMEA TSPWA.NME is $TSPWA,20081021,190000,00000,TAB00000,,,172,.00,6.2,.00,.00,10.8,. 00,15.4,6.5,28.6,28.7,.00,280.5,75.1*3F Thresh Active stat.fra[115] waves.fra[103] ndirspec.fra[535] dirspec.fra[2630] VERS...
  • Page 62 08-10-21 19:59:00 Next @ 20:00:00 zzz 08-10-21 20:00:00 After the completion of the transmission of the data, the TRIAXYS™ buoy will go into "sleep" mode prior to the start of the next data acquisition period. The previous sample collection period can be monitored on...
  • Page 63 TRIAXYS™ Directional Wave Buoy User Manual version 13 the IR communications port, but cannot be interrupted during this cycle as the RX lines on this serial device are disabled while the buoy is in run mode. Axys Technologies Inc.

  • Page 64: Moorings

    3. M OORINGS The TRIAXYS™ Directional Wave Buoy has certain mooring requirements, which need to be observed to achieve maximum performance. The key feature required in all surface wave-monitoring systems is the need to de-couple the mooring from the buoy to allow unrestricted buoy motions in wave fields.
  • Page 65 TRIAXYS™ Directional Wave Buoy User Manual version 13 Figure 17: Standard 20 to 50 m TRIAXYS Mooring Configuration Axys Technologies Inc.
  • Page 66 TRIAXYS™ Directional Wave Buoy User Manual version 13 Figure 18: Standard 20 to 150 m TRIAXYS Mooring Configuration There are several mooring designs that can be used to deploy the buoy in deeper water or faster currents. These include false-bottom moorings and inverse catenary moorings. There are many references in oceanographic literature documenting alternative mooring strategies as well as commercial mooring design programs available.

  • Page 67: Deployment Procedures

    There are no extraordinary procedures that need to be followed to prevent damage to any of the payload components or sensors. The TRIAXYS™ Buoy is a rugged instrument designed to take minor bumps anticipated through the course of routine field operations. There are no limitations associated with spinning or freezing.

  • Page 68: Software And Data Formats

    The wave processing algorithms reside both in the buoy firmware and WaveViewT base station software for VHF and GSM transmitted data. The TRIAXYS™ Post Processing Software will take raw logged TRIAXYS™ Buoy data and perform all wave analysis and archive the data into various data products.

  • Page 69: Motion Analysis

    4.1.5. Low Frequency Energy The Root Mean Square (RMS) noise value for the accelerometers in the TRIAXYS™ sensor is about 0.0005g. This noise is uniformly distributed over the nominal measurement bandwidth of 1 Hz so the vertical acceleration spectra have a fairly constant amplitude of approximately 0.0000 1 (m2/s4)/Hz at all frequencies.

  • Page 70: Directional Wave Analysis

    4.2. TRIAXYS™ Data Formats The data is transmitted from the TRIAXYS™ Directional Wave Buoy as per the set-up instructions of the Buoy User Manual via either VHF, GSM cell phone telemetry and email receipt of YYYYMMDD.RX data. The WaveViewTM software builds complete data files from the repeated messages. It does not archive redundant data.

  • Page 71: File Yyyymmdd.rx

    NOTE: In areas where there is significant radio interference, the operator may see many extra data sets of random Hex values with a header time stamp. A valid TRIAXYS™ message should begin with "7F". The timing of the incoming data time stamps should correspond to the set-up parameters on the buoy, i.e., reception hourly at 27 minutes past the hour for a 25 minute sample starting at the top of the hour.

  • Page 72: File Yyyymmdd.fourier

    TRIAXYS™ Directional Wave Buoy User Manual version 13 Parameter Formula/Units Received Message Time (computer time) YYMMDD HHMMSS Status Message Time (buoy time) YYMMDDHHMM Buoy ID 12 Characters Alphanumeric Location (lat./long.) DDMM.MMM/ DDDMM.MMMM Water Temperature 0.0°C Battery Voltage 0.0 VDC Sample Rate (4 Hz) 4HZ.( Fixed)

  • Page 73: File Yyyymmdd. Dirspec

    TRIAXYS™ Directional Wave Buoy User Manual version 13 bands. The first four lines of data include: Date/time Number of frequency bands (n) Centre of the initial frequency band Frequency Separation The fifth and subsequent lines of data include the m2/Hz values for each...

