Summary of Contents for egber VandalVeto 800367

  • Page 1 AV over IP Extender User Manual Model : 800367,800368 1080P HDMI KVM & USB, RS232 , IR, Audio over IP Extender...
  • Page 2 User Manual 800367,800368 Introduction 800367,800368 uses AV over IP technology to route up to 1,000 HDMI sources to up to 60,000 displays over IGMP and Jumbo frame protocol gigabit switches, achieving HDMI signal extending, distributing, switching, and routing. Additionally, the boundless switching function allows you to use one mouse to operate multiple PCs by moving the mouse cursor across each HDMI monitors' borders.

  • Page 3: Installation View

    User Manual 800367,800368 Installation view...

  • Page 4: Panel View

    User Manual 800367,800368 Panel view 800367 800368 Panel Button Function Button - and + together Short Press Reduce Number Increase Number Enter Press 1 seconds Menu/Cancel Carry Decomposition Press 3 seconds Lock/Unlock Button(When no OSD menu) Press and hold then power on Factory Default Engineering Mode Set Factory Default then enter Engineering Mode...
  • Page 5 User Manual 800367,800368 Receiver: video output be turned off Breathing(Fading) Screen saver mode (not available for transmitter) Connected & video is streaming Link(Blue) Flash Connecting, or no source input from transmitter Transmitting /receiving IR signal Other message (IR, RS232, System setting…) Flash Slowly Menu mode IR(Red)
  • Page 6 User Manual 800367,800368 Cable & Transmission Distance Link Cable use high quality CAT.5e UTP/STP/FTP or CAT.6 UTP cable Transmission distance will be affected by equipment (Switch HUB), cable quality…etc. When using CAT.5e/CAT.6 cable connect transmitter and receiver directly without Ethernet switch, the maximum transmission distance up to 150M.
  • Page 7 User Manual 800367,800368 For 8~16 sources: use switches which support 802.3ad Link Aggregation or smart (or intelligent) switches to get 2 Gbps or more bandwidth. For over 16 sources: use switches which support SFP+ uplink or stackable switches to get 10 Gbps bandwidth.

