Summary of Contents for Deditec MOD-REL8 10A

Page 1 MOD-REL8_10A Hardware description 2023 März...
Page 2 INDEX 1. Introduction 1.1. Foreword 1.2. Customer satisfaction 1.3. Customer response 1.4. Brief description 2. Commissioning 2.1. Step 1 - Safety instructions 2.2. Step 2 - Connecting the power supply 3. Hardware description 3.1. General technical data 3.1.1. Technical data 3.2.
Page 3 Introduction Introduction | Seite...
Page 4: Customer Satisfaction
1. Introduction 1.1. Foreword Congratulations on purchasing a high quality DEDITEC product! Our products are developed by our engineers according to today's required quality standards. We pay attention already during the development to flexible expandability and long availability. We develop modular!
Page 5: Brief Description
1.4. Brief description The "MOD-REL8_10A" is a power or expansion module that has eight changeover relays with a switching capacity of 40V/10A AC or 40V/8A DC. External low-power outputs e.g. of a PLC, relay or optocoupler can be used for switching.
Page 6 Commissioning Commissioning | Seite...
Page 7: Step 1 - Safety Instructions
2. Commissioning 2.1. Step 1 - Safety instructions Before commissioning your DEDITEC product, please familiarize yourself with this manual and read the following points carefully: Damage caused by non-observance of these operating instructions will void · the warranty or guarantee of this product. We do not accept any liability for...
Page 8: Step 2 - Connecting The Power Supply
2.2. Step 2 - Connecting the power supply Select a suitable power supply* with sufficient power of at least 5 watts and an output voltage of, for example, +7VDC or +24VDC. The power supply is connected to the 2-pole pluggable screw terminal. Please note the polarity as shown below.
Page 9: Hardware Description
Hardw are description Hardware description | Seite...
Page 10: General Technical Data
3. Hardware description 3.1. General technical data 3.1.1. Technical data Supply voltage: 24V DC · 8*Relay outputs (changeover contact) · Maximum switching voltage: 40V · Maximum switching current: 10A AC / 8A DC · Potential-free switching inputs (no control voltage required) ·...
Page 11 3.2. Overview pictures 3.2.1. Overview image of a MOD-REL8_10a Hardware description | Seite...
Page 12: Pin Assignments
3.3. Pin assignments 3.3.1. Pin assignment MOD-REL8_10a Description Relais Opener Common Relais 1 Closer Opener Common Relais 2 Closer Opener Common Relais 3 Closer Opener Common Relais 4 Closer Hardware description | Seite...
Page 13 Description Relais Opener Common Relais 5 Closer Opener Common Relais 6 Closer Opener Common Relais 7 Closer Opener Common Relais 8 Closer Hardware description | Seite...
Page 14: Connection Wiring
3.4. Connection wiring 3.4.1. Connection wiring 16pin connector The 16-pin connector J3 provides the coil contacts of the eight changeover relays. The changeover relay can be switched via any potential-free make/break contact. Pin assignment for 16pin connector J3: Port Pin - J3 Coil relay 1 &...
Page 15 Appendix Appendix | Seite...
Page 16: Contact / Support
Support Hardware Tel. +49 (0) 22 32 / 50 40 8 – 30 Support via E-mail support@deditec.de 4.2. Environment and disposal You can return the defective or obsolete product to us at the end of its service life. As a manufacturer and distributor of electronic assemblies, we will take care of the proper disposal for you in accordance with the applicable legal regulations.
Page 17 4.3. Revisions Rev 3.00 DEDITEC Design Update Rev 2.00 Index added Rev 1.00 First instruction Appendix | Seite...
Page 18: Copyrights And Trademarks
4.4. Copyrights and trademarks Linux is a registered trademark of Linus Torvalds. USB is a registered trademark of USB Implementers Forum Inc. LabVIEW is a registered trademark of National Instruments. Intel is a registered trademark of Intel Corporation. AMD is a registered trademark of Advanced Micro Devices, Inc. ProfiLab is a registered trademark of ABACOM Ingenieurbüro GbR.