  • Page 74: Yyyymmdd.hne

    TRIAXYS™ Directional Wave Buoy User Manual version 13 INITIAL FREQUENCY (HZ) 0.000 FREQUENCY SPACING (HZ) 0.005 DIRECTION SPACING (DEG) 3.000 ALL VALUES FOR DIR1(1..NFREQ) ARE GIVEN, THEN ALL VALUES FOR DIR2(1..NFREQ) ETC (1..NDIR) 0.00000E+00 0.00000E+00 0.00000E+00 0.00000E+00 0.00000E+00 0.00000E+00... 0.00000E+00 0.00000E+00 0.00000E+00 0.00000E+00 0.00000E+00 0.00000E+00...

  • Page 75: Logged Data Format

    This data is described in the following section as to file nomenclature. To review the logged data, the user must first run the logged data through the TRIAXYS™ Post Processing Software. The use of this application is described in Chapter 6 of the TRIAXYS™ Directional Wave Buoy Applications Software User's Manual.

  • Page 76: Orbcomm Transmitted Data Format (Optional)

    It does not archive redundant data. The TRIAXYS™ Directional Wave Buoy transmits the data in binary format. The data files are transmitted as separate blocks with CRC error checking. On being received at the base station, WaveViewT first verifies that the data was received from a registered platform, then will process the data into the various files listed below.

  • Page 77: Description Of Argos Parameters

    The current TRIAXYS™ Directional Wave Buoy ARGOS format is based on using the 28-bit ARGOS user ID found in Table 1.5. NOTE: Decode of the ARGOS data can also be done using TRIAXYS™ ARGOS Decode Software. Refer to the TRIAXYS™ Application Software Manual for more information.
  • Page 78 TRIAXYS™ Directional Wave Buoy User Manual version 13 Acquisition ARGOS Reported ARGOS Reported Acquisition Interval Duration AC DUR AC INT 1440 Axys Technologies Inc.

  • Page 79: Powering Argos On And Off

    TRIAXYS™ Directional Wave Buoy User Manual version 13 Data Range Bits XOR Checksum from next bit to end of message Housekeeping (T=0)* Sample Start - Year 0 to 31 Sample Start - Month 01 to 12 Sample Start - Day...
  • Page 80 TRIAXYS™ Directional Wave Buoy User Manual version 13 Both Processed and Raw data can be recorded on the TRIAXYS™ Directional Wave Buoy onto a single PCMCIA 1 Gbyte Flash Ram card. See section 1.6.1 for data capacities. This data is described in the following section as to file nomenclature.

  • Page 81: Base Station System Configuration

    The basic requirements are a means to input the transmitted TRIAXYS™ data message into a PC running WaveView, either by direct VHF transmission, telephone modem or email. Each of these are described in the following section 5.1.

  • Page 82: Vhf Radio Receiver

    TRIAXYS™ Directional Wave Buoy User Manual version 13 5.2. VHF Radio Receiver Frequency Ranges: 29 to 38 MHz or 38 to 50 MHz Number of channels: 16 preset channels. Set at the factory. Received Signal Strength: 1.0 to 5.0 VDC linear over 60 dB input signal level Change Operating Temperature: -30øC to +60øC, non condensing...

  • Page 83: Modem

    TRIAXYS™ Directional Wave Buoy User Manual version 13 realignment of the radios. The frequency change is the accumulated frequency change in relation to the frequency stamped on the label. For a minor frequency change contact AXYS for a detailed work instruction.

  • Page 84: Operation Of The Tdr

    If a Laptop Computer is supplied with the System, no setup is required. The internal modem of the laptop only needs to be connected to the phone line that the TRIAXYS™ Buoy has been configured to call. NOTE: This must be an Analog phone line (NOT a digital line).

  • Page 85: Internet Reception Of Buoy Data

    PC running a registered copy of WaveView software and connected to either a LAN or dialup ISP can receive, decode, display and archive the emailed wave data. Further functionality of the email features are discussed in the TRIAXYS™ Applications Software User's Manual. Axys Technologies Inc.

  • Page 86: Triaxys ™ Application Software

    TRIAXYS™ Directional Wave Buoy User Manual version 13 6. T ™ A RIAXYS PPLICATION OFTWARE See the TRIAXYS™ Software User Manual Version 01 Axys Technologies Inc.