  • Page 8: Ir Remote Control Operation

    User Manual 800367,800368 Number 5 Number 6 Number 7 Number 8 Number 9 Number 0 IR Remote Control Operation Select Channel: Mode 1: use  or or or  to select channel and press ENTER to confirm. Mode 2: enter the channel number and press ENTER to confirm the input channel. Select Menu Function: Mode 1: press MENU then use ...
  • Page 9 User Manual 800367,800368 IR Menu Function List Menu Description Option / Remark System Information System Information Network Information Network Information Function Information Function Information Control Information Control Information Video & Audio Video & Audio Information Information RS232 Control RS232 Control Information Information Channel Information Channel Information...
  • Page 10 User Manual 800367,800368 4 = Full HD 1080p 50Hz 5 = Customize 0 = Digital TX Audio Input Select Audio Select 1 = Analog /RX Audio Output Select 2 = Auto Analog Input Volume Analog Input Volume 0 = Mute 1 ~ 100 = Volume % Analog Output Volume Analog Output Volume...
  • Page 11 User Manual 800367,800368 Fast Switch Switch without stop link 0 = Disable Conflict Check Check existing TX channel 1 = Enable 0 = Hide Channel Name Display Channel Name 1 = Display Only Favorites Only Favorites Channel Available 0 = Disable Lock Favorites Lock Favorites Channel 1 = Enable...
  • Page 12 User Manual 800367,800368 Preset Configuration Set RX Group ID 0 ~ 15 (OEM Version only) System Reboot System Reboot Caution of IR Menu Function  Menu 17 Free Routing function only works in Multicast mode.  Menu 22 When disable USB extender function it will also disable keyboard mouse function. ...
  • Page 13 User Manual 800367,800368  Menu 80~86 Fix selected function not follow the channel, only available when free routing enabled. Menu 90~107 Only available when video wall function enabled..  Menu 200 Will not backup the parameters of men function 107 Save Video Wall. ...
  • Page 14 User Manual 800367,800368 RS232 Control In RS232 extender mode, user could use RS232 port of transmitters to operate/setup the receivers at same channel by program like Hyper Terminal which built-in Windows XP and before version. Hyper Terminal setting:〔115200 bps (8-N-1), Flow control: None〕(Properties -> Settings -> ASCII Setup… and select “Send line ends with line feeds”...
  • Page 15 User Manual 800367,800368 NAME CLR Clear all channel name NAME IMPORT Import channel name FAST ? Status of current fast switch FAST [ ENABLE | DISABLE ] Enable/disable fast switch CHECK ? Status of channel conflict check CHECK [ ENABLE | DISABLE ] Enable/disable channel conflict check Usage of favorite channel (MAX.32) Add current to favorite channel...
  • Page 16 User Manual 800367,800368 ROW? Show position in row ROW [ 0~7 ] Set position in row COLUMN ? Show position in column COLUMN [ 0~15 ] Set position in column STRETCH ? Status of stretch type STRETCH [ 0~2 ] Set stretch, 0 = Auto, 1 = Stretch Out, 2 = Fit In ROTATE ? Status of rotate type...
  • Page 17 User Manual 800367,800368 ROUTING [ FOLLOW | 0~999 ] Set IR routing follow or specified CTRL ? Status of IR control setting CTRL [ ENABLE | DISABLE ] Enable/disable IR control ID ? Status of IR remote ID ID [ 0~10 ] Set IR remote ID KEY [ 0~32 ] ? Status of IR key setting...
  • Page 18 User Manual 800367,800368 IP_ MO DE [ 0~2 ] 0=Auto, 1=static, 2=DHCP IP ? Status of static IP address IP [ xxx. xxx. xxx. xxx ] Set static IP address NETMASK ? Status of subnet mask (static IP mode) NETMASK [ xxx. xxx. xxx. xxx ] Set subnet mask (static IP mode) GATEWAY ? Status of gateway (static IP mode)
  • Page 19 User Manual 800367,800368 >CMD_G34> CHANNEL 5 (Set receivers which Group No is to Channel 5) (HEX code: 3E 43 4D 44 5F 47 3E 20 43 48 41 4E 4E 45 4C 20 35 0D 0A) (No response from multiple receivers) 33 34 ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- >CMD_ALL>...

  • Page 20: Keypad Control

    User Manual 800367,800368 Keypad Control You can use RS232 Keypad or terminal program with number key to emulate IR remote operation. Before using RS232 keypad you have to select Keypad by Menu 50 RS232 Select, and set keypad baudrate Menu 54 Auxi li ary Baudrate.
  • Page 21 User Manual 800367,800368 IP Setting You could input the IP address of transmitter / receiver at link column of browser which printed in the label. If the label is missing or not able to identify you can check the IP address as below: How to get the IP address of receiver: Check the sticker at bottom of receiver with default IP Connect monitor with receiver,...
  • Page 22 User Manual 800367,800368 could reset the transmitters and receiver to default in two ways below: 1. Press the channel button “- “ than power on (power and link LED will be flash) to reset to default. 2. Press IR remote control MENU, 3, 3, 3, ENTER to reset to default.
  • Page 23 User Manual 800367,800368 During update the web will shows the status as above message. Updated unit will reboot automatically after updating firmware. If not, please reboot manually. D o not ref resh, close, sw i tch tab of w eb brow ser or pow er of f to avoi d any damage duri ng f i rmw are update. Utilities ...
  • Page 24 User Manual 800367,800368 Statistics  Indicate system status...

