USER MANUAL
PITCH
MOD
MODE
TRANSPOSE
SWING
SC
C
C#
D
D#
E
F
ARP
UP
DOWN INCL
EXCL RAND ORDER
SMK-25
VEL
OCT
LATCH
GATE
TEMPO
RATE
TRANSPOSE
F#
G
G#
A
A#
B
OFF
REPEAT
OCT+LATCHGATE+ GATE- TAP
SWING+SWING-TEMPO+TEMPO-
Pad 1
Pad 2
PRE
Pad 5
Pad 6
CH
TRIAD
7TH
9TH RAND OFF
SYNC
1/4
1/4T 1/8
Pad 3
Pad 4
Pad 7
Pad 8
MAJOR
MINOR
1/8T
1/16 1/16T 1/32
1/32T

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMK-25 and is the answer not in the manual?

Questions and answers

Summary of Contents for LEKATO SMK-25

  • Page 1 USER MANUAL SMK-25 Pad 1 Pad 2 Pad 3 Pad 4 PITCH Pad 5 Pad 6 Pad 7 Pad 8 MODE LATCH GATE TRANSPOSE SWING TEMPO RATE TRANSPOSE TRIAD 9TH RAND OFF MAJOR MINOR DOWN INCL EXCL RAND ORDER REPEAT...
  • Page 2 Ⅱ.Making the connection ■USB Connection : Plug the cable through the USB port to the Windows/Mac it will automatic be recognized , When plug into Windows/Mac the SMK-25 will be charging at the same time; (Red light : charging , Green light :charging complete) ■Wireless Connection : Press and hold the BT button, when the light flashing...
  • Page 3 Ⅲ.Presets Setup ① ⑦ ④ ③ ② Pad 1 Pad 2 Pad 3 Pad 4 PITCH Pad 5 Pad 6 Pad 7 Pad 8 ⑥ MODE LATCH GATE ⑤ TRANSPOSE RATE SWING TEMPO TRANSPOSE TRIAD 9TH RAND OFF MAJOR MINOR DOWN INCL EXCL RAND ORDER REPEAT...
  • Page 4 ③ Display area; ③ ④ ④ Button area; PLAY : Control the Play function of the Daw; STOP : Control the Stop function of the Daw; RECORD : Control the Record function of the Daw; Note:To use Transport control needs to Select the presets within the keyboard and set up inside Daw correctly;...
  • Page 5 ⑤ Oct+,Oct- ⑤ This two buttons adjust the pitch range of the keyboard, Hold OCT+/OCT- and rotate the Transpose Knob to Shift the Pitch by one note per step; Higher the octave range of keyboard , faster the light of the OCT+button will flashing;...
  • Page 6 Ⅳ.Arpeggiator instructions Arpeggiator Types( Up,Down,Incl,Excl,Random,Order,Repeat) Press and hold the Arp button or Press the button and rotate the knob to change the way arpeggiator work based on BPM/Tempo; Up : The pressing notes will play from the lowest to highest; Down : The pressing notes will play from the highest to lowest;...
  • Page 7 Ⅴ.Smart Scale/Chord instructions Smart Scale Mode: Select the scale : Hold the button and press the notes C-B to select the scale; Major/Minor : When set to the selected scale , hold the button and press the major/minor to determined weather it is a major scale or minor scale; For example : If you want to select C minor scale , hold the button and press the C on the left side of keybed and Minor on the right side of keybed ,After setting correctly all the keys that been played will be fit in the C minor Scale;...
  • Page 8 Ⅶ .Technology Parameters Product Dimensions 321mm(L) x 178mm (W)x 46mm(H) Product Weight 750g Keys Twenty-five velocity-sensitive keys; 8 RGB Back-Lit Pads with velocity-sensitive and after touch; Pads 8 assignable endless 360 degree encoders; K n o b s Touch Stripes Capacitive touch-stripes pitch bend &...