  • Page 87: Assembly /Disassembly Procedures

    The following procedures for removal and replacement of the Dome must be carried out if the Dome is being removed to replace the batteries or to access the other systems inside the TRIAXYS™ Buoy. Ensure that proper gas detection or purging procedures have been followed prior to the removal of the dome as described in Section 7.1.

  • Page 88: Dome Installation

    Damaged Dome Studs In the event that the TRIAXYS™ hull dome studs are damaged and prevent the dome from being properly tightened as specified in Section 7.2.2, the studs can be replaced with an M8 x 45mm SS316 hex bolt by...

  • Page 89: Triaxys™ Sensor And Telemetry Module

    Remove the dome and solar panel assembly per previous sections. Loosen the two captive screws on the front of the top of the lid of the TRIAXYS™ Sensor Module. Lift up the lid of the Module. It is hinged at the back.

  • Page 90: Replacing The Triaxys™ Sensor And Telemetry Module

    *Formatted using FAT 16 protocol or erase the card in the direct pipeline mode per section 2.6.4.2. 7.3.1.1. Removing the TRIAXYS™ Sensor and Telemetry Module If the TRIAXYS™ Sensor and Telemetry Module needs to be removed from the buoy to return to an authorized service depot, the following procedures should be carried out.

  • Page 91: Removal Of Batteries

    TRIAXYS™ Directional Wave Buoy User Manual version 13 7.4.1. Removal of Batteries Before the batteries can be removed, the Sensor and Telemetry Module has to be removed (see Section 8.2 above). Ensure that the orange battery connectors are unplugged from the Solar Panel Assembly.

  • Page 92: Care And Maintenance

    2 hours. For storage protection of the dome it is recommended that the shipping/storage cover be kept in place at all times when the TRIAXYS™ Directional Wave Buoy is not in use. Care should be taken not to scratch or damage the sealing flange surface.

  • Page 93: Set Up And Check Out Procedures

    The compass inside the buoy sets this orientation. The Module sits on rubber pads over the four upward pointing studs on the battery brackets. Fasten the TRIAXYS™ Sensor and Telemetry Module using M6 flat washer and M6 Nylock nuts (SS316). Tighten until rubber is slightly compressed, but not so tight that the feet are against the bottom nut.
  • Page 94 Press 6 to reset the boot times to zero. This indicates how many times the TRIAXYS™ processor has been reset. A reset occurs when the Magnetic Key is replaced and then removed. Press M to return to the MAIN MENU.

  • Page 95: Moorings

    9.6.1. Deployment Procedures The procedures to deploy a moored TRIAXYS™ buoy are as follows: Layout all mooring components in the correct order and in a fashion that will allow for a free run during pay out (either flaked in parallel lines or in a figure of eight).

  • Page 96: Recovery Procedures

    There are no extraordinary procedures that need to be followed to prevent damage to any of the payload components or sensors. The TRIAXYS™ Buoy is a rugged instrument designed to take minor bumps anticipated through the course of routine field operations. Operators should take precautions when working in extreme conditions, which can jeopardize the safety of both personnel and equipment.

  • Page 97: Glossary

    TRIAXYS™ Directional Wave Buoy User Manual version 13 LOSSARY Acceleration of gravity (g) - The rate of change with time of the velocity of an object caused by the earth's gravitational force. Acquisition Duration (AC DUR) - The duration of a data acquisition event (minutes). This duration is limited to between 1 and 35 minutes.
  • Page 98 TRIAXYS™ Directional Wave Buoy User Manual version 13 Fourier Transform - A mathematical transform that converts a time series of data that has been collected at a specific sample interval into a series of frequency energy data, e.g., data in meters is converted into m2/Hz.
  • Page 99 TRIAXYS™ Directional Wave Buoy User Manual version 13 Shoaling -Changes in wave height as waves move into shallow water. Except for a limited depth region, shoaling increases wave heights. Shoaling occurs even if wave heights and directions do not change as a result of wave refraction.

  • Page 100: References

    TRIAXYS™ Directional Wave Buoy User Manual version 13 EFERENCES References to the software used in the TRIAXYS™ Directional Wave Buoy include: Nwogu, O.U., E.P.D. Mansard, M.D. Miles, M. Isaacson (1987) "Estimation of Directional Wave Spectra by the Maximum Entropy Method". IAHR Seminar on Wave Analysis and Generation in Laboratory Basins, Lausanne, pp.