  • Page 25: Video Wall

    User Manual 800367,800368 Video Wall: Basic Setup  Bezel and Gap Compensation: Set outer width/height of monitor and width/height of viewable area.  OW: outside width OH: outside height VW: viewable width VH: viewable height Please note: 1. The viewable width/height must be less than the outside width/height. 2.
  • Page 26 User Manual 800367,800368  Advance Setup:...
  • Page 27 User Manual 800367,800368 Before enter “Advanced Setup”, please complete the “Basic Setup” as follows: In “Basic Setup”, select Vertical and Horizontal Monitor Count. 2. In “Advanced Setup”, choose the target of the video wall to control Step 2: Control Options Reset to Basic Setup: ...
  • Page 28 User Manual 800367,800368 Setup the video output to “Fit In’ or “Stretch Out” mode in the screen Clockwise Rotate:  Setup the rotation angle 0,180, 270 degree of the video output Screen Layout (Row x Column):  Set up the number of vertical and horizontal monitor based on the video wall layout. Vertical number 1~8 and horizontal number 1~16.
  • Page 29 User Manual 800367,800368 Column Position:  Setup the column position of monitor, number from 0 to the total number of horizontal monitor. Horizontal/Vertical Shift:  Horizontal/Vertical Scale Up  Horizontal Shift: Set the video horizontal shift, Left or Right by pixels. Vertical Shift: Set the video vertical shift, Up or Down by pixels.
  • Page 30 User Manual 800367,800368  Consol API Command: Input Linux command to do advanced setup.
  • Page 31 User Manual 800367,800368 Network: IP Setup:  IP Mode could be Auto IP, DHCP, Static three mode Host default setting is Static IP, client default setting is Auto IP For mass deploying please use static or DHCP mode. Notice: if there is no DHCP server in network the host/client will keep reboot, you need to set the host/client to factory default Press channel button “-”...
  • Page 32 User Manual 800367,800368 Functions for Transmitter: Video over IP  Enable Video over IP: This function setup the video signals send from network.  Enable Video Wall: This function setup the video wall, default is not checked.  Maximum Bit Rate: Set maximum bit rate. ...
  • Page 33 User Manual 800367,800368 USB over IP  Enable USB over IP: Enable/disable USB extender function.  Operation Mode: Set USB operation mode. Recommand Auto select mode.  Compatibility Mode: Set USB compatibility mode.  Serial over IP：  Enable Serial over IP: setup Serial (RS232) signal sends from network ...
  • Page 34 User Manual 800367,800368 Functions for Receiver: Video over IP  Enable Video over IP: This function setup the video signals send from network.  Copy EDID from this Video Output: Copy EDID from TV when booting (unicast mode only),  default is not checked.
  • Page 35 User Manual 800367,800368 USB over IP:  Enable USB over IP: Enable/disable USB extender function.  Operation Mode: Set USB operation mode. Recommand Auto select mode.  Compatibility Mode: Set USB compatibility mode. ...

  • Page 36: Troubleshooting

    User Manual 800367,800368 Troubleshooting Transmitter/receiver boot time require 30 seconds and will be able to control after booting, First time reboot after reset to default will be longer than 30 seconds. Not recommend to work with existing LAN connection to avoid large video, data transmission or multicast packets to slow down your other LAN devices.
  • Page 37 User Manual 800367,800368 Package Include 800367 Package Include: Transmitter x 1 pcs USB A to B cable x 1 pcs IR emitter cable x 1 pcs DC 5V 2A power adapter x 1 pcs 800368 Package Include: Receiver x 1 pcs IR emitter cable x 1 pcs IR remote control x1 pcs DC 5V 2A power adapter x 1 pcs...

  • Page 38: Specification

    User Manual 800367,800368 Specification ITEM NO. 800367 800368 Support Compliance HDCP 1.4, USB 1.1, USB 2.0 Max. Video Resolution 1080p@60Hz, 1920 x 1200px Max. Transmission Distance 150M over CAT5e Cable or Greater 7.1 LPCM 192kHz, Dolby True HD, DTS-HD Master Audio, ATMOS, Audio Format DTS:X IR Support...