  • Page 101: Appendix A - Axys Warranty And Service Limited Warranty

    The above Warranty applies only to Products manufactured by AXYS. Equipment provided, but not manufactured by AXYS, is warranted and will be repaired to the extent of and according to the current terms and conditions of the respective equipment manufacturer.
  • Page 102 TRIAXYS™ Directional Wave Buoy User Manual version 13 ú All systems returning to AXYS are put through an incoming inspection to determine the validity of the warranty claim. If a valid warranty claim is established, an inspection fee is waived; otherwise the owner will be invoiced the minimum inspection fee of $500.

  • Page 103: Appendix B - Obstruction Light Flash Sequences & Codes

    TRIAXYS™ Directional Wave Buoy User Manual version 13 APPENDIX B - OBSTRUCTION LIGHT FLASH SEQUENCES & CODES Light Flash Code Reference - listed by number of flashes SYMBOLS FL Flash -followed by number e.g., Fl 1 S one every second Q Quick...

  • Page 104: Appendix C: Sample Triaxys Buoy Field Checkout/Deployment Record

    TRIAXYS™ Directional Wave Buoy User Manual version 13 APPENDIX C: SAMPLE TRIAXYS BUOY FIELD CHECKOUT/DEPLOYMENT RECORD General Date: TRIAXYS Serial Number: TDR S/N: Deployment Location: WaveView Version: Form Completed by: Depth: Functional Checkout: Work Instruction 0260701E Completed: Compass: Rotate buoy through a full circle checking the output of buoy North against a hand compass.

  • Page 105: Appendix E - Triaxys™ Faq

    How is the TRIAXYS™ Buoy constructed? A: The TRIAXYS™ hull consists of two parts. The lower half or hull is constructed of a single piece of 316 stainless steel covered with a thermal powder coat finish and the dome is constructed of clear polycarbonate.
  • Page 106 How is a TRIAXYS™ Buoy deployed? A: The TRIAXYS™ can be deployed in currents up to about 3kts. Currents greater than this may cause the buoy to submerge periodically. While this will not compromise the buoy in anyway it may affect the quality of the data and the reliability of the telemetry.
  • Page 107 Please refer to the User's Manual for instructions on removal and replacement of the batteries. The flange gasket between the dome and hull of the TRIAXYS™ should be replaced as required or every two years to ensure its condition is sufficient to allow the dome and hull to form a seal prior to deployment.
  • Page 108 TRIAXYS™ Directional Wave Buoy User Manual version 13 A: As detailed in Section 2.0 of the TRIAXYS™ Manual, the buoy will need to be configured with your operating parameters if you require a set up that is different from the default settings. The PC or Laptop you use for this setup procedure must be equipped with a RAW IR driver and of course a hyperterminal or IR terminal.
  • Page 109 How is Local Magnetic Variation handled on the TRIAXYS™ and on WaveView? A: Local Magnetic Variation is not corrected for on the TRIAXYS™. The wave data sent from the buoy to the base station will not have any corrections for true north applied. In addition, WaveView makes no corrections for local magnetic variation.
  • Page 110 There should be more than enough solar and battery capacity to recharge throughout the spring and summer and be ready again for the next winter. It is very important to ensure the TRIAXYS™ is deployed with batteries at full charge or seasonal solar radiation fluctuations may result in a buoy with too little battery power to function.
  • Page 111 VHF in the area. Interference in the area can be measured by determining the baseline and receive voltage on the TRIAXYS™ Digital Receiver (TDR). By pressing the DISPLAY button on the TDR, (when the TDR is NOT receiving), the baseline voltage will be displayed. This voltage is normally in the 1.0 to 2.5 volt level;...
  • Page 112 Summary files cannot be displayed graphically using the Data Viewer. Additionally, WaveView CANNOT be used to view post processed data from a flash memory card. If desired, AXYS offers data post processing of your logged data, which can then be viewed using Excel's graphing function.
  • Page 113 TRIAXYS™ Directional Wave Buoy User Manual version 13 coated cable. For water depths greater than 75m false bottom or reverse caternary designs can be implemented. The mooring should be inspected every six months with replacement each year. Anchor weight should be about 3 00kg wet. It can consist of heavy link chain or other iron material. If a concrete anchor is desired, then its air weight must be approximately 600kg or twice the wet weight.
